Homelegance 1526RF-31 Assembly Instruction

PARTS LIST
(Coffee Table)
No. Sketch
1
Top Panel
2
Bottom Panel
3
Leg
PARTS LIST
(End Table)
No. Sketch
4
Top Panel
5
Bottom Panel
6
Leg
CAUTION:
(1) Do not fully-tighten the nuts or bolts initially until all the nuts and bolts are in place. (to avoid causing damages to the
thread, do not over tighten the nuts or bolts.)
(2) Keep all hardware parts out of resch of children.
MADE IN MALAYSIA
ASSEMBLY INSTRUCTION
ITEM NO : 1526RF-31 3PCS PACK OCC SET
( 1COFFEE , 2 END TABLE)
Thank you for purchasing this product. Please take time to read and
follow the instructions below. Check that you have all parts and
hardware before assembly. Parts apparently missing are often found
in the packing materials. If you do not have all parts listed, have your
dealer contact us and they will be sent to you immediately.
It is recommended to install protective pads under all legs and
supports to avoid damage or scratches when placing furniture on a
wood floor or other hard surface, and to limit indentation and prevent
discoloration if placing on carpet.
Description Qty.
1
1
4
Qty.
Description
1
1
4
No. Descriptions
Bolt Hex Com
A
Spring Washer
B
Flat Washer
C
Spanner
D
No. Descriptions
Bolt Hex Com
E
Spring Washer
F
Flat Washer
G
Spanner
H
* Above Hardware are packed in 1526RF-31 for Assembly.
HARDWARE LIST
(Coffee Table)
Size Sketch
5/16'' - 18 x 2 1/2"
(Blk)
5/16'' x 35/64'' x 0.07''
(Blk)
5/16'' x 5/8'' X 0.06''
(Blk)
13MM
HARDWARE LIST
(End Table)
Size Sketch
5/16'' - 18 x 2 1/2"
(Blk)
5/16'' x 35/64'' x 0.07''
(Blk)
5/16'' x 5/8'' X 0.06''
(Blk)
13MM
Qty.
12
12
12
1
Qty.
12
12
12
1
PAGE 1 OF 3
