Iron logic Z-5R Relay Wiegand User Manual page 5

Z-5R Relay Wiegand
Table 2. Programming Modes.
Programming using Master keys
1. Add Normal and Blocking Cards
2. Add Master Cards
3. Erase Single, Normal and Blocking Cards
4. Erase All Memory
5. Set Door Release Time
6. Blocking Mode
7. Accept Mode
8. Storing Controller Memory to DS1996L Key
9. Loading information from DS1996L
Key into Controller Memory
Programming using Jumpers
1. Work with electromechanical lock
2. Erase All Memory
3. Add Normal Keys without Master Card
4. Work with electromagnetic lock
5. Trigger Mode
* The absence of a jumper is equivalent to the presence of a jumper in position 4.
Mode 1. Add Normal and Blocking Card (1M)
External reader is connected via iButton protocol.
Touch and hold (long touch) the reader with a Master key. On touch, the controller emits a short beep,
acknowledging the Master card recognition, and in 6 s, one more signal, denoting activation of Add
Normal and Blocking Cards mode. Take away the Master card now.
To add new cards, keep touching the reader with them, leaving no more than 16 s between touches.
Each new card touch is acknowledged by a short beep, which confirms storing the card number into
controller memory and sets the card status to Normal. If the card is still held at the reader for ~5 s
more, a long beep sounds and the card status becomes Blocking. If the card is already present in
controller memory, two short beeps will sound.
The Add Normal and Blocking Cards mode ends either automatically after 16 s after the last touch, or
with a Master card touch. The controller confirms the exit with a series of four short beeps.
External reader is connected via Wiegand protocol.
touch, the controller emits a short beep, acknowledging Master card recognition
beep "invitation" . During the "invitation" re-t
acknowledging that controller is now in Add Normal Card mode.
a Master card during the invitation beep, then the touch will be considered as short. Adding blocking
cards via Wiegand protocol is not possible.
touch of any card. The controller confirms the exit with a series of four short beeps.
Modes Activation
1M
1m, 1M
2M, 1M
3m, 1M
4m
1B
5m
1m, 1M
Initial power-up
scenario
Position 1
Position 2
Position 3
Position 4
Pos. 5 / Pos. 5 +
"Exit" closed to GND
Touch the reader with a Master card. On first
ouch the reader with a Master card
If you do not re-touch the reader with
The mode ends automatically after 15 s after the last
www.ironlogic.me
Legend
1...5 – # of touches
* Uppercase letter –
Long touch (hold
key for ~6 s)
* Lowercase letter –
Short touch (hold
key for <1s)
M – Master key
N – Normal key
B – Blocking key
Do NOT set the
jumper in any
position not
mentioned here: Risk
of damaging the
device!
and then emits long
: the beep will stop,
Page 5
