Precision Miter Gauge
with Dual Indexing Angle Location
User Manual
Model #07100
Thank you for choosing this product from
JessEm Tool Company. We appreciate your
support and hope that our product serves you
well. This product is designed to provide
many years of reliable service provided it is
used as intended and taken care of.
This user manual will assist you in assembly
and general operation of this product. It is
not our intent to teach you about
woodworking. It is assumed that you are an
experienced woodworker with the basic skills
and experience necessary to use this product
safely. If you are unsure or uncomfortable
about safely using this product after reading
the following instructions we urge you to seek
additional information through widely
available woodworking books or classes.
As part of our Continuous Product
Improvement Policy, JessEm products are
always advancing in design and function.
Therefore there may be differences between
what is shown in our catalogs, website or at
retail display and what is sold at time of
purchase. We reserve the right to make
positive changes to our products at our
discretion without notification.
Excel
124 Big Bay Point Road
Barrie, Ontario, L4N 9B4
Canada
866-272-7492 Toll Free
705-726-6145 Local Phone
705-726-6055 Fax
Email: jessem@jessem.com
Website: www.jessem.com
IMPORTANT!
Read and understand the contents of
this manual before assembly or
operation of this product.
IMPORTANT!
Make sure that no part of the miter
gauge or fence can make contact with
the blade or cutter and all knobs are
securely tightened before each use.
MITER GAUGE COMPONENTS
The diagram below shows key components
for using this miter gauge.
SCALE
FENCE EXTENSION
LOCKING
CLAMPING KNOB
DIAL
FENCE EXTENSION
SCALE INDICATOR
SMALL
LOCATOR
PIN
27186
GAUGE
CLAMPING
HANDLE
FENCE
CLAMP
KNOB
PIN
STORAGE
LARGE
LARGE
LOCATOR
LOCATOR
PIN
PIN
RTD10000137AA
