2
easy
-MOB
A22800
MOB: AIS + DSC
Quick Instruction
English
Vers.: 1.0
Stand 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the easy2-MOB and is the answer not in the manual?

Questions and answers

Related Manuals for Weatherdock easy2-MOB

Summary of Contents for Weatherdock easy2-MOB

  • Page 1 easy -MOB A22800 MOB: AIS + DSC Quick Instruction English Vers.: 1.0 Stand 1.0...

  • Page 2: Table Of Contents

    PROGRAMMING OF MMSI NUMBERS FOR DSC DISTRESS CALL USING APP ....... 20 INSERTION IN LIFE JACKET ......... 21 TECHNICAL DATA ..........22 DECLARATION OF CONFORMITY ....... 24 RESTRICTIONS ............. 25 NOTIZEN ..............26 Revisions A22800, Stand 1.0, MK – 02/2023 Weatherdock AG Seite 2 www.easyAIS.com...
  • Page 3 Index of Abbreviations Weatherdock AG Seite 3 www.easyAIS.com...

  • Page 4: Safety Intructions

    Keep the device away from heat or hot environments. The batteries inside the easy2- MOB could overheat, possibly even explode or burn and cause damage to the device and the environment! Weatherdock AG Seite 4 www.easyAIS.com...

  • Page 5: Product Overview

    10. Magnet slider 3. Antenna flap 11. Lanyard, 1 m 4. Water-soluble 12. Button „TEST“ cellulose tablet 13. Program-LED 5. Antenna 14. Status-LED 6. Antenna head 15. Emergency light LED 7. GPS antenna 8. Button „ON“ Weatherdock AG Seite 5 www.easyAIS.com...

  • Page 6: Controls

    AIS-DSC-MOB device. This is done by the magnetic slide (10) integrated in the alarm flap. • "Disarmed" means that the auto- matic is switched off • "Armed" means that the automatic is activated Weatherdock AG Seite 6 www.easyAIS.com...

  • Page 7: Button "On

    AIS receiver. The additional text message "MOB TEST" informs each recipient of this test signal that it is a function test, i.e. not an emergency. Weatherdock AG Seite 7 www.easyAIS.com...

  • Page 8: Antenna

    The device acti- vates automatically when it comes into contact with water, without you having to intervene (the magnetic slider (10) must be set to "armed"). Weatherdock AG Seite 8 www.easyAIS.com...

  • Page 9: Operation

    Operation The AIS MOB easy2-MOB can float without additional aids. In heavy seas, the easy2-MOB may need a long time to determine a GPS/GNSS position while swimming. For best AIS transmission performance and GPS/GNSS reception accuracy, hold the beacon in your hand as high out of the water as pos- sible.

  • Page 10: Test Function (Mob Test)

    TEST function (MOB TEST) Test the easy2-MOB for the send function at regular intervals. A six-monthly test is usually sufficient. Testing too often will reduce battery capacity. The battery is designed for 5 years and up to 30 test activations (see also table "Technical Data",Chapter 7).
  • Page 11 "Mothership" MMSI in the list. (See Chapter 5, Programming) "DSC Acknowledgment" is Status LED (14) changes from received yellow to green (After confirming the message on the radio.) Table 2: Test mode flashing/lighting pattern Weatherdock AG Seite 11 www.easyAIS.com...
  • Page 12 Table 3: Flashing/Lighting Pattern Test Result The current battery status of the easy2-MOB can also be queried via Bluetooth using the app. However, please limit the number of Bluetooth connections to what is absolutely necessary (e.g. monthly, i.e. a total of approx.

  • Page 13: Alarm

    ALARM 4.2.1 Automatic activation The AIS MOB easy2-MOB is intended for use in an automatic life jacket (see Chapter 6). The vest opens and inflates when it comes into contact with water if you fall into the water. This puts the transmitter in the water and releases the an- tenna.
  • Page 14 Status LED (14) continues to acknowledgment from a DSC flash yellow radio or coast station "DSC Acknowledgment" is Status LED (14) changes from received - everything is OK yellow to green Table 4: Flashing/lighting patterns for alarm triggering Weatherdock AG Seite 14 www.easyAIS.com...

  • Page 15: Manual Activation

    The transmitter can then only be activated manually. 4.2.3 Functionality When the easy2-MOB is triggered, the transmission of AIS emergency telegrams always starts by default as soon as a position fix is available. These include: •...
  • Page 16 Navigation status 14 (activated distress beacon) According to the current standard, the position report of the easy2-MOB should appear as a circle symbol with an "X" on the electronic display/map (a system update may be necessary via the manufacturer of the display device):...
  • Page 17 ID of the transmitter, but no GPS/GNSS position data. As soon as the easy2-MOB has received a position fix and the coordinates have been determined, another DSC emergency call is made parallel to the AIS transmission. But this time with the current GPS/GNSS position data.
  • Page 18 10 minutes each time. This interval is maintained until the end of the emergency situa- tion. As soon as the easy2-MOB in the DSC open loop receives con- firmation that it has received the emergency signal, the DSC functionality is switched off.

  • Page 19: Deactivation (Switching Off The Device)

    Press the "ON" button (8) for at least 3 seconds until all LEDs (13, 14, 15) flash together briefly. Deactivate TEST mode: Press the "TEST" button (7) for at least 3 seconds until all LEDs (13, 14, 15) flash together briefly. Weatherdock AG Seite 19 www.easyAIS.com...

  • Page 20: Programming Of Mmsi Numbers For Dsc Distress Call Using App

    Up to 8 different ship MMSI numbers can be programmed via Bluetooth connection between a smartphone/tablet and the easy2-MOB. The app required for this is available for down- load free of charge for Apple and Android devices (from iOS11 / Android6).

  • Page 21: Insertion In Life Jacket

    Insertion in life jacket The easy2-MOB is intended for use in an automatic life jacket. The AIS rescue beacon is inserted into the folded side of the swim bladder without the release mechanism of the auto- matic life jacket. To do this, the zipper/Velcro fastener at the lower end of the vest is first opened.

  • Page 22: Technical Data

    Controls 2 buttons (“TEST” and “ON”) Msg.1: AIS position report is sent Supported AIS messages in • 6-8 times per minute transmission mode • Unit ID: 9-digit identifica- tion number • Speed Over Ground (SOG) Weatherdock AG Seite 22 www.easyAIS.com...
  • Page 23 In TEST mode: in DSC mode TEST CALL • In ALARM mode: DISTRESS RELAY Operating temperatur -10°C up to +55°C Storage temperature -30°C up to +70°C MMSI/Unit-ID: 972XXXXXX Identification as MOB ACTIVE/TEST Table 5: Technical data Weatherdock AG Seite 23 www.easyAIS.com...

  • Page 24: Declaration Of Conformity

    Declaration of Conformity Weatherdock AG hereby declares that the radio system type easy2-MOB complies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.easyais.com/en/declaration-of-confor- mity/easy2-mob/ For more information, please refer to the full AIS MOB A22800 easy2-MOB instruction manual: https://www.easyais.com/en/downloads/manual-hardware/...

  • Page 25: Restrictions

    Restrictions There are no known restrictions for the usage of the easy2- MOB2-MOB in EU countries. Weatherdock AG Seite 25 www.easyAIS.com...

  • Page 26: 10 Notizen

    10 Notizen Weatherdock AG Seite 26 www.easyAIS.com...
  • Page 27 Weatherdock AG Seite 27 www.easyAIS.com...
  • Page 28 Weatherdock AG Emmericher Strasse 17 D – 90411 Nürnberg Tel.: +49 (0) 911 – 37663830 Table 5: Technical data Fax: +49 (0) 911 – 37663840 www.easyais.com info@weatherdock.de...
