York International RHP Series Technical Manual

Split system heat pumps
Hide thumbs
Table of Contents

Advertisement

Quick Links

TECHNICAL
TECHNICAL
GUIDE
GUIDE
TECHNICAL GUIDE
RHP SERIES
SPLIT SYSTEM
HEAT PUMPS
14 SEER – R-410A – SINGLE-PHASE
1.5 TON TO 5 NOMINAL TON
MODELS: RHP14L18 TO 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Standard 5-Years limited parts warranty.
Standard 5-Years limited compressor warranty.
Extended 10-Years limited parts and compressor warranty
when product is registered online within 90 days of purchase
for replacement or closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed
®

DESCRIPTION

The RHP14L heat pumps are optimized for the 14 SEER / 8.2
HSPF Minimum Efficiency in all US Regions, and are specifi-
cally designed to be matched with Johnson Controls Ducted
Systems indoor coils, furnaces, and air handlers to provide a
complete system solution.

FEATURES

• Easier Installation - Independent panels provide quick
access for unit setup. Installation time is reduced by easy
power and control wiring access. The factory installed filter-
drier and factory charge for a 15 ft lineset means less time
spent brazing and charging the system. The small base
dimension and reduced unit size make for easier retrofits.
• Durable Finish - The coated steel wire fan guard, coated
external fasteners, and pre-treated G90-equivalent galva-
nized steel chassis components resist corrosion and rust
creep. Powdercoat paint further protects external panels.
• Louvered Coil Protection - Two stamped steel louvered
panels protect the coil from mechanical damage.
• Quality Coils - Enhanced aluminum fins are mechanically
bonded to copper tubing.
• Protected Compressor - Compressors are protected inter-
nally by a high pressure relief valve and a temperature sen-
sor, and externally by the system high and low pressure
switches. The liquid line stainless steel filter-drier is factory
installed to protect the compressor against moisture and
debris.
• Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
• Top Discharge - Air is blown up, away from the structure
and any landscaping and allows compact location on multi-
unit applications.
• Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.
5612272-UTG-H-1221
