Nortel 10 Safety Instruction

1. The power supply unit can be operated in an ambient temperature
from 5°C up to 40°C max.
2. The power supply unit is an equipment for building-in. All sides of
the enclosure have been found as operator accessible area.
However, all modification and replacement of compartments(including
the battery, UPS and SPS modules) shall be performed by trained
service personnel.
3. The power supply unit has three configurations with different
electrical ratings as stated below:
Without UPS modules, Input: AC 100-240 V/12-6 A, 47-63 Hz
With UPS module GES142L11yyyy installed, Input: AC 100/120 V, 12 A,
60 Hz.
With UPS module GES142L22yyyy installed, Input: AC 230 V, 7 A, 50
Hz.
4. When the unit has UPS modules installed, the output ratings of the
four AC outlets are defined as:
Maximum AC O/P: 800 W/1400 VA
Maximum DC O/P: according to each provided SPS module
AC and DC combined O/P shall not exceed 800 W/1400 VA
5. The power supply unit should be installed in the end system which
is located in a restricted access area
SAFETY INSTRUCTION
for BayStack 10 Power Supply Unit
Models RPS-800-1 XX and RPS-800-2 XX
2 1 2 3 0 5 - A
*
*
