Low Temperature Upstream Heater
VP and NG-Fired Heater
Installation, Operation, and Parts Manual
This manual applies to:
GGH-8390/GGH8390-50
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
INSTALLATION AND WIRING MUST BE IN
ACCORDANCE WITH CEC, NEC, AND LOCAL
ELECTRICAL CODES
Part Number: GNA-2069 R1
Revised: August 2022
Original Instructions
