U-Line 29WHTP User Manual

COMBO ICE MAKER/REFRIGERATOR

Model COMBO 29WHTP

FEATURES

1. Manual defrost ice maker
2. Anodized aluminum door handle and frame
3. Stainless hinges and mounting hardware
4. Specially coated grille
5. Travel pin – Factory installed
6. Front vented for built-in installation
7. 2.1 cubic feet of refrigeration
8. No drain required for water
9. Conserves water
10. Field reversible door
11. In-door storage
12. Tempered glass shelves

ADDITIONAL FEATURES:

• See through, removable ice bucket, stores 13 lbs. of ice
• Available in 110/115V 60 cycle or 220/230V 50/60 cycle
• Shipping weight: 97 lbs.
• White vinyl clad steel cabinet and door panel
KCC Printed in U.S.A.
20-13/16 (52.9)
* WATER
VALVE
LOCATION
* POWER CORD
3-5/16
(8.4)
3-5/16
(8.4)
* ON BACK OF UNIT

BENEFITS

Greater daily ice production capacity. Less affected by warmer ambients.
Produces up to 18 lbs. of ice per day in a 70°F ambient temperature.
Corrosive and UV resistant.
Corrosive resistant.
UV resistant.
Helps keep the door secure when en route. Pre-installed at factory.
No need for extra fans, air space, or special venting to the outside of the
cabin. Do not obstruct front grille.
Ice making and refrigeration in one compact unit.
Easy and inexpensive to install. Only needs 1/4" outside diameter
water line connection.
Only 2-1/4 gallons of water needed to produce approximately 18 lbs. of ice.
Flexible installation capabilities to ensure easy access.
2 door shelves with clear, flexible bottle retainers for greater storage.
Generous amount of shelving space, easy to clean, helps to contain spills.
All specifications subject to change without notice.
28-1/2
(72.4)
1-9/16
(4.0)
4-1/2
(11.4)
1-7/16
(3.7)
INCHES (CENTIMETERS)
8900 N. 55th Street
Milwaukee, Wisconsin 53223
(414) 354-0300
FAX (414) 354-7905
www.u-line.com
24 (61.0)
WATER INLET
VALVE
21-7/16 (54.5)
P/N COMBO 29WH
