CS2000 Automatic control V2
Quick Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Flexit CS2000

Summary of Contents for Flexit CS2000

  • Page 1 112626E-02 2012-09 CS2000 Automatic control V2 Quick Guide...

  • Page 2: Table Of Contents

    Content This quick guide only applies to software version V2.x To view current software version: Start page > Main menu > System Overview > Versions > Flexit.ahu = V2.x 1. HMI ..................................................................2. Settings ..............................................................2.1. Introduction ............................................................. 2.2. Select language ........................................................

  • Page 3: Hmi

    1. HMI A central element in the system is the HMI (control panel), where you can adjust settings and take readings. The control panel consists of an 8-line graphic display, indicator lamps and controls for the settings. Here is a short introduction to the control panel showing how to enter the initial settings in the system.

  • Page 4: Adjust Setpoints

    • Rights to all menus except I/O configuration and system settings. Level 4: OEM, password given only in consultation with the Flexit service organisation. • All rights as for level 3, plus: Activate the function on the menu selection: •...

  • Page 5: Set The Calendar And Timing Program

    6. Set the calendar and timing program 6.1. General This section describes functions and settings for the timing program and calendars. When no object with higher priority (for example Manual operation <> Auto) is activated, the system can be disconnected or the stages altered from the timing program. A maximum of six switch-over times can be specified per week.

  • Page 6: Calendar (Exceptions And Stop)

    6.4. Calendar (exceptions and stop) EXAMPLE: Val-x = Date Exception days can be defined in the calendar. These can Only the time for (start) is relevant. include specific days, periods or weekdays. Exception days override the weekly schedule. • -(Start)Date = *,01.01.09 Calendar exceptions Result: 1 January 2009 is an exception date.

  • Page 7: Alarm Handling

    7. Alarm handling If an alarm has been triggered, it will be shown by the flashing alarm symbol. You can get more information by pressing the alarm button. To reset the alarm, press the alarm button twice and select Confirm/Reset and then Execute in the menu.
  • Page 8 Flexit AS, Televeien 15, N-1870 Ørje www.flexit.no...
