Components - JEXtream RG2100 User Manual

Components

1. Power Button – Turn on/off the device.
Button Operation
Operations
2. Display – Provides general information of the device status and device setting menu.
3. Power Indicator Light – White light blinks while the device is powered on.
4. Navigation Buttons – Left, Right arrows and Enter button to navigate the device menu.
5. Type C USB Port – The USB cable connects here to charge and data transfer.
6. Vent Holes – Ventilation holes to cool down the device.
7. Battery Cover – Battery is inside the battery cover.
8. Battery Cover Notch – Lift the notch to open the battery cover.
Turn On Press and hold the button until "Welcome" message appears.
Turn Off Press and hold the button until Power-Off animation appears.
Display When the display is off, the first quick press of the button wakes
Wake-Up up the display.
Actions
3
