Summary of Contents for Weatherdock easy2-MOB
- Page 1 easy -MOB A22800 MOB: AIS + DSC User Guide English Vers.: 1.0 Stand 1.0...
-
Page 2: Table Of Contents
ALARM ..............16 6.2.1 Automatic activation .......... 16 6.2.2 Manual activation ..........18 6.2.3 Functionality ............18 Deactivation (switching off the device) .... 22 PROGRAMMING OF MMSI NUMBERS FOR DSC DISTRESS CALL USING APP ........ 23 Weatherdock AG Page 2 www.easyAIS.com... - Page 3 RESCUE DATABASE AND LOGIN ......43 LICENSE AGREEMENT ........45 WARRANTY ............46 TECHNICAL DATA ..........48 DECLARATION OF CONFORMITY ....... 51 NOTES ..............52 Revisions A22800, Stand 1.0, MK – 02/2023 A22800, Stand 1.1. JZ – 04/2024 Weatherdock AG Page 3 www.easyAIS.com...
- Page 4 Index of Abbreviations Weatherdock AG Page 4 www.easyAIS.com...
-
Page 5: Safety Intructions
Keep the device away from heat or hot environments. The batteries inside the easy2- MOB could overheat, possibly even explode or burn and cause damage to the device and the environment! Weatherdock AG Page 5 www.easyAIS.com... -
Page 6: Restrictions
(A22800) has an auto- matic release by water contact. The device can float without additional aids. The AIS/DSC distress beacon easy2-MOB is used in an emer- gency situation for direct notification via: •... - Page 7 The device is compatible with the AIS system (Automatic Identification System) used worldwide. The device is compatible with the worldwide used DSC radio procedure (Digital Selective Call). The device is compatible with Android and iOS smart devices. Weatherdock AG Page 7 www.easyAIS.com...
-
Page 8: Product Overview
10. Magnet slider 3. Antenna flap 11. Lanyard, 1 m 4. Water-soluble 12. Button „TEST“ cellulose tablet 13. Program-LED 5. Antenna 14. Status-LED 6. Antenna head 15. Emergency light LED 7. GPS antenna 8. Button „ON“ Weatherdock AG Page 8 www.easyAIS.com... -
Page 9: Controls
(10) integrated in the alarm flap. • "Disarmed" means that the auto- matic release is switched off, and a test is not possible either • "Armed" means that the automatic release is activated, a test is also pos- sible Weatherdock AG Page 9 www.easyAIS.com... -
Page 10: Button "On
AIS receiver. The additional text message "MOB TEST" informs each recipient of this test signal that it is a function test, i.e. not an emergency. Weatherdock AG Page 10 www.easyAIS.com... -
Page 11: Antenna
The device acti- vates automatically when it comes into contact with water, without you having to intervene (the magnetic slider (10) must be set to "armed"). Weatherdock AG Page 11 www.easyAIS.com... -
Page 12: Operation
Operation The AIS MOB easy2-MOB can float without additional aids. In heavy seas, the easy2-MOB may need a long time to determine a GPS/GNSS position while swimming. For best AIS transmission performance and GPS/GNSS reception accuracy, hold the beacon in your hand as high out of the water as pos- sible. -
Page 13: Test Function (Mob Test)
TEST function (MOB TEST) Test the easy2-MOB for transmission function at regular in- tervals. The easy2-MOB has a so-called ‘shelf life’ of 7 years. This means that with a maximum of 30 test cycles, the battery still has sufficient capacity in the 7th year (in accordance with the standard). - Page 14 (10 seconds) if programmed at least 1 MMSI is programmed (duration: 10 seconds) GPS fix/GNSS fix available Yellow status LED (14) flashes slowly (2 every second). Device sends 8 x AIS test transmission (duration: approx. 14 seconds) Weatherdock AG Page 14 www.easyAIS.com...
- Page 15 Only GPS fix/GNSS fix is OK Status LED (14) turns solid amber at the end of the test Only DSC-Acknowledge is OK Status LED (14) quickly flashes green (5Hz) Nothing is OK Status LED (14) quickly flashes yellow (5Hz) Weatherdock AG Page 15 www.easyAIS.com...
-
Page 16: Alarm
Table 3: Flashing/Lighting Pattern Test Result The current battery status of the easy2-MOB can also be que- ried via Bluetooth using the app. However, please limit the number of Bluetooth connections to what is absolutely necessary (e.g. monthly, i.e. a total of approx. - Page 17 Status LED (14) continues to acknowledgment from a DSC flash yellow radio or coast station "DSC Acknowledgment" is Status LED (14) changes from received - everything is OK yellow to green Table 4: Flashing/lighting patterns for alarm triggering Weatherdock AG Page 17 www.easyAIS.com...
-
Page 18: Manual Activation
The transmitter can then only be activated manually. 6.2.3 Functionality When the easy2-MOB is triggered, the transmission of AIS emergency telegrams always starts by default as soon as a position fix is available. These include: •... - Page 19 Navigation status 14 (activated distress beacon) According to the current standard, the position report of the easy2-MOB should appear as a circle symbol with an "X" on the electronic display/map (a system update may be necessary via the manufacturer of the display device):...
- Page 20 ID of the transmitter, but no GPS/GNSS position data. As soon as the easy2-MOB has received a position fix and the coordinates have been determined, another DSC emergency call is made parallel to the AIS transmission. But this time with the current GPS/GNSS position data.
- Page 21 10 minutes each time. This interval is maintained until the end of the emergency situa- tion. As soon as the easy2-MOB in the DSC open loop receives con- firmation that it has received the emergency signal, the DSC functionality is switched off.
-
Page 22: Deactivation (Switching Off The Device)
Press the "ON" button (8) for at least 3 seconds until all LEDs (13, 14, 15) flash together briefly. Deactivate TEST mode: Press the "TEST" button (7) for at least 3 seconds until all LEDs (13, 14, 15) flash together briefly. Weatherdock AG Page 22 www.easyAIS.com... -
Page 23: Programming Of Mmsi Numbers For Dsc Distress Call Using App
Up to 8 different ship MMSI numbers can be programmed via Bluetooth connection between a smartphone/tablet and the easy2-MOB. The app required for this is available for down- load free of charge for Apple and Android devices (from iOS11/Android6). - Page 24 ARMED position. Otherwise all buttons are deactivated. Press the "TEST" button for >3 seconds until the white LED lights up. After 4 seconds, the white LED starts flashing. → Bluetooth is ready Weatherdock AG Page 24 www.easyAIS.com...
- Page 25 Open the easy2-MOB app and you will get to this start screen. If you have switched your easy2-MOB to Bluetooth mode, please press Con- nect to establish a con- nection between smartphone and the AIS rescue beacon. Weatherdock AG Page 25...
- Page 26 The connection is estab- lished. After a successful connec- tion, you will see addi- tional information about the device on the start screen. Weatherdock AG Page 26 www.easyAIS.com...
- Page 27 grammed (no number entered upon delivery) You will see an over- view of the device ac- tivations that have al- ready taken place (no number entered upon delivery) Weatherdock AG Page 27 www.easyAIS.com...
- Page 28 In addition, there is infor- mation when the battery has reached its expiration date and needs to be changed. Weatherdock AG Page 28 www.easyAIS.com...
- Page 29 Here you can see the re- sult of a self-test that was carried out. You can see when and where this test was car- ried out and you can see the test results and infor- mation about the device itself. Weatherdock AG Page 29 www.easyAIS.com...
- Page 30 Here you can enter the MMSI number of your DSC radio. In addition, up to a total of 8 different MMSI num- bers can be programmed. Weatherdock AG Page 30 www.easyAIS.com...
- Page 31 DANGER: The first "mothership" in the list is also used for the test. NOTICE: Reduce the number of "motherships" as much as possible to extend the runtime of the device. Weatherdock AG Page 31 www.easyAIS.com...
- Page 32 If you tap on a displayed date under ACTIVA- TIONS on the start screen, you will get this display. You will see the activa- tion deactivation date/time and a map will show you where this took place. Weatherdock AG Page 32 www.easyAIS.com...
- Page 33 Too many active Bluetooth devices in the vicinity, e.g. Smart- watches, fitness trackers etc. can cause problems when estab- lishing the Bluetooth connection with the easy2-MOB. It of- ten helps here to repeat the connection attempt (press "Con- nect" again as instructed by the app).
-
Page 34: Insertion In Life Jacket
Insertion in life jacket The easy2-MOB is intended for use in an automatic life jacket. The AIS rescue beacon is inserted into the folded side of the swim bladder without the release mechanism of the auto- matic life jacket. To do this, the zipper/Velcro fastener at the lower end of the vest is first opened. -
Page 35: Maintenance And Service
Maintenance and Service Basic Antenna Position If the antenna mechanism of your easy2-MOB should have been triggered unintentionally or you notice in the process of time that the water soluble pill starts breaking apart, you have the possibility to return your easy2-MOB to original state. - Page 36 Hold the Allen key with the thumb (Warning: Spring effect oft he screwed antenna!) Insert the water soluble pill into the antenna flap. Close the antenna flap and fix it with the alert flap. Ready. Your easy2-MOB is fully functional again. Weatherdock AG Page 36 www.easyAIS.com...
- Page 37 4./5 Weatherdock AG Page 37 www.easyAIS.com...
- Page 38 The overhaul of the trigger mechanism by a non-certified distributor or reseller is at your own risk! Only original spare pills are suited for replacement. Please also note our video tutorials and the reference information on our website (www.easyais.com) Weatherdock AG Page 38 www.easyAIS.com...
-
Page 39: Maintenance/Service
Although Weatherdock AG always endeavors to process all publications with the greatest possible accuracy, these in- structions may contain errors or ambiguities. In addition, changes to these instructions are the sole responsibility of Weatherdock and can be carried out without prior notice. Weatherdock AG Page 39 www.easyAIS.com... -
Page 40: Disposal
Telefax: +49 (0)911-376638-40 E-Mail: info@weatherdock.de Internet: www.easyais.com Disposal The AIS MOB easy2-MOB uses lithium batteries. These shall not be given to normal household waste and must be taken to the collection of recy- clables. If you want to dispose of the device, you can do this at a re- cycling center in your area, at an appropriate dealer or through us. -
Page 41: Troubleshooting
ON button ter contacts. easy2-MOB does Hold the easy2-MOB (in your not find a GPS/GNSS po- hand) as far out of the water as sition (GPS status LED possible. This also increases does not flash) - Page 42 The easy2-MOB has be- Carefully try to free the easy2- come stuck in the life MOB without damaging the jacket or between the swim bladder. life jacket and the body. Please send the device to us for service immediately your TEST mode cannot be dealer.
-
Page 43: Rescue Database And Login
11 RESCUE Database and Login To increase functionality of AIS based personal locating bea- cons more safe and more effective, Weatherdock AG is providing a web-based database where customers can give additional relevant information. For more information about that service please look on our website: www.easyais.com... - Page 44 Register with your email address and set a password. You can manage several rescue transmitters in your account. On the type label of each easy2-MOB there is a unique device iden- tification number (Unit-ID) with which you can register your rescue transmitter in the RESCUE database.
-
Page 45: License Agreement
12 License agreement By using the easy2-MOB you agree to the conditions of the following warranty agreements. Please read this agreement carefully. Weatherdock AG grants you a limited license to use the de- vice in the normal operation of the product. Title, ownership rights and intellectual property rights in and to the software remain with Weatherdock AG. -
Page 46: Warranty
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty gives you specific legal rights which vary from country to country. In no event shall Weatherdock AG be liable for any incidental, special, indirect, or consequential damages arising out of the use, possible inability to use, or any defect in the product. - Page 47 When making warranty repairs, always include a copy of the original sales receipt as proof of ownership. The easy2-MOB contains no user-serviceable parts. If you have a problem with your device, contact your dealer. Any attempt to open, change or modify the device will void the warranty and may irreparably damage the device.
-
Page 48: Technical Data
IEC 61108-1 Fold out VHF antenna Rolled up inactive in the device 9 LEDs (1 x GPS status, 2 x FLASH, Display 6 x emergency light) Controls 2 buttons (“TEST” and “ON”) Weatherdock AG Page 48 www.easyAIS.com... - Page 49 • GPS Position (Lat./Long.) Sent Information • In TEST mode: in DSC mode TEST CALL • In ALARM mode: DISTRESS RELAY Operating temperatur -10°C up to +55°C Storage temperature -30°C up to +70°C Weatherdock AG Page 49 www.easyAIS.com...
- Page 50 Product standards IEC63269, RTCM 11901.1 MMSI/Unit-ID: 972XXXXXX Identification as MOB ACTIVE/TEST Table 6: Technical data Weatherdock AG Page 50 www.easyAIS.com...
-
Page 51: Declaration Of Conformity
15 Declaration of Conformity Weatherdock AG hereby declares that the radio system type easy2-MOB complies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.easyais.com/en/declaration-of-conform- ity/easy2-mob/ You can find helpful videos on our YouTube channel: https://www.youtube.com/@EasyaisDe/playlists... -
Page 52: Notes
16 Notes Weatherdock AG Page 52 www.easyAIS.com... - Page 53 Weatherdock AG Emmericher Strasse 17 D – 90411 Nürnberg Tel.: +49 (0) 911 – 37663830 Fax: +49 (0) 911 – 37663840 www.easyais.com info@weatherdock.de Weatherdock AG Page 53 www.easyAIS.com...
