Summary of Contents for Euresys Picolo.net HD1
- Page 1 REFERENCE MANUAL Picolo.net HD1 © EURESYS S.A. 2021 - Document D304ET-Reference-Picolo.net_HD1-2.7.3.3038 built on 2021-11-23...
- Page 2 This documentation is provided with Picolo.net HD1 2.7.3 (doc build 3038). www.euresys.com This documentation is subject to the General Terms and Conditions stated on the website of EURESYS S.A. and available on the webpage https://www.euresys.com/en/Menu-Legal/Terms-conditions. The article 10 (Limitations of...
-
Page 3: Table Of Contents
1. The Proprietary Device Service 2. The Proprietary Media Service 3. The Proprietary Recording Service 4. The Proprietary PTZ Service 5. The Proprietary Device IO Service PART III : THE CUSTOM SERVICES 1. The ERSP - Euresys Remote Serial Protocol... -
Page 4: Part I : The Onvif Services
PART I THE ONVIF SERVICES... -
Page 5: The Onvif Device Service
Picolo.net HD1 Reference Manual PART I The ONVIF Services 1. The ONVIF Device Service See also: "The Proprietary Device Service" on page 12 Using the Device Service The ONVIF device service is the entry point to all other services provided by your device. -
Page 6: The Onvif Media Service
Picolo.net HD1 Reference Manual PART I The ONVIF Services 2. The ONVIF Media Service See also: "The Proprietary Media Service" on page 13 Using the Media Service The ONVIF media service provides functions to configure the streaming properties of the media streams. -
Page 7: The Onvif Recording Service
Start and stop the recording job. The WSDL filename is "recording.wsdl". As of version 2.6, Picolo.net HD1 provides a limited implementation of the ONVIF recording services with only one pre-existing recording job and one pre-existing recording using a local media profile. Picolo.net HD1 does not generate events so far. -
Page 8: The Onvif Event Service
Picolo.net HD1 Reference Manual PART I The ONVIF Services 4. The ONVIF Event Service The ONVIF event service provides functions to manage the events. You can easily: □ Find out the notifications that a device supports and the information these notifications contain. -
Page 9: The Onvif Ptz Service
Picolo.net HD1 Reference Manual PART I The ONVIF Services 5. The ONVIF PTZ Service See also: "The Proprietary PTZ Service" on page 15 Using the PTZ Service The ONVIF media service provides functions to control the NVT pan, tilt and zoom. -
Page 10: The Onvif Device Io Service
□ DeviceIORelayOutputsBistable For serial ports: □ Set/GetSerialSerialPortConfiguration □ SendReceiveSerialCommand with Timeout values ranging between 1 ms and 5 seconds. Picolo.net HD1 automatically uses base64 encoding (binary payload) for replies captured from the serial line when the request used base64 encoding. -
Page 11: Part Ii : The Proprietary Services
PART II THE PROPRIETARY SERVICES... -
Page 12: The Proprietary Device Service
Picolo.net HD1 Reference Manual PART II The Proprietary Services 1. The Proprietary Device Service See also: "The ONVIF Device Service" on page 5 Using the Device Service With the proprietary device service, you can: □ Get the internal temperature of the device. -
Page 13: The Proprietary Media Service
Picolo.net HD1 Reference Manual PART II The Proprietary Services 2. The Proprietary Media Service See also: "The ONVIF Media Service" on page 6 Using the Media Service With the proprietary media service, you can: □ Perform the auto setup of ONVIF Media Profiles. -
Page 14: The Proprietary Recording Service
Picolo.net HD1 Reference Manual PART II The Proprietary Services 3. The Proprietary Recording Service See also: "The ONVIF Recording Service" on page 7 Using the Recording Service With the proprietary recording service, you can: Query the status and set the AES storage. -
Page 15: The Proprietary Ptz Service
Picolo.net HD1 Reference Manual PART II The Proprietary Services 4. The Proprietary PTZ Service See also: "The ONVIF PTZ Service" on page 9 Using the PTZ Service With the proprietary PTZ service, you can: □ Set and get the serial port configuration of the COM IO device. -
Page 16: The Proprietary Device Io Service
Picolo.net HD1 Reference Manual PART II The Proprietary Services 5. The Proprietary Device IO Service See also: "The ONVIF Device IO Service" on page 10 Using the Device IO Service Sending Custom Commands over the Serial Port The proprietary device IO service extends the ONVIF device IO service to manage the alarm input. -
Page 17: Part Iii : The Custom Services
PART III THE CUSTOM SERVICES... -
Page 18: The Ersp - Euresys Remote Serial Protocol
1. The ERSP - Euresys Remote Serial Protocol ERSP (Euresys Remote Serial Protocol) is a wrapper protocol above TCP/IP that allows the transparent delivery of binary commands to serial devices over RS-232 and RS-485 connectors and the retrieval of the serial devices replies. - Page 19 Picolo.net HD1 Reference Manual PART III The Custom Services Authentication ● A client sends a { HELLO, opt=<client version number>, data=<authentication } message. code> ● A malformed hello message or invalid authentication codes terminate the connection but the server keeps running.
- Page 20 Picolo.net HD1 Reference Manual PART III The Custom Services □ Replies { } if no byte different than the byte to discard was found when the ERR, opt=1 reading timeout expired □ Replies { } if other I/O errors occurred while waiting for the synchronization...
