DEHA 6325
GB
Lifting loops
D
Abhebeschlaufen
F
Boucles de levage
PL
Pętle transportowe
CZ
Lanové smyčky
Assembly Instructions • Montageanleitung • Notice d'utilisation • Instrukcja montażu
• Montážní návod
INST_AB 06/14
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for Halfen DEHA 6325
Lifting Systems Halfen DEHA KKT-U Assembly Instructions Manual
Lifting anchor (25 pages)
Lifting Systems Halfen DEHA Assembly Instructions Manual
Lifting anchor system, inserts (20 pages)
Lifting Systems Halfen HLX Series Assembly Instructions Manual
Lift-box (32 pages)
Summary of Contents for Halfen DEHA 6325
Page 1
DEHA 6325 INST_AB 06/14 Lifting loops Abhebeschlaufen Boucles de levage Pętle transportowe Lanové smyčky Assembly Instructions • Montageanleitung • Notice d‘utilisation • Instrukcja montażu • Montážní návod...
Page 2
(fi g. 3); in this case diagonal pull at loop must remain visible after pouring greater than the diameter of the right angles to the walls main orien- the concrete. cable. tation is not allowed. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 3: General Information
3 times the cable diameter or • 16 cable wire breaks over a cable length of 6 times the cable diameter or • 16 cable wire breaks over a cable length of 30 times the cable diameter. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 4
Schrägzug quer zur Wand- Die Kennzeichnung der Abhebeschlau- muss mindestens dem Durchmes- ebene ist hierbei nicht erlaubt. fe muss nach dem Betonieren noch ser des Seils entsprechen. sichtbar sein. • Scharfkantige Haken sind zu © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 5: Allgemeine Hinweise
• 4 Drahtbrüche auf einer Seillänge vom 3-fachen des Seildurchmessers oder • 6 Drahtbrüche auf einer Seillänge vom 6-fachen des Seildurchmessers oder • 16 Drahtbrüche auf einer Seillänge vom 30-fachen des Seildurchmessers © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 6: Notice D'utilisation
être parfaitement visible après correspondre au minimum au La traction oblique vers la paroi de bétonnage. diamètre du câble. l‘élément n‘est alors pas autorisée. • Les crochets à arêtes vives doivent © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 7: Remarques Générales
• 6 brins cassés sur une longueur de câble équivalente à 6 fois le diamètre du câble ou • 16 brins cassés sur une longueur de câble équivalente à 30 fois le diamètre du câble. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 8: Instrukcja Montażu
• promień zaokrąglenia haka musi W takim przypadku rozciąganie na po zabetonowaniu prefabrykatu. być większy lub równy średnicy ukośne prostopadle do płaszczyzny liny ściany jest niedopuszczalne. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 9: Informacje Ogólne
• 4 pęknięte druty na długości 3 średnic liny lub • 6 pękniętych drutów na długości 6 średnic liny • 16 pękniętych drutów na długości 30 średnic liny. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 10: Montážní Návod
30°. nového krytí smyčky a přídavné výztuže musí být dodrženo ustano- Pokud mají být smyčky upevněny do vení EC2. čelní strany úzkého prefabrikátu, mo- hou být umístěny jak svisle (obr.2), © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 11
• 4 zlomy na délce lana odpovídající 3násobnému průměru lana nebo • 6 zlomů na délce lana odpovídající 6násobnému průměru lana nebo • 16 zlomů na délce lana odpovídající 30násobnému průměru lana. © 2016 HALFEN · INST_AB 06/14 · www.halfen.com...
Page 12
We reserve the right to make technical and design changes at any time. Halfen GmbH shall not accept liability for the accuracy of the information in this publication or for any printing errors.
