- Page 1 TOP-12AC Wi-Fi 5 AC 1200Mbps Ceiling Access Point TOP-18AX Wi-Fi 6 AX 1800Mbps Ceiling Access Point inWall-U618AX Wi-Fi 6 AX 1800Mbps inWall Access Point Web Manual Ver. 1.0...
-
Page 2: Table Of Contents
2.3 TOP-12AC, TOP-18AX, inWall-618AX Hardware installation 2.4 TOP-12AC, TOP-18AX Installation 2.5 InWall-U618AX Installation Chapter 3 Quick Installation Guide 3.1 TOP-12AC, TOP-18AX , Web login Management 3.2 Configuring the IP Address Manually 3.3 Starting Setup in the Web UI Chapter 4 Configure the Access Point 4.1 Main Home Page... - Page 3 4.6 Network (AP Mode) 4.6.1 LAN Settings 4.6.2 Cloud 4.7 Network (Gateway Mode) 4.7.1 LAN Settings 4.7.2 Static DHCP 4.7.3 WAN 4.7.4 WAN DHCP 4.7.5 WAN Advanced Settings 4.7.6 WAN Static IP 4.7.7 WAN PPPoE 4.7.8 Cloud 4.8 Firewall (Gateway Mode Only) 4.8.1 URL Filter 4.8.2 IP Filter 4.8.3 MAC Filter...
-
Page 4: Product Introduction
Before using this access point, please check if there is anything missing in the package, and contact your dealer of purchase to claim for missing items: ⚫ TOP-12AC or TOP-18AX Ceiling Mount Access Point P ackage Co ntents of WDAP-C7210E ⚫... -
Page 5: Product Specification Top-12Ac
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Product Specification TOP-12AC Model TOP-12AC AC1200 Access Point Device Interface Management Main Chip: MTK, Dual Core MT7621DAT Web-UI, Remote Management, WLAN Controller, • • Cloud Management System AirCloud Flash:8MB • RAM:128MB DDNS • Ethernet (LAN): 1 x RJ45 10/100/1000mbps •... -
Page 6: Product Specification Top-18Ax
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Product Specification TOP-18AX Model TOP-18AX AX1800 Access Point Device Interface Management Main Chip: MTK, Dual Core MT7621AT Web-UI, Remote Management, WLAN Controller, • • Cloud Management System AirCloud Flash:16MB • RAM:256MB DDNS • Ethernet (LAN): 1 x RJ45 10/100/1000mbps •... -
Page 7: Product Specification Inwall-U618Ax
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Product Specification inWall-U618AX Model inWall-U618AX AX1800 Access Point Device Interface Management Main Chip: MTK, Dual Core MT7621DAT Web-UI, Remote Management, WLAN Controller, • • Cloud Management System Flash:16MB • RAM:256MB DDNS • Ethernet (LAN): 4 x RJ45 10/100/1000mbps Oray •... -
Page 8: Hardware Installation
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Chapter 2. Hardware Installation TOP-12AC and TOP-18AX Port description. PWR and SYS LED Front Panel LED Description. Status Function The Access Point is powered on System is operating. Wireless LAN is initializing. Blinking (Blue/Green) 2.4GHz/5GHz wireless LAN is working. -
Page 9: Inwall-U618Ax Port Description
Userguide for TOP-12AC, TOP-18AX, inWall-618AX inWall-U618AX Port description. Top Cover LAN1~4, WAN, SYS Reset Button Front Panel WAN /POE Port RJ-11 Connector Not in use. Back Panel LED/Reset Description. State Function Power On Power Off On/Flash WAN connected / data transmitting... - Page 10 Userguide for TOP-12AC, TOP-18AX, inWall-618AX Object Description PoE Port 10/100/1000Mbps RJ45 port, auto MDI/ MDI-X (802.3af/at PoE+) Connect PoE port to the IEEE 802.3af/at PoE+ switch to power on the device. 10/100/1000Mbps RJ-45 port, auto MDI/ MDI-X LAN 1-4 Port...
-
Page 11: Top-12Ac, Top-18Ax, Inwall-618Ax Hardware Installation
Userguide for TOP-12AC, TOP-18AX, inWall-618AX TOP-12AC, TOP-18AX, inWall-618AX Hardware installation. Connect the Access Point to a PoE Switch via the WAN/PoE port to power it on, then connect your computer via the LAN port to the either LAN port on the Access Point or to the LAN port of your PoE switch. The Access points can also be powered on by a PoE Injector when a PoE switch is not used. -
Page 12: Top-12Ac, Top-18Ax Installation
Userguide for TOP-12AC, TOP-18AX, inWall-618AX TOP-12AC, TOP-18AX Installation. For the Ceiling Wireless AP, they will be installed on the ceiling based on the following steps: Take the mounting bracket from the back of the Ceiling Access Point, put it on the target place by aligning the holes and fix it with the supplied screws. -
Page 13: Inwall-U618Ax Installation
Userguide for TOP-12AC, TOP-18AX, inWall-618AX InWall-U618AX Installation. When installing the inWall Access Point please make sure your PoE LAN cable is already at the power socket location into which the inWall Access Point will be placed. Follow the following steps: ①.Open wall socket cover... -
Page 14: Quick Installation Guide
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Chapter 3. Quick Installation Guide TOP-12AC, TOP-18AX , Web login Management. This chapter will show you how to configure the basic functions of your AP within minutes. Manual Network Setup – TCP/IP Configuration. The default IP address of the Access Point is 192.168.188.253, and the default subnet is 255.255.255.0. These values can be changed as you want. -
Page 15: Starting Setup In The Web Ui
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Starting Setup in the Web UI. It is easy to configure and manage the Access Point with a web browser. Input 192.168.188.253 into the browser, and the login page will appear, the default login password is: admin. -
Page 16: Configure The Access Point
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Chapter 4. Configure the Access Point Main Home Page. The below web GUI and the topology used in this guide uses the inWall-U618AX as an example. It is easy to configure and manage the AP with the web browser. The default setting of the Access Point is AP Mode. -
Page 17: Wizard Configuration
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Wizard Configuration. Wizard: It instruct users to configure wireless AP’s operation mode based on needs, there are two operation modes including AP and Gateway mode. Please confirm the operation mode first before starting the configuration. -
Page 18: Gateway Mode (Router) Wizard
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Gateway Mode (Router). Before changing the default AP mode to the Gateway mode, confirm your internet will be Static IP, PPPoE, or DHCP. Then click on the Gateway mode and the below image will pop-up. Please choose the right WAN settings mode, then click next to continue. -
Page 19: Wan Settings Static Ip Wizard
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.3.1 WAN Settings. Static IP If your ISP offers you a static IP Internet connection type, select “Static IP" and then enter IP address, subnet mask, default gateway and primary DNS information provided by your ISP in the corresponding fields. -
Page 20: Wan Settings Pppoe Wizard
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.3.2 WAN Settings. PPPoE (ADSL) Select PPPOE if your ISP is using a PPPoE connection and provided you wit an PPPoE username and password. The page includes the following fields: Object Description Usern ame Enter the PPPoE Username provided by your ISP... -
Page 21: Wan Settings Dhcp Wizard
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.3.3 WAN Settings. DHCP Choose “DHCP” and the router will automatically obtain IP addresses, subnet masks and gateway addresses from your ISP. 4.3.4 Wi-Fi Settings. In the Wi-Fi settings the settings for the 2.4Ghz are first after these are done click next to setup the 5Ghz Wi-Fi settings. - Page 22 Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Wi-Fi Statu s Select ON (Green) or OFF (Gray) to enable or disable Wireless LAN This is the wireless network name. The default SSID is Wireless SSID 2.4G_XXXXXX and Wireless 5.8G_XXXXXX.
- Page 23 Userguide for TOP-12AC, TOP-18AX, inWall-618AX Router Mode: After the Access Point has restarted the Gateway mode will be active. The web GUI will now display the Gateway Mode and will have an additional Firewall menu on the left side. See Chapter xx for information.
-
Page 24: Ap Mode Wizard
The default mode of the Access Point is AP mode. Select Static IP, Get IP from Gateway or Get IP from AC. When selecting the Get IP from AC you would need an AirLive WLAN-64/128GM Controller (sold separately). In the AP mode, the AP wireless interface and cable interface bridge together. -
Page 25: Wi-Fi Settings Wizard
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.4.1 Wi-Fi Settings. In the Wi-Fi settings the settings for the 2.4Ghz are first after these are done click next to setup the 5Ghz Wi-Fi settings. Setup your own SSID, Wireless Mode, Channel, Encryption and Wi-Fi Password. - Page 26 Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Wi-Fi Statu s Select ON (Green) or OFF (Gray) to enable or disable wireless LAN. This is the wireless network name. The default SSID is Wireless SSID 2.4G_XXXXXX and Wireless 5.8G_XXXXXX.
-
Page 27: Wi-Fi
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Wi-Fi In Wi-Fi setting you can setup the 2.4Ghz and 5Ghz setting, MAC ACL, Wi-Fi Timer and Advanced settings. Basic Wi-Fi settings for 2.4Ghz and 5Ghz. Setup your own SSID, Wireless Mode, Channel, Encryption and Wi-Fi Password, Max Station, TX Power and VLAN. -
Page 28: Vap
Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Wi-Fi Statu s Select ON (Green) or OFF (Gray) to enable or disable wireless LAN. This is the wireless network name. The default SSID is Wireless 2.4G_XXXXXX and Wireless 5.8G_XXXXXX. X is the last 6 numbers of the AP SSID MAC address. -
Page 29: Wi-Fi Analyzer
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.5.2 Wi-Fi Analyzer Press this button to analyze the local area to see which wireless channels are in use. Both the 2.4Ghz and the 5Ghz have their own Wi-Fi Analyzer. The straight vertical red line indicate the current channel used by the Access Point. -
Page 30: Mac Acl
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.5.3 MAC ACL Allow or deny the users access into this Access Point based on MAC address. The page includes the following fields: Object Description Press the “Add” button to add end-device that is scanned from wireless network and mark them. -
Page 31: Wi-Fi Timer
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.5.4 Wi-Fi Timer Enable Wi-Fi Timer to turn off the SSID on a specified time. The page includes the following fields: Object Description Wi-Fi Timer Select ON (Green) or OFF (Gray) to enable or disable timer. -
Page 32: Advanced
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.5.5 Advanced Advanced Settings allows to change the parameters of the Access Points. Country Region lets you select there different Wi-Fi regions, please select the one which is valid in your country of use. The page includes the following fields:... -
Page 33: Network (Ap Mode)
In AP mode only LAN Settings and Cloud are available. 4.6.1 LAN Settings Select the Connection, Static IP, Get IP from Gateway, Get IP from AC. To use the option, Get IP from AC an AirLive WLAN-64/128GM Wireless Controller is needed. The page includes the following fields:... -
Page 34: Cloud
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.6.2 Cloud By default, the Cloud setting is turned on. When this settings is turned on the Access Point can be added to the AirCloud platform. The AirCloud platform allows you to remote control the Access Points via the Cloud. -
Page 35: Static Dhcp
Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description IP Address Enter the Access Point Static IP Address. Su b n et Enter the network mask. Enable or Disable Spanning Tree (Default is on) DHCP Server... -
Page 36: Wan
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.7.3 WAN Settings allows you setup the Internet Mode of the Access Point, When using the WAN settings make sure your WAN port is connected to your Modem. The Access Points has 3 WAN settings, DHCP, Static IP and PPPoE. -
Page 37: Wan Advanced Settings
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.7.5 WAN Advanced Settings The WAN Advanced Settings are for 3 modes DHCP, Static IP and PPPoE. The page includes the following fields: Object Description Enable web server a c c e s s o n... -
Page 38: Wan Static Ip
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.7.6 WAN Static IP The default setting for the WAN port is DHCP. If your ISP offers you static IP Internet connection type, select “Static IP" and then enter IP address, subnet mask, default gateway and primary DNS information provided by your ISP in the corresponding fields. -
Page 39: Wan Pppoe
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.7.7 WAN PPPoE The default setting for the WAN port is DHCP. Select PPPOE if your ISP is using a PPPoE connection and provided you with a PPPoE username and password. For the Advanced Settings see Chapter 4.7.5... -
Page 40: Cloud
By default, the Cloud setting is turned on. When this settings is turned on the Access Point can be added to the AirCloud platform. The AirCloud platform allows you to remote control the Access Points via the Cloud. See www.airlive.com for more information about the AirCloud. -37-... -
Page 41: Firewall (Gateway Mode Only)
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Firewall (Gateway Mode Only) URL Filtering, IP Filter, MAC Filter, Port Mapping and DMZ will only appear when the Access Point is set to Gateway Mode. Setup for the IP Group and Time Group which can be used in some of the Firewall features can been done in the Management menu (see chapter 4.9.7 and 4.9.8). -
Page 42: Ip Filter
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.8.2 IP Filter IP Filtering can block or allow certain clients based on the IP Address, also a port or port range can be set for the IP Address together with the Protocol. Click Add to open the Pop-up window to enter the IP and Time information. To Delete an IP Filter, select the IP Filter which was made before and check mark it, then press Delete. - Page 43 Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Statu s Select ON (Green) or OFF (Gray) to enable or disable Rule Name Enter the rule name, e.g. Black list Time Group Select Any or Cu stomer to set up time range and work data.
-
Page 44: Mac Filter
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.8.3 MAC Filter MAC Filtering can block or allow certain clients based on the MAC Address, also a port or port range can be set for the IP Address together with the Protocol. Click Add to open the Pop-up window to enter the MAC and Time information. To Delete an MAC Filter, select the MAC Filter which was made before and check mark it, then press Delete. -
Page 45: Port Mapping
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.8.4 Port Mapping Port mapping allows extranet access to an intranet server. Enter the IP Address of the client for which you would like to open the External and Internal port. Click Add to open the Pop-up window to enter the Port information. To Delete a Port Mapping, select the Port Mapping which was made before and check mark it, then press Delete. - Page 46 Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Statu s Select ON (Green) or OFF (Gray) to enable or disable Rule Class Select the rule class, e.g. HTTP, HTTPS… Rule Name Enter the rule name, e.g. Black list...
-
Page 47: Dmz
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.8.5 Open the DMZ for a client IP Address. The page includes the following fields: Object Description Enable DMZ Select Enable DMZ Host or Disable DMZ Host IP Enter the DMZ LAN IP for which you would like to open DMZ Save Save the setting. -
Page 48: Manage
Userguide for TOP-12AC, TOP-18AX, inWall-618AX Manage The Management page allows for a backup, reset or upgrade of the Access Point. Note that there is a difference between AP Mode and Gateway Mode. The functions QoS, IP Group, Time Group and DDNS will only appear when the Access Point is in Gateway Mode. -
Page 49: Timed Reboot
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.2 Timed Reboot Set a schedule time on which the Access Point would reboot, this can be every day or on an interval The page includes the following fields: Object Description Timed Reboot Select Enable or Disable to start schedule reboot... -
Page 50: Upgrade
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.3 Upgrade Browse the firmware file and click on upgrade. Wait till the upgrade is successful. The device will reboot automatically after successful firmware upgrade. Version will show which firmware is currently on the Access Point. -
Page 51: Time Manager
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.4 Time Manager Setup the system time, enable NTP Server and select the Time Zone for the Access Point. The page includes the following fields: Object Description System Time Show system time of device NTP Enable... -
Page 52: Log
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.5 Review the Access Point log, you can also enable Remote Log Service or export the log file. The page includes the following fields: Object Description Select ON/OFF to record log or not Remote Log Service... -
Page 53: Qos (Gateway Mode Only)
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.6 QoS (Gateway Mode only) The QoS function only will work when the Access Point is in Gateway Mode. QoS can limited the bandwidth for an IP Address or IP Group also the Time Group can setup to limit the bandwidth only at a certain time. - Page 54 Userguide for TOP-12AC, TOP-18AX, inWall-618AX The page includes the following fields: Object Description Statu s Select enable or disable QoS control rule IP Group Select custom or Add an IP group IP Ad d ress Enter an IP address range or use scan to select...
-
Page 55: Ip Group (Gateway Mode Only)
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.7 IP Group (Gateway Mode only) IP Group, Setup up an IP Group which can be used in the QoS as well as in the Firewall menu. Click Add to open the Pop-up window to enter the IP information. To Delete an IP Group, select the IP Group which was made before and check mark it, then press Delete. -
Page 56: Time Group (Gateway Mode Only)
Userguide for TOP-12AC, TOP-18AX, inWall-618AX 4.9.8 Time Group (Gateway Mode only) Time Group, Setup up a Time Group which can be used in the QoS as well as in the Firewall menu. Click Add to open the Pop-up window to enter the IP information. To Delete a Time Group, select the Time Group which was made before and check mark it, then press Delete. -
Page 57: Ddns (Gateway Mode Only)
A DDNS can be setup using the build in DDNS. To make an DDNS account please click on Registration. Note: the DDNS service is not related to AirLive Technology Corp, but a third party. The page includes the following fields:... -
Page 58: Fit Mode
Userguide for TOP-12AC, TOP-18AX, inWall-618AX FIT Mode The main function of FIT Mode is to work with the AirLive Wireless Controller WLAN-64/128GM. When the Access Point is connected to the Wireless Controller, it will receive an IP Address from the Wireless Controller and the functions like SSID, Encryption and Channel are controlled via the Wireless Controller.
