360P
CONSOLE
WIRELESS
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JBL QUANTUM 360P and is the answer not in the manual?

Questions and answers

Summary of Contents for Harman JBL QUANTUM 360P

  • Page 1 360P CONSOLE WIRELESS O W N E R ’ S M A N U A L...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ......................1 WHAT’S IN THE BOX ..................... 2 PRODUCT OVERVIEW ....................3 Controls on headset .............................3 Controls on 2.4GHz USB wireless dongle ..................4 GETTING STARTED....................... 5 Charging your headset ..........................5 Wearing your headset ..........................6 Power on ................................7 First-time setup (for PC only) ........................7 USING YOUR HEADSET ....................
  • Page 3: Introduction

    Introduction Congratulations on your purchase! This manual includes information on the JBL QUANTUM360P CONSOLE WIRELESS gaming headset. We encourage you to take a few minutes to read this manual, which describes the product and includes step-by- step instructions to help you to set up and get started. Read and understand all the safety instructions before using your product.
  • Page 4: What's In The Box

    What’s in the box JBL QUANTUM360P CONSOLE WIRELESS gaming headset USB charging cable (USB-A to USB-C) Removable microphone 2.4GHz USB wireless dongle QSG, warranty card and safety sheet Windshield foam for boom microphone - 2 -...
  • Page 5: Product Overview

    PRODUCT OVERVIEW Controls on headset dial • Balances the chat volume in relation to the game audio volume. Volume +/- dial • Adjusts headset volume. button • Press to mute or unmute the microphone. Charging LED • Indicates the charging and battery status. USB-C port Jack for 2.5 mm boom microphone Flat-fold ear cup...
  • Page 6: Controls On 2.4Ghz Usb Wireless Dongle

    / slider • Slide upwards to power on and enter 2.4GHz pairing mode, or slide downwards to power off the headset. • Slide upwards and hold for 2 seconds to enter Bluetooth pairing mode. Controls on 2.4GHz USB wireless dongle button •...
  • Page 7: Getting Started

    Getting started Charging your headset Before use, fully charge your headset through the supplied USB-A to USB-C charging cable. TIPS: • It takes approximately 2 hours to fully charge the headset. • You can also charge your headset through a USB-C to USB-C charging cable (not supplied).
  • Page 8: Wearing Your Headset

    Wearing your headset 1. Attach the detachable boom microphone. 2. Put the side marked L onto your left ear and the side marked R onto your right ear. 3. Adjust the earpads and headband for a comfortable fit. 4. Adjust the microphone as necessary. - 6 -...
  • Page 9: Power On

    Power on • Slide the power switch upwards to power on the headset.  The status LED glows solid white upon powering on.  Slide downwards to power off. First-time setup (for PC only) Download from jblquantum.com/engine to gain access to 3D audio technologies.
  • Page 10 1. Connect the headset to your PC via 2.4GHz USB wireless connection (See “Using your headset”). 2. Go to “Sound Settings” -> “Sound Control Panel”. 3. Under “Playback” highlight “JBL Quantum360P Console Wireless Game” and select “Set Default” -> “Default Device”. 4.
  • Page 11: Using Your Headset

    Using your headset With 2.4GHz wireless connection 2.4G 1. Plug the 2.4GHz USB wireless dongle into a USB-A port on your PC, Mac, PS4/PS5 console, or Nintendo Switch™ console. 2. Power on the headset. It will pair and connect with the dongle automatically. Basic operation Controls Operation...
  • Page 12 To pair manually >5S 1. Power on the headset. 2. On the 2.4GHz USB wireless dongle, hold for more than 5 seconds until the LED flashes white quickly.  Both LEDs on the headset and dongle turn solid white after successful connection.
  • Page 13: With Bluetooth (Secondary Connection)

    2 seconds to enter Bluetooth pairing mode.  The status LED flashes quickly (pairing). 2. Enable Bluetooth on your mobile phone and choose “JBL Quantum 360P” from “Devices”.  The status LED flashes slowly (connecting), and then turns solid blue (connected).
  • Page 14 Control calls ×1 ×1 ×2 When there is an incoming call: • Push the / slider upwards once to answer. • Push the / slider upwards twice to reject. During a call: • Push the / slider upwards once to hang up. TIP: •...
  • Page 15: Dual Source Switching

    Dual source switching This feature allows you to switch from game audio to incoming calls or music sources quickly and easily. 2.4GHz 2.4GHz 1. Ensure that your headset is connected to your mobile phone through Bluetooth and to your PC through 2.4GHz at the same time. 2.
  • Page 16: Product Specifications

    Product Specifications • Model: QUANTUM360P CONSOLE WIRELESS • Driver size: 40 mm Dynamic drivers • Frequency response (Passive): 20 Hz - 20 kHz • Frequency response (Active): 20 Hz - 20 kHz • Microphone frequency response: 100 Hz - 8 kHz •...
  • Page 17 NOTE: • Technical specifications are subject to change without prior notice. - 15 -...
  • Page 18: Troubleshooting

    Troubleshooting If you have problems using this product, check the following points before you request service. No power • The headset turns off automatically after 10 minutes of inactivity. Power on the headset again. • Recharge the headset (see “Charging your headset”).
  • Page 19 • You may experience obvious sound quality degradation when using the headset near a USB 3.0 enabled device. This is not a malfunction. Use an extension USB dock instead to keep the dongle as far from the USB 3.0 port as possible. •...
  • Page 20 HP_JBL_Q360P_OM_SOP_V4_EN...
