- Page 1 INSTRUCTION GUIDE VENTUS 3 MONITOR...
- Page 2 The contents of this manual are subject to change without notice to improve quality. © 2023 JLL Fitness Ltd JLL Fitness Ltd owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of JLL Fitness Ltd is prohibited.
-
Page 3: Table Of Contents
CONTENTS - Safety precautions p. 4 - Cleaning p. 5 - Installation p. 6 - Operation p. 7 Manual mode - program 1 p. 7 Program mode - programs 2-12 p. 8 Body fat - program 13 p. 8 Watts - program 14 p. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS The monitor on this machine has been tested to the required standards, each of those passed regulations are shown via the following symbols: WEEE - Waste Electrical and Electronic Equipment Recycling. CE - The product conforms with relevant EU directives regarding health and safety or environmental protection. ROHS - This is an abbreviation for “Restriction of (the use of certain) Hazardous Substances in electrical and electronic Equipment”. - Page 5 CLEANING Please take care when cleaning this monitor as the LCD screen can easily be scratched. You will need a soft dry cloth Do not spray cleaning chemicals directly onto the monitor Do not apply water to the monitor as it is electrical and may damage the internal components...
-
Page 6: Installation
INSTALLATION STEP 1 STEP 2 Remove the four screws already in the back of Connect the male to female wire from the the monitor. frame arm to the monitor. STEP 3 Secure the monitor to the frame arm using the four screws removed previously. -
Page 7: Operation
OPERATION The Ventus 3 monitor has a total of 9 readouts, displaying: Time Time 500m Distance Strokes Strokes Per Minute Pulse Total Strokes Watts Calories Plug in the power supply and the monitor will display every segment on the screen for 2 seconds. -
Page 8: Program Mode - Programs
PROGRAM MODE - PROGRAMS 2-12 • Press the “UP” key to scan through the selection of programs between 2-12. At the bottom of the screen the chart will show the pattern and intensity of each. • Press the “START/STOP” key to begin a program. •... -
Page 9: Watts - Program 14
BODY FAT Gender Medium Slightly High High Male <13% 13% - 25.9% 26% - 30% >30% Female <23% 23% - 35.9% 36% - 40% >40% BODY TYPE Skinny Thin Slightly Slim Healthy Slightly Overweight Overweight Obese Obesity Thin WATTS - PROGRAM 14 •... -
Page 10: Heart Rate Mode - Programs
HEART RATE MODE - PROGRAMS 15-18 • Press the “UP” key to scan through the programs till TRAINING ZONE you reach between 15-18. MIN - MAX (BPM) • Press the “ENTER” key to choose setting items with 133 - 167 the relevant flashing windows for TIME, DISTANCE, 132 - 166 CALORIE, STROKES and AGE. -
Page 11: User Mode - Programs
USER MODE - PROGRAMS 19-22 • Press the “UP” key to scan through the programs till you reach between 19-22. You will be able to select from user 1-4. • Press the “ENTER” key to choose setting items with the relevant flashing windows for TIME, DISTANCE, CALORIE, STROKES, AGE and RESISTANCE LEVEL. -
Page 12: Bluetooth/Kinomap App
BLUETOOTH/KINOMAP APP This monitor is equipped with Bluetooth which is designed to connect to the Kinomap app. The app can be downloaded from the App Store or from Google Play. Once connected the monitor will power off and all readings will be displayed within the app. -
Page 13: Data Readouts
DATA READOUTS Readout Measurement Time Minutes : Seconds Time 500m Minutes : Seconds Distance Kilometres Pulse BPM (Beats Per Minute) Strokes Per Minute... -
Page 14: Troubleshoot
TROUBLESHOOT Issue Resolutions No power to the monitor • Make sure the power cable is fully inserted into the back of the machine and the plug is pushed fully into the socket. • Check your connection wires from the monitor to the adjustable arm. They must not be trapped, fully connected and the pins must be straight. -
Page 15: Contact Details
CONTACT DETAILS Tel: 0121 328 7507 Email: info@jllfitness.co.uk Live Chat: WWW.JLLFITNESS.CO.UK... - Page 16 JLLFITNESS...
