Summary of Contents for Alfred DB2S
- Page 1 DB2S EN Version 1.0...
- Page 2 Panel Panel Handing Switch Low battery indicator Speaker Status Indicators: #1: Door Locked or Error #2: Door Unlocked or Successful Operation Bottom view of Outside Panel USB-C Power port for Emergency Power 1/12...
- Page 3 Kit A Drive-In Collar Outside panel Mounting panel Inside panel Battery cover BM4*55 KA4*40 BM4*65 Kit B Screwdriver 2/12...
- Page 4 (continued) Kit C Kit D Back up screw for battery cover USB-C Charging RFID card X 2 Reset tool Cable for battery ST3*8 Magnet for Door Door Position Sensor ST3*16 Screws for Door Position Sensor (Optional) Screws for Magnet Override keys Position Sensor Lithium Ion battery...
- Page 5 The handing switch needs to be put in the direction the latch bolt is sliding when looking at the inside of your door. ie: if your latch bolt extends out on the left side of your door when 1. 2-1/8” (54mm) hole saw standing inside looking at the door, then the 2.
- Page 6 Measure your door's door prep, if you have a 1-1/2" (38mm) hole, please refer to the separate guide included "Instructions for doors with 1-1/2" (38mm) holes". If you have a standard 2-1/8" (54mm) prep please proceed to step 1 below. If you have a brand new door with no hole, please use provided template to properly prep your new door using a 2-1/8"...
- Page 7 Step 3. Step 4 (OPTIONAL): If you're not installing the Door Position Sensor, please skip to step #7. To install the Door Position Sensor, use the provided template to align with your existing door prep holes. Once you have Make sure to return latch bolt to the unlocked position aligned the template, take note of the designated area for the before moving forward.
- Page 8 Installing door sensor Step 5a (OPTIONAL): If you’re not installing door Step 5b (OPTIONAL): Once the location of door position sensor, skip this step and go to step 7. position sensor is decided in step 4, peel off the red Once the location of door position sensor is decided in sticker on the back of the door position sensor and step 4, peel off the red sticker on the back of the door...
-
Page 9: Installation
Installation Step 6 (OPTIONAL): If you're not installing door Step 7: Hold the outside panel with Keypad flush to position sensor, skip this step. your door and align tailpiece and cable with door hole Attach the magnet onto the door frame for the door prep. - Page 10 Step 8: Position the inside mounting plate and gasket by Step 9: Secure both assemblies using (2) BM4 Bolts (and first routing the cables and connectors through the (1) #8-32 screw if using optional 3rd Post) making sure mounting plate’s cable holes. that the outside panel is vertically aligned on your door.
- Page 11 Installation Step 12: Install inside panel on inside mounting plate. Step 13: Secure using screws through the inside panel onto the mounting plate using a #2 Philips screwdriver and listed screws below. NOTE: Tail piece must be in horizontal position when you insert the NOTE: Test operation using thumbturn before installing batteries to inside panel (thumb turn should be vertical).
- Page 12 Step 15: Insert Lithium Ion Battery. Front Keypad Step 14: The handing switch needs to be put in the direction the latch bolt is sliding when looking at the will light up to confirm proper installation. inside of your door. ie: if your latch bolt extends out on the left side of your door when standing inside looking at the door, then the Handing switch should be set to the "L"...
- Page 13 Step 16 (OPTIONAL): Install Alfred Wireless Module Step 17: Finally, install the battery cover plate. to connect lock to 3rd Party Smart Hubs (Z-wave or Other Module Sold Separately and not required for normal Bluetooth operation of the lock). Follow syncing instruction per smart hub guide.
