- Page 1 115029EN-03 2025-04 Pressure regulator P1000 Installation instructions 114730...
-
Page 2: Table Of Contents
Contents 1. Important information ..................................1.1. Rules and regulations ................................1.2. Guarantee and liability ................................ 2. General safety instructions ................................2.1. Intended use ....................................2.2. Improper use ..................................................................2.4. Safety instructions in this manual ......................... 2.5. Adhere to the following instructions ........................ -
Page 3: Important Information
Read these instructions completely and 2.1. Intended use thoroughly before working with the product. ruck CON P1000 has been designed and developed • Keep these instructions in a location where to comply with the requirements of the EU Low they are accessible to all users at all times. -
Page 4: Safety Instructions In This Manual
2.4. Safety instructions in this 2.5.2. During installation manual • Disconnect all of the product‘s poles from the mains before installing the product or In this manual, there are safety instructions before connecting or removing plugs. Make sure that the steps whenever there is a danger of personal the product cannot be switched back on again. -
Page 5: Delivery Contents
Transport and storage Included in delivery depending on model type: Transport and storage should only be performed • 1 x CON P1000 Constant pressure control by specialist personnel in accordance with the • 1 x installation and operating manual installation and operating manual and regulations in force. - Page 6 Electrical installation may only be performed • The electrical connections must be made as shown in the corresponding wiring diagrams and installation terminal diagrams. and operating manual and the national regulations, • The type of cable, size of cable and method of standards and guidelines in force: laying should be determined by an authorized •...
-
Page 7: Modbus Communication
Only potential-free contacts may be connected at terminals X3 and X4, and X5 and X6. Applying an external voltage can seriously damage the regulator. The regulations for safety extra-low voltages must be observed. The maximum pressure in a ventilation plant must not exceed 5000 Pa. -
Page 8: Modbus Register
8.1. Modbus register 8.1.1. Implemented functions Function code Name Description 03 HEX Read Hold Register Read device parameter 04 HEX Read Input Register Read current value 06 HEX Write Single Register Write device parameter word by word 10 HEX Write Multiple Register Write several device parameters word by word Function code Name... -
Page 9: Current Value Table, Protocol Addresses 24 (Error Numbers)
Register Protocol Parameter name Value range Data Authority address address type 30001 Reserved integer 30002 Room temperature integer 30003 Measured pressure Pressure (PA) integer 30004 Set day internal switch Pressure (PA) integer 30005 Set night internal switch Pressure (PA) integer 30006 Reserved integer... -
Page 10: Commissioning
Bridging terminals X5 and X6 switches the constant Before performing any work on pressure regulator CON P1000 on, and removing the conductive parts, always disconnect the unit completely from the electricity supply and make sure that it cannot be switched Changing day-time set-point Adjust set-point Day with the decade switches (8). -
Page 11: Adjustment Of The Control Unit Parameter
Switches to the control unit Mode Button Control cable parameter menu. Display ON/OFF Button Button for switching the unit on or off or switching to menu management. when regulator on Button A Buttons for increasing and decreasing when regulator off the set-point for “DAY”... -
Page 12: Menu Functions
10.2.2. Menu functions See Fig. 3 on page 10. Status ON / OFF Press the ON/OFF button (1) to switch the unit on The unit‘s status now appears on the display with the current values DAY – Changing the setting Use the A buttons on the control unit to increase ( ) or reduce ( ) the set-point. -
Page 13: Parameter Settings Menu
10.2.3. Parameter settings Menu You move to the parameter settings menu menu P 10 sec by pressing the ON/OFF button , which must be held down for approx. 10 seconds. Parameter P01 is displayed on the screen. With the A P01 MIN-VALUE ) buttons on the control unit, the individual P parameters can be called up. -
Page 14: Maintenance And Repair
11. Maintenance and repair tion 11.1. Important notes • Electricity warning (hazardous voltage)! delivered. Failure to observe the hazard may result in The warranty will cease to apply after any death, injury or damage to property. Before performing any work on 13. -
Page 15: Troubleshooting
14. Troubleshooting Please note the following instructions: • Proceed systematically and purposefully when troubleshooting, even when under the pressure of time. In the worst case, randomly and indiscriminately dismantling and changing settings may result in it no longer being possible to determine the original cause of the fault. -
Page 16: Technical Data
15. Technical data Technical data: Pressure regulation 10-990 Pa range: Supply voltage: 230 V AC 50/60 Hz 2 x potential-free Digital inputs: (on/off, day/night switching) 2 (enable frequency converter, Relay outputs: set-point reached) 24 V-1 A Analog output: 0-10V DC Degree of protection: IP55 1 x RS485 for control unit... -
Page 17: Wiring Diagrams
16. Wiring diagrams 126060... - Page 18 The right to give notice of lack of conformity applies to this product in accordance with the existing terms of sale, provided that the product is correctly used and maintained. Filters are consumables. The symbol on the product shows that this product must not be treated as household waste.
- Page 19 Electromagnetic Compatibility (EMC) Directive 2004/108/EC Flexit hereby declares that the product designated below in its conception and design, and in the version marketed by us complies with the requirements of the named EC directives. In the event of any changes to the product not approved by us, this declaration loses its validity.
- Page 20 Flexit AS, Moseveien 8, N-1870 Ørje www.flexit.no...
