Summary of Contents for Flexit CS2000
- Page 1 112626E-03 2017-09 CS2000 Automatic control V3 Quick Guide...
- Page 2 All electrical connections must be made by an expert.
- Page 3 Contents This quick guide only applies to software version V3.x To view current software version: Start page > Main menu > System Overview > Versions > Flexit.ahu = V3.x Getting started 1.1. HMI .................................. 1.2. Settings ................................. 1.2.1. Introduction ............................... 4 1.2.2.
- Page 4 1. Getting started 1.1. HMI A central element in the system is the HMI (control panel), where you can adjust settings and take readings. The control panel consists of an 8-line graphic display, indicator lamps and controls for the settings. Here is a short introduction to the control panel showing how to enter the initial settings in the system.
- Page 5 Shows current command when the Level 4: OEM, password given only in consultation with the current day is Monday. The latest Flexit service organisation. time that can be entered for a day • All rights as for level 3, plus: is 23:59.
- Page 6 1.2.4.4. Kalender (undantag och stopp) EXAMPLE: Val-x = Date Exception days can be defined in the calendar. These can Only the time for (start) is relevant. include specific days, periods or weekdays. Exception days override the weekly schedule. • -(Start)Date = *,01.01.16 Calendar exceptions Result: 1 January 2016 is an exception date.
- Page 7 To adjust supply air temperature limits with extract air regulation. 1.3. Adjust the setpoints for speeds and temperatures Start page > Quick menu > Setpoints/Settings Start page > Quick menu > Setpoints/Settings Parameter Function Parameter Function Setpoint, min. supply Indicates the lowest permitted supply air temp.
- Page 8 Flexit AS, Televeien 15, N-1870 Ørje www.flexit.no...
