- Page 1 Easee Equalizer Installer and User guide...
- Page 2 Introduction The information in this leaflet applies to Easee Equalizer P1 (E02-EQP) and Easee Equalizer HAN (E02-EQ), unless specified otherwise. Read the Important product information guide in the product packaging or at easee.com/manuals before using the product. Optimal performance The Equalizer makes it possible to charge smarter, safer and faster if the installation is scaled accordingly.
-
Page 3: Product Overview
Product overview Magnetic backside Touch button Equalizer Wall mounting kit Cable For non-metallic surfaces... -
Page 4: Technical Specifications
Weight 95 g (Equalizer P1) 110 g (Equalizer HAN) IP degree IP40 Supply 5-30 V DC 100 mA (Equalizer P1) 20-32 V DC 30 mA (Equalizer HAN) Cabling Cable length 1.5 m Custom made cable RJ12 to RJ12 (Equalizer P1) - Page 5 50 mW at 2.4–2.472 GHz. Connectivity Easee Link RF and WiFi HAN (NVE/AMS) (Equalizer HAN) or P1 (Equalizer P1) smart meter communication Modbus connection to energy meter Monitor power consumption with the Easee App RFID / NFC reader WiFi is required for normal operation and for future software updates. Installations with multiple master chargers need to be connected to the same WiFi for load balancing to work.
-
Page 6: Customer Setup
Setup In Scandinavia, the Scan the QR code to Add the Equalizer in the communication port on the download the Easee App app, follow the on-screen smart meter is most likely and create a free account. installation guide and get not activated. -
Page 7: Installer Setup
Installer App the provided cable. The and follow the on-screen Equalizer will appear in the installation guide to set Easee Portal after a while. it up. 12345 kWh easee.com/installer-app HAN / P1 Smart meter... - Page 8 10 flashes (100%) Use the Easee App to set up the WiFi. Contact your utility company to activate the HAN port. Go to http://easee.support. Check your internet connection. After booting, it can take a few minutes before Easee Link status flashes green.
- Page 9 The device is free from material defects and is in accordance with laws and regulations for consumer protection in the country where the product is purchased. All correctly installed Easee hardware is covered by our 3 years* limited warranty. *Some countries may have extended warranty.
- Page 10 The information in this document is for information purposes only, is provided as is, and may be subject to change without notice. Easee AS including its subsidiaries does not accept any liability for the correctness or completeness of the information and illustrations,...
