- Page 1 PHANTASM E 866 / 710 LOWER PACKAGE...
- Page 2 COMPLETE FOIL SETUP E866 FRONT WING NEOPRENE COVER SKU: 122825011 PHANTASM 400 STABILIZER T30 TORX WRENCH NEOPRENE COVER *SKU: 121237008 PFH 767 / 710 SKU: 122826000 PHANTASM MEDIUM CARRYING CASE *COMPLETE HARDWARE SKU: 122824001 PACKAGE SKU: 122827015 PTM 684 / 710 710 FUSELAGE SKU: 121290710 PS 400...
- Page 3 FOIL ASSEMBL Y Coat all bolt hardware with Lanolin oil or a marine-grade grease and wrap with Teflon tape before assembling your foil. (see maintenance section for details) Connect the front wing to the fuselage using the M6x30mm flathead screw for the forward hole, the M6x35mm screw for the center hole and the M6x25mm screw for the third hole.
- Page 4 Note: Mounting hardware comes packaged with Slingshot foil boards, and is not included in the foil package.
- Page 5 PHANTASM ALUMINUM MAST ASSEMBLY INSTRUCTIONS Coat all screws with lanolin oil or marine-grade grease and wrap with Teflon tape before assembling mast. Connect the pedestal to the top of the mast with the two M8 x 40mm flathead screws. Connect the fuselage adapter foot to the other end of the mast with the two M8 x 45mm socket head screws.
-
Page 6: Maintenance
SAFETY MAINTENANCE Foiling comes with a unique set of challenges, risks and dangers. It is imperative to clean and lubricate your foil regularly, especially Know your limits, know your gear, know the conditions and use after use in salt water. This is true for all of your gear, but especially extra caution to keep yourselves and others safe in the water. - Page 7 LUBRICATE HARDWARE: In a clean, sand-free area, carefully coat all bolt hardware, bolt holes and ALL connection points with a layer of Lanolin oil or marine-grade grease. Coat anywhere that parts touch each other to prevent them from corroding and fusing together. Don’t forget the inside of your fuselage to mast slot.
- Page 8 CONTACT: IN FO@ S LI N GS H OTSPO RTS . C O M RID E R S ERV I CE I N TH E U S : 87 7.7 75 .4 8 3 2 INT ER N AT IO NAL PH O NE: 50 9.4 2 7.4 9 5 0 SHIPPING A D D RES S : 390 EV ER G R EE N D R I V E, S UI TE N O RT H F...
