- Page 1 PHANTASM 767 / 710 LOWER PACKAGE...
- Page 2 PHANTASM 767/710 PACKAGE The PFH 767/710 Lower Package is an ultra-maneuverable lower for Kite, Wing, Prone or SUP with a combination of PFH 767 front wing and a PS 400 Rear Stabilizer and 710 Fuse. It can achieve higher speed than similarly sized wing setups in the line and has a mid-range takeoff /stall speed.
- Page 3 COMPLETE FOIL SETUP PFH 767 FRONT WING NEOPRENE COVER SKU: 122825010 PHANTASM 400 STABILIZER T30 TORX WRENCH NEOPRENE COVER *SKU: 121237008 SKU: 122826000 PHANTASM SMALL CARRYING CASE *COMPLETE HARDWARE SKU: 122824000 PACKAGE SKU: 122827011 710 FUSELAGE SKU: 121290710 PS 400 STABILIZER PFH 767 SKU: 121237004...
- Page 4 FOIL ASSEMBL Y Coat all bolt hardware with Lanolin oil or a marine-grade grease and wrap with Teflon tape before assembling your foil. (see maintenance section for details) Connect the front wing to the fuselage using the M6x25mm flathead screw for the forward hole, the M6x30mm screw for the center hole and the M6x25mm screw for the third hole.
- Page 5 Note: Mounting hardware comes packaged with Slingshot foil boards, and is not included in the foil package.
- Page 6 PHANTASM ALUMINUM MAST ASSEMBLY INSTRUCTIONS Coat all screws with lanolin oil or marine-grade grease and wrap with Tefl on tape before assembling mast. Connect the pedestal to the top of the mast with the two M8 x 40mm fl athead screws. Connect the fuselage adapter foot to the other end of the mast with the two M8 x 45mm socket head screws.
-
Page 7: Maintenance
SAFETY MAINTENANCE Foiling comes with a unique set of challenges, risks and dangers. It is imperative to clean and lubricate your foil regularly, especially Know your limits, know your gear, know the conditions and use after use in salt water. This is true for all of your gear, but especially extra caution to keep yourselves and others safe in the water. - Page 8 LUBRICATE HARDWARE: In a clean, sand-free area, carefully coat all bolt hardware, bolt holes and ALL connection points with a layer of Lanolin oil or marine-grade grease. Coat anywhere that parts touch each other to prevent them from corroding and fusing together. Don’t forget the inside of your fuselage to mast slot.
-
Page 9: Sh Ip Ping Ad D R E Ss
CON TACT: IN FO @ S LIN G S H OTSPO RTS. CO M RID ER SERVICE IN TH E U S : 8 77.77 5 .4 83 2 I N T E R NAT IO NAL P H ON E: 509.42 7.4 95 0 SH IP PING AD D R E SS : 39 0 E VE RG REE N D R I V E , SU I TE NO RTH F...
