Webasto SmarTemp Control 3.0 Installation & Operation Instructions page 5

SmarTemp Control 3.0
LCD Screen Symbol Legend – Air Heater
Main Screen
Heat Mode
Vent Mode
LCD Screen Symbol Legend – Coolant Heater
Mode (Auto or Manual)
Day / Time
Auto or
Manual
Mode
NOTE: When Auto is visible, timers
are enabled
Operation Using SmarTemp Panel
Heater ON Example
Press the Webasto button to turn heater on.
Select heater model – SmarTemp 3.0
1. Using the selection button enter the menu.
2. Using the rotary dial and the selection button, select Heater.
3. Select Heater again to enter the list of available heaters.
4. Select the heater you wish to control with the SmarTemp 3.0 using the rotary dial and the
selection button.
Select heater model – SmarTemp 3.0 Mobile App
1. From the home page tap the selection icon.
2. Select Heater Model from the settings menu.
3. Select the heater you wish to control with the SmarTemp 3.0 mobil app.
Heater Mode
Timer Start Day / Time
Timer Active
Ambient Temperature
Set Temperature
Runtime Remaining
Ambient Temperature
User Set Temperature
Runtime Remaining
Ambient Temperature
Fan Speed Indicator (Low –
Medium - High)
Current
Timer
Day
Active
Auto
Mode
Runtime Remaining
Mode Indicator
Heater ON
Mode Indicator
Fan ON
Auto Mode
Curren
t Day
Curren
t Time
Heater
ON
5
Installation - Operating Instructions
Vent Mode
Timer Start Day / Time
Ambient Temperature
Timer Active
Manual Mode
Manual
Mode
Runtime Remaining
Current
Day
Current
Time
Heater
ON
