Summary of Contents for JLL AQUA 1
- Page 1 INSTRUCTION GUIDE AQUA 1 MONITOR...
- Page 2 The contents of this manual are subject to change without notice to improve quality. © 2023 JLL Fitness Ltd JLL Fitness Ltd owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of JLL Fitness Ltd is prohibited.
-
Page 3: Table Of Contents
CONTENTS - Safety precautions p. 4 - Cleaning p. 5 - Installation p. 6 - Operation p. 7 Setup p. 7 Manual mode p. 8 Race mode p. 8 Recovery function p. 8 Resetting your monitor p. 9 - Data readouts p. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS The monitor on this machine has been tested to the required standards, each of those passed regulations are shown via the following symbols: WEEE - Waste Electrical and Electronic Equipment Recycling. ABS - Acrylonitrile Butadiene Styrene often referred to as ABS is a type of plastic that is an opaque thermoplastic. CE - The product conforms with relevant EU directives regarding health and safety or environmental protection. -
Page 5: Cleaning
CLEANING Please take care when cleaning this monitor as the LCD screen can easily be scratched. You will need a soft dry cloth Do not spray cleaning chemicals directly onto the monitor Do not apply water to the monitor as it is electrical and may damage the internal components... -
Page 6: Installation
INSTALLATION STEP 1 STEP 2 Insert the batteries, making sure they are the Remove the four screws already in the back of the monitor. correct way round. STEP 3 STEP 4 Connect the male to female wires from the Secure the monitor to the frame arm using the frame arm to the monitor. -
Page 7: Operation
OPERATION The AQUA 1 monitor has a total of 11 readouts, displaying: Time Time 500m Distance Strokes Strokes Per Minute Pulse Total Strokes Date Clock Calendar Temperature When first powered on, the monitor will automatically be in ‘Scan’ mode. This means the digits in the largest segment on the screen will change every few seconds between time, distance, strokes etc. -
Page 8: Manual Mode
MANUAL MODE • Next press ENTER so that the sport symbol in the top left corner is showing, • The MANUAL and RACE will blink ready to be selected. Press UP or DOWN to select MANUAL and then press ENTER to confirm. •... -
Page 9: Recovery Function
RECOVERY FUNCTION • After exercising for a period of time, if you are wearing a chest strap press RECOVERY. • All of the functions will stop displaying except for time, which will start counting down from 60 secs. • The screen will display your heart rate recovery status from F1-F6. •... -
Page 10: Data Readouts
DATA READOUTS Readout Measurement Time Minutes : Seconds Time 500m Minutes : Seconds Distance Metres Pulse BPM (Beats Per Minute) Temperature Degrees... -
Page 11: Troubleshoot
TROUBLESHOOT Issue Resolutions No power to the monitor • Make sure the batteries are fully inserted and the correct way round. • Check your connection wires from the monitor to the arm. They must not be trapped, fully connected and the pins must be straight. -
Page 12: Contact Details
CONTACT DETAILS Tel: 0121 328 7507 Email: info@jllfitness.co.uk Live Chat: WWW.JLLFITNESS.CO.UK... - Page 14 @JLLFITNESS...
