- Page 1 ExpressCard Gigabit Ethernet User Manual (DN-10141) All brand names and trademarks are properties of their Respective owners.
- Page 2 Features and Benefits Fully compliant with ExpressCard Specification 1.0 ExpressCard/34 Form Factor Module Fully compliant with IEEE 802.3, 802.3u and 802.3ab 10/100/1000M data rate auto-negotiation LEDs indicate the status of data transmission Support Wake On Lan (WOL) power management (optional) ...
- Page 3 Hardware Description LED Indicators The following table provides descriptions of the LED status and their meaning. Color Status Description The port is connecting with 1000 Mbps GREEN (1000/ACT) BLINK Sending/Receiving Packets The port is connecting with 100 Mbps GREEN (100/ACT) BLINK Sending/Receiving Packets...
- Page 4 The driver for this device will be installed in the next step. Please insert the CD driver bound with Gigabit Ethernet ExpressCard into your CD-ROM Drive. At the Windows desktop click Start, then Run. Type D:\DN-10141\setup.exe, then click OK. (Change D:\ to match your CD-ROM drive letter)
- Page 5 Please insert the CD driver bound with Gigabit Ethernet ExpressCard into your CD-ROM Drive. At the Windows desktop click Start, then Run. Type D:\DN-10141\Vista\setup.exe, then click OK. (Change D:\ to match your CD-ROM drive letter) Follow the on-screen instructions to complete the installation.
- Page 6 Verify Driver Installation Click on the “Device Manager” tab in System Properties, which you access from the Windows Control Panel. You should see a “Realtek RTL8168C(P)/8111C(P) PCI-E Gigabit Ethernet NIC (Windows® 2000/XP/Server2003)” or “Realtek RTL8168C/8111C Family PCI-E Gigabit Ethernet NIC (NDIS 6.0) (Windows® Vista)” installed under “Network adapters”...
