Truper ESRE-1/4N Manual

Truper ESRE-1/4N Manual

Die grinder

Advertisement

Quick Links

Manual
Die grinder
Applies for:
Code
Model
16871
ESRE-1/4N
CAUTION
ESRE-1/4N
Read this manual thoroughly
before using the tool.
0.8 HP
Power

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESRE-1/4N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Truper ESRE-1/4N

  • Page 1 Manual Die grinder 0.8 HP Power Applies for: Code Model 16871 ESRE-1/4N ESRE-1/4N Read this manual thoroughly CAUTION before using the tool.
  • Page 2: Table Of Contents

    Manual before Parts using the tool. Preparation Keep this manual for future references. Start up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Notes Authorized service centers Warranty policy ESRE-1/4N ENGLISH...
  • Page 3: Technical Data

    Technical Data ESRE-1/4N Code 16871 Description Die grinder Collet 1/4” Maximum capacity ” of the accessory Voltage 127 V Frequency 60 Hz Current 4.7 A Power 0.8 HP Speed 11 300 RPM - 30 000 RPM Duty cycle 50 minutes work and 20 minutes idle.
  • Page 4: General Power Tool Safety Warnings

    General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references.
  • Page 5: Safety Warnings For Grinders

    Safety warnings for grinders Kickback While operating the grinder CAUTION CAUTION • Kickback is the reaction caused by a • Do not start the too while the rotating disc, pad or any other accessory that gets stuck or accessory is in contact with the work piece. WARNING pinched.
  • Page 6 Safety warnings for grinders While operating the grinder ENGLISH...
  • Page 7: Parts

    CAUTION • For best results USE STONES with 1/4" shank and diameters from ¾” to 1 3/8”. It is recommen- ded to use Truper mounted stones such as: JMP-10, JPM-7, JPM-5. General Purpose Mounted Stones and JPM-5X High Performance Stones.
  • Page 8: Start Up

    Start Up The grinder is a manual power tool. It is used to grind metal, bricks, tiles, stone and/or ceramic pieces, with no need to use water. It is used to remove burr from metal surfaces. To level and smooth down in welding. With a different accessory the tool can be used to remove oxide and polish metal surfaces and other materials.
  • Page 9: Maintenance

    Maintenance • Always disconnect the tool before cleaning. • Never use water or other liquids. Use only a brush. • To prevent the motor to overheat clean the ventilation slots regularly. • Check all the tool components are perfectly fixed. •...
  • Page 10: Notes

    Notes ENGLISH...
  • Page 11: Authorized Service Centers

    Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center.
  • Page 12: Warranty Policy

    ® require any proof of purchase to make the warranty effective. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
