Haws H1001.8HPSHO Quick Start Manual

HANDS FREE
Touchless operation for safety and peace of mind.
high polished
unit with added peace of mind.
MOUNTING
Heavy-duty 16-gauge galvanized steel mounting frame
with welded-in heavy-duty 10 gauge mounting plate with
pre-punched mounting holes. Further convenience is given
to the chiller with the integral fold-out shelf.
Fountain incorporates a touchless sensor operated stainless
steel solenoid valve controlled by a transformer for hands-
free operation. A pressure regulator is used to adjust the
bubbler flow according to incoming water pressures.
TAMPER RESISTANT
30-second obstruction time-out to reduce tampering of
sensor.
VANDAL-RESISTANT
The bubbler head, push button, round bowl, drain strainer
and bottom plate are locked in place, discouraging
unwanted vandal tampering.
HPS and 1011HPS
Chilled Vandal-Resistant ADA Motion-Activated High Polished Fountain
high polished
long lasting
HOHPS touchless
HPS high polished
Model H1001.8HPSHO vandal-resistant
mounted motion-activated drinking fountain shall include an 18
gauge Type 304 polished stainless steel basin with integral
swirl design, 14 gauge Type 304 polished stainless steel wall
bracket, 100% lead-free
operated stainless steel
obstruction time-out controlled by a transformer, polished
chrome-plated brass vandal-resistant bubbler head with
integral laminar anti-squirt flow, chrome-plated brass vandal
resistant waste strainer, vandal-resistant
polished stainless steel
intrusion-proof grill, and 1-1/4" O.D. (3.2 cm)
The R-134a refrigeration
and delivers a minimum of 8 gph (30.3 L) of water at 50° F
(10° C) cooled from 80° F (26.7° C) inlet water at 90° F (32.2° C)
ambient. 115 Volts, 60Hz, rated watts: 370, full load amps: 5
REQUIRES MODEL HCR8 AND MTGFR.SM PRICED SEPARATELY.
FOR INDOOR USE ONLY
drinking fountains, faucets and electric water coolers to be
lead-free by all known definitions including NSF/ANSI/CAN 61-
Section 9, NSF/ANSI/CAN 372, California Proposition 65, and
the Federal Safe Drinking Water Act. Product is compliant to
California Health and Safety Code 116875 (AB 1953-2006),
and NSF/ANSI/CAN 61: Q ≤ 1.
8HPSHO
electric ADA
waterways, touchless
solenoid valve with 30-second
bottom plate,
back panel and louvered
waste
system is hermetically sealed
Haws manufactures
20 July
wall
sensor
pipe.
2
