Summary of Contents for inDESIGN iD-HP Series
- Page 2 INSTRUCTIONS possible performance from these products. FEATURES The inDESIGN iD-HP loudspeaker series is a compact, high output design suitable for mobile and permanent sound installations. CONNECTIONS Attention to detail during development of these products...
-
Page 3: Important Safety Instructions
They can take this product for environmental-safe recycling. WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 3... - Page 4 • Wide dispersion: iD-HP series cabinets are designed to give wide and even dispersion patterns in order to maximise sound coverage over a given area from a single loudspeaker. Each two-way product features a rotate-able HF horn flare allowing horizontal or vertical mounting/operation.
- Page 5 NEAR mode. Switching the products into NEAR mode attenuates the HF driver by 1.5dB. The products deliver neutral voicing no matter which setting is chosen. As we said speaker voicing is subjective, let’s leave it at that. iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 5...
-
Page 6: Horn Rotation
The loudspeakers can be mounted in horizontal or vertical orientation with the supplied U-brackets. Be sure to rotate the horn flare according to the installed orientation. Note: The installer must ensure suitable fasteners are used to secure the U-brackets to mounting surface/s. PAGE 6 iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL... - Page 7 U-Bracket Diagram iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 7...
- Page 8 U-Bracket Diagram PAGE 8 iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL...
- Page 9 U-Bracket Diagram iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 9...
- Page 10 Eye Bolt Suspension The iD-HP series of loudspeakers provide a number of secured mounting points for use with M8 eye bolts. The two mounting points towards the front of the cabinet should be used, with the 3rd point used to angle the enclosure as needed.
- Page 11 PRODUCT TECHNICAL DRAWINGS iD-HP108 iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 11...
- Page 12 PAGE 12 iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL...
- Page 13 Note: M10 fasteners are used for U-bracket mounting. M8 eye bolts are required for flying the iD-HP112. iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 13...
-
Page 14: Specifications
454 x 454 x 715mm Shipping weight 12kg 18kg 25kg Included accessories U-mount bracket * Disclaimer: Instructions and specifications are correct at time of printing. Information within may be subject to change without notice. PAGE 14 iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL... - Page 15 The Warranty offered by NAS is not transferable. The Warranty will only apply if your NAS product has been installed and used in accordance with NAS’s recommendations as noted in the operating instructions. iD-HP SERIES LOUDSPEAKERS: INSTALLATION & OPERATION MANUAL PAGE 15...
-
Page 16: Warranty Exclusions
The Warranty excludes accessories and consumable goods which have ceased working through normal wear and tear such as, but not limited to, batteries, lamps and other parts classifiable as a consumable part. This includes the CD mechanism and laser fitted to the inDESIGN iDCDP-110. These parts carry a 3 month warranty.
