Thank you for choosing this product from JessEm Tool Company. We appreciate
your support and hope that our product serves you well. This product is designed
to provide many years of reliable service provided it is used as intended and taken
care of.
This user manual will assist you in assembly and general operation of this product.
It is not our intent to teach you about woodworking. It is assumed that you are an
experienced woodworker with the basic skills and experience necessary to use this
product safely. If after reading the following instructions, if you are unsure or
uncomfortable about safely using this product we urge you to seek additional
information through widely available woodworking books or classes.
As part of our Continuous Product Improvement Policy, JessEm products are
always advancing in design and function. Therefore there may be differences
between what is shown in our catalogs, website or at retail display and what is sold
at time of purchase. We reserve the right to make positive changes to our products
at our discretion.
CLEAR-CUT FLEX
STOCK GUIDES
MODEL # 04250
Contents
:
• (1) Infeed Stock Guide
• (1) Outfeed Stock Guide
• (4) 1/4" Washers
• (4) FLEX T-Bolts
• (2) Locking Knobs
• (2) Pivot Knobs
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JessEm Tool 04250
Summary of Contents for JessEm Tool 04250
- Page 1 • (2) Locking Knobs • (2) Pivot Knobs Thank you for choosing this product from JessEm Tool Company. We appreciate your support and hope that our product serves you well. This product is designed to provide many years of reliable service provided it is used as intended and taken care of.
- Page 2 To assemble the stock guides, start by using (1) of the T-Bolts included and slide it through the backside of the acetal washer and attach (1) 1/4" stainless washer and (1) pivot knob to the T-Bolt. (As seen in image below). Using another T-Bolt, slide it through the larger opening and then add (1) 1/4"...
- Page 3 To install them on your fence, loosen both the locking knob and the pivot knob to allow the 1/4-20 T-bolt, on each guide, to slide into the T-slot on your fence. Each guide is labeled for infeed side and outfeed side. Slide them toward your fence guard ensuring they can pivot up and down without hitting the guard.
- Page 4 PART 04250-R 04250-L DESCRIPTION F0525 1/4-20 x 7/8" Low Head Cap Screw S0061-25 Custom Stainless Washer S0054-9 Washer Insert M0296 1/2" I.D x 3/4" O.D One Way Roller Bearing Roller M0301-1 M0392 #319 Polyurethane O-Ring S0047-7 Roller Axle - FLEX...
- Page 5 Appel sans frais: 1-800-436-6799 • (2) Poignee de pointe de pivot Merci d'avoir ce produit de la Société JessEm Tool. Nous apprécions votre soutien et espérons que notre produit vous sera utile. Ce produit est conçu pour fournir plusieurs années de service fiable sous réserve qu'il est utilisé...
- Page 6 Pour les installer sur votre clôture, desserrez à la fois le bouton de verrouillage et le bouton de pivotement pour permettre au boulon en T 1/4-20, sur chaque guide, de glisser dans la fente en T de votre clôture. Chaque guide est étiqueté pour le côté entrée et le côté sortie. Faites-les glisser vers votre garde de clôture en vous assurant qu'ils peuvent pivoter de haut en bas sans frapper le garde.
- Page 7 GUIDAGES PRÉCIS DES BOIS SPÉCIAUX MODÈLE No.04250...
- Page 8 NUMÉRO ARTICLE Inclus avec DE LA DESCRIPTION 04250-R 04250-L l'ensemble PIÈCE Vis d'assemblage à tête basse 1/4-20 x 7/8" F0525 S0061-25 rondelle inox sur mesure S0054-9 Insert de rondelle Roulement à rouleaux à sens unique 1/2" I.D x M0296 3/4" O.D...
