3.3 Presentation of the user interface

The following elements are visible on the user interface (1):
the colour screen 7" (2),
the keyboard (7),
the payment zone (3), with:
the payment card reader,
the numeric keypad,
the contactless antenna,
the coin slot,
the coin bowl, (4),
the ticket bowl with optional banknote slot(5),
the maintenance compartment lock (6).
With the extended keyboard option, the keys configuration depends on the customisation
of the terminal.
In any case, the extended keyboard has a validation button (green) and a cancellation
button (red).
External view without BNA
Examples of extended keyboards
STRADA PAL – MAINTENANCE MANUAL
12/149
External view with BNA
