Downstream Centrifugal Fan
Heater
LP and NG-Fired Heater
Installation, Operation, and Parts Manual
This manual applies to:
GGH-8371 and GGH-8372
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
INSTALLATION AND WIRING MUST BE IN
ACCORDANCE WITH CEC, NEC, AND
LOCAL ELECTRICAL CODES
Part Number: GNA-1435 R1
Revised: January 2023
Original Instructions
