Wireless LAN PCI Express Adapter
Quick installation guide
Package Contents ...................................................................... Page 1
Network Card Installation ........................................................... Page 2
Connect to Wireless Access Point............................................... Page 6
Advertisement
Related Manuals for Digitus DN-7057
Summary of Contents for Digitus DN-7057
- Page 1 Wireless LAN PCI Express Adapter Quick installation guide Package Contents ..............Page 1 Network Card Installation ............Page 2 Connect to Wireless Access Point..........Page 6...
-
Page 2: Package Contents
Package Contents Before you starting to use this wireless network card, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items: User manual / device driver CDROM (1 pcs)……..…………...………………… □ Quick installation guide (1 pcs) …………………………………………………... -
Page 3: Network Card Installation
Network Card Installation Please follow the following instructions to install your new PCIe wireless network card: 1. SWITCH THE COMPUTER OFF, remove the cover and insert the wireless network card into an empty PCIe slot of your computer. 2. Fasten the antennas to the antenna connectors on the network card by clockwise direction. - Page 4 When view from back: 4. To improve radio reception, please adjust antennas to the position shown in the picture. When view from top: When view from side:...
- Page 5 5. Switch the computer on, the following message will appear on your computer, please click ‘cancel’. 6. Insert device driver CDROM into the CD/DVD ROM drive of your computer, and execute ‘Setup.exe’ program in ‘Driver’ folder. Please read the end user license agreement and click ‘I accept the terms of the license agreement’...
- Page 6 8. Please select ‘Optimize for WiFi mode’ for wireless compatibility, then click ‘Next’. If you want to enhance wireless performance, please select ‘Optimize for performance mode’. However, wireless compatibility is not guaranteed in this mode. Please refer to user manual for details of performance mode.
-
Page 7: Connect To Wireless Access Point
Connect to Wireless Access Point Using Configuration Utility to Connect to Wireless Access Point 1. After installation is complete, wireless configuration utility will be shown as an icon at the lower-right corner of your windows desktop. Please click the icon by right mouse key, and select ‘Launch Config Utilities’. - Page 8 3. If the wireless access point uses encryption, you have to input WEP passphrase or WPA preshared key. Please ask the owner of the wireless access point you want to connect, and input the correct passphrase / preshared key here, then click ‘OK’.
