- Page 2 Treble, Bass and Volume controls as well as REAR PANEL unbalanced stereo RCA and balanced stereo inputs. The iD-SMA50 features a 5.25” bass driver, a 1” piezo high REMOTE CONTROL frequency tweeter delivering a solid 2 x 25 watts RMS of clear, MOUNTING intelligible power.
-
Page 3: Important Safety Instructions
They can take this product for environmental-safe recycling. WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. iD-SMA50: INSTALLATION & OPERATION MANUAL PAGE 3... - Page 4 Use the included remote control to defeat this feature if required. Blinking RED LED = System is muted This feature is enabled/disabled via the included remote control. 4. Remote control infra-red receiver PAGE 4 iD-SMA50: INSTALLATION & OPERATION MANUAL...
- Page 5 Passive Speaker Termination: Terminate you speaker cable to the colour coded spring terminals. Take care when connecting the active speaker to the passive speaker, that both are wired in the same polarity. Red Terminal = positive (+) Black Terminal = negative (-) iD-SMA50: INSTALLATION & OPERATION MANUAL PAGE 5...
-
Page 6: Remote Control
RESET: keep pressed (for 2 secs.) to reset the system to its default values: Sleep/Standby mode ON, volume= 30 bass; treble = 0. 10. FLAT: keep pressed (for 2 secs.) to reset the system to its default equalizer values: bass= 0; treble= 0. PAGE 6 iD-SMA50: INSTALLATION & OPERATION MANUAL... -
Page 7: Mounting Brackets
All fixings must be installed in accordance with the manufacturer’s instructions and specifications. Mounting Brackets The iD-SMA50 speakers are supplied with vertical wall mount U-brackets. The brackets allow users both pan and tilt to position the speaker correctly. Slots for mounting the brackets are spaced 60mm apart. The design of the slots allows for the bracket to be easily mounted and removed. -
Page 8: Specifications
Passive Speaker: 2kg (4.4lbs) Gross Weight per Pair (Box) 6.8kg (13.4lbs) Accessories (Supplied) Active Speaker Passive Speaker Wall Brackets (Pair) 3 metre Speaker Cable 1.5 metre Main Cord Instruction Manual Remote Control! * Disclaimer: Instructions and specifications are correct at time of printing. Information within may be subject to change without notice. PAGE 8 iD-SMA50: INSTALLATION & OPERATION MANUAL... - Page 9 INSTALLATION & OPERATION MANUAL PAGE 9...
- Page 10 NOTES PAGE 10 iD-SMA50: INSTALLATION & OPERATION MANUAL...
- Page 11 The Warranty offered by NAS is not transferable. The Warranty will only apply if your NAS product has been installed and used in accordance with NAS’s recommendations as noted in the operating instructions. iD-SMA50: INSTALLATION & OPERATION MANUAL PAGE 11...
-
Page 12: Warranty Exclusions
The Warranty excludes accessories and consumable goods which have ceased working through normal wear and tear such as, but not limited to, batteries, lamps and other parts classifiable as a consumable part. This includes the CD mechanism and laser fitted to the inDESIGN iDCDP-110. These parts carry a 3 month warranty.
