DUAL-ZONE WINE COOLER
MODELS: KM-CW92DZ-SS, KM-CW155DZ-SS
Before using your wine cooler,please read this
manual carefully and keep it for future reference.
For any service-related Issues,
please contact us:
Phone Number: 718-576-6342
Email address: support@koolmore.com
OWNER'S MANUAL
Read This Manual
Inside you will find many helpful hints on how to use and maintain your
wine cooler properly. Just a little preventative care on your part can
save you a great deal of time and money over the life of your wine
cooler. You'll find many answers to common problems in the chart of
troubleshooting tips. If you review the chart of Troubleshooting Tips
first, you may not need to call for service.
Advertisement
Table of Contents
Related Manuals for KoolMore KM-CW92DZ-SS
Summary of Contents for KoolMore KM-CW92DZ-SS
- Page 1 OWNER’S MANUAL DUAL-ZONE WINE COOLER MODELS: KM-CW92DZ-SS, KM-CW155DZ-SS Before using your wine cooler,please read this manual carefully and keep it for future reference. Read This Manual For any service-related Issues, Inside you will find many helpful hints on how to use and maintain your wine cooler properly.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS……………………………………………………..……..2 NAMES OF THE PARTS…………………………………………………………………………..……3 INSTALLATION INSTRUCTIONS BEFORE USING YOUR WINE COOLER………………………..……………………………………………. ………4 INSTALLING YOUR WINE COOLER….……..………….………………………………………………………………4 ELECTRICAL CONNECTION ……………….……………………………………………….…………………………….4 USING YOUR WINE COOLER TEMPERATURE CONTROL …..…………….……………………………………….……………………………………5 BEFORE SWITCHING ON ……………….………………………………………….….……………………………..……7 DURING FIRST USE ……………….………………..………………………………..….………………………………..….7 SWITCHING ON THE APPLIANCE AND SETTING THE TEMPERATURE………..……….…………..8 SAFE LOCK…………………………………………………………………………………………………………………….….8 LOADING THE WINE COOLER………………………………………………………………………………….…..……9... -
Page 3: Important Safety Instructions
product and save this manual for your future reference. THIS PRODUCT IS FOR HOUSEHOLD USE ONLY! IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions: • Before using check that the voltage of wall outlet corresponds to the one shown on the rating plate. -
Page 4: Names Of The Parts
To disconnect the appliance, grip the plug and pull it from the wall outlet. Never pull by the cord. • The appliance is not intended to be operated by means of an external timer or a separate remote – control system. NAMES OF THE PARTS KM-CW92DZ-SS KM-CW155DZ-SS... -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Wine Cooler • Remove the exterior and interior packing. • Before connecting the wine cooler to the power source, let it stand upright for approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from improper handling during transportation. -
Page 6: Using Your Wine Cooler
WARNING • Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized service center. • This wine cooler should be properly grounded for your safety. The power cord of this wine cooler is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock. - Page 7 REGLAGE DE TEMPERATURE BUTTON To choose and set the internal temperature of each compartment. POWER BUTTON To control the appliance turn on or off. To turn OFF the appliance, touch the buttons and hold 5 seconds. UP BUTTON Used to increase (warm) the set temperature by 1°C. DOWN BUTTON Used to lower (cool) the set temperature by 1°C.
-
Page 8: Before Switching On
o The shelves are fully adjustable to suit various wine bottle shapes and sizes. o To prevent damaging the door gasket, make sure the door is fully open when pulling shelves out of the rail compartment. For easy access to the bottles stored, pull the shelves out approximately 1/3. The shelves are designed with an emergency stop to prevent them being removed too far when loaded. -
Page 9: Switching On The Appliance And Setting The Temperature
Switching on the appliance and setting the temperature To switch the appliance on, press the buttons and hold 5 seconds To turn the appliance off again, press and hold the power button for 5 seconds. o Press the "SET" to set the internal temperature of each zone. -
Page 10: Loading The Wine Cooler
Loading the wine cooler IMPORTANT: Your appliance is ideally suited to store 0.75 litre Bordeaux style wine bottles. Whilst it can store larger bottles, you must make sure that they do not prevent the door from shutting properly. o Always check that you can close the door without it fouling on a wine bottle, before shutting it. o When loading several bottles of wine at once, it will take longer for the appliance to cool the individual bottles. - Page 11 Temperature stability is the most important factor when it comes to storing wine. Exposure to light, vibrations or fluctuations in temperature and humidity can all cause wine to spoil. When properly stored, wines not only maintain their quality but many will actually improve in aroma, flavor and complexity as they mature.
-
Page 12: Reversing The Door
Reversing the door Swing This unit has the capability of either opening the door from the left or right side. The unit is delivered to you with the door opening from the left side. Should you desire to reserve the opening direction, please follow these instructions: Note: Before reversing the door, the power must be shut off. -
Page 13: Care And Maintenance
③ ④ CARE AND MAINTENANCE Cleaning Your Appliance ★ Upon installation of your new appliance, it is recommended that it be cleaned thoroughly. ★ Turn off the wine cooler first and then unplug the unit from the wall outlet. ★ Remove all contents. ★... -
Page 14: Moving Your Appliance
Moving Your Appliance ★ Turn off the wine cooler first and then unplug the unit from the wall outlet. ★ Remove all the contents. ★ Securely tape down all loose items inside your appliance. ★ Tape the doors shut. Energy Saving Tips ★... -
Page 15: Technical Specifications
N,SN Fitting ambient temperature range of working Temperature Range 5°C —22°C Rated Voltage 115V Rated Frequency 50Hz Rated current 2.0A Type KM-CW92DZ-SS Volume (liter) 275 L Case stainless steel Material Door Glass Unit Dimension(W×D×H)(mm) 595*566*1397 MM Packaging Dimension ( W×D×H)(mm) -
Page 16: Electrical Circuit Diagram
ELECTRICAL CIRCUIT DIAGRAM We decline liability for any damage or accident derived from any use of this product which is not in conformity with the instructions contained in this booklet. • CORRECT DISPOSAL OF THIS PRODUCT This marking indicates that this product should not be disposed with other household wastes throughout the EU.
