- Page 1 Application Note: User Guide for TLSR9_DEV_KEY AN-20200731-E1 Ver.0.1.0 2020/07/30 Keyword TLSR9_DEV_KEY, JATG Brief This document is the user guide for TLSR9_DEV_KEY.
- Page 2 All Right Reserved Legal Disclaimer This document is provided as-is. Telink Semiconductor reserves the right to make improvements without further notice to this document or any products herein. This document may contain technical inaccuracies or typographical errors. Telink Semiconductor disclaims any and all liability for any errors, inaccuracies or incompleteness contained herein.
-
Page 3: Revision History
User Guide for TLSR9_DEV_KEY Revision History Version 0.1.0 (2020-07-31) This is the Initial release. AN-20200731-E1 Ver.0.1.0... -
Page 4: Table Of Contents
User Guide for TLSR9_DEV_KEY Contents Revision History ................................. 2 Contents ................................... 3 List of Figures ................................4 Brief Introduction ............................... 5 Connection Guide .............................. 6 TLSR9_DEV_KEY ..................................6 UPPLY POWER FOR TLSR9_DEV_KEY ............................6 OWNLOAD FIRMWARE INTO Schematic ................................. 9 AN-20200731-E1 Ver.0.1.0... -
Page 5: List Of Figures
User Guide for TLSR9_DEV_KEY List of Figures Figure 1-1 TLSR9_DEV_KEY photo ........................5 Figure 2-1 Connection chart to supply power for TLSR9_DEV_KEY ................6 Figure 2-2 Connection chart 1 to download FW into DUT via TLSR9_DEV_KEY ............7 Figure 2-3 Connection chart 2 to download FW into DUT via TLSR9_DEV_KEY ............8 Figure 3-3-1 TLSR9_DEV_KEY schematic ...................... -
Page 6: Brief Introduction
User Guide for TLSR9_DEV_KEY 1. Brief Introduction This document presents guide on how to use TLSR9_DEV_KEY as an adapter to download firmware into target board (DUT). Figure 1-1 TLSR9_DEV_KEY photo Pin header Mini-USB interface TRSTn SRSTn AN-20200731-E1 Ver.0.1.0... -
Page 7: Connection Guide
User Guide for TLSR9_DEV_KEY 2. Connection Guide 2.1 Supply power for TLSR9_DEV_KEY Connect the mini-USB interface of the TLSR9_DEV_KEY with PC USB via a mini USB cable. Figure 2-1 Connection chart to supply power for TLSR9_DEV_KEY Mini-USB interface Connect to PC USB via USB cable 2.2 Download firmware into DUT via TLSR9_DEV_KEY The TLSR9_DEV_KEY is used as burning adapter and it is preloaded with the “aice_mini.hdr”. - Page 8 User Guide for TLSR9_DEV_KEY Figure 2-2 Connection chart 1 to download FW into DUT via TLSR9_DEV_KEY Pin header Mini-USB interface Connect to TDI of DUT Connect to TDO of Connect to GND of Connect to 5V of DUT Connect to 3V3 of DUT Connect to TCK of DUT Connect to TMS of Connect to PC USB via USB cable...
- Page 9 User Guide for TLSR9_DEV_KEY Figure 2-3 Connection chart 2 to download FW into DUT via TLSR9_DEV_KEY Pin header Mini-USB interface Connect to GND of Connect to 3V3 of DUT Connect to 5V of DUT Connect to TCK of DUT Connect to PC USB via USB cable Connect to TMS of AN-20200731-E1 Ver.0.1.0...
-
Page 10: Schematic
User Guide for TLSR9_DEV_KEY 3. Schematic Figure 3-3-1 TLSR9_DEV_KEY schematic AN-20200731-E1 Ver.0.1.0... - Page 11 User Guide for TLSR9_DEV_KEY AN-20200731-E1 Ver.0.1.0...
