Haws HWCT8 Quick Start Manual

HWCT8
Recessed Wall Mounted Electric Drinking Fountain
FEATURES & BENEFITS
Bubbler Head
Polished chrome-plated brass bubbler head features an integral
basin shank for added strength, and is equipped with a shielded,
anti-squirt orifice that provides a steady sanitary source of water.
Barrier-Free
Barrier-free capabilities combined with its ease of use allows for
a number of installation location possibilities.
Finish
Beautiful #4 satin stainless steel finish basin can be easily
cleaned and maintained while also resisting corrosion.
Ease of Installation
Installing Model HWCT8 drinking fountain and Model HCR8
refrigeration pack is made easy with this heavy gauge
galvanized steel mounting frame.
Push Button
With its patented (Pat.# 6,981,692) push-button valve assembly
which allows for front access stream adjustment as well as
cartridge and strainer access, this fountain offers the ultimate in
ease of maintenance.

OPTIONS

o Filter: Model 6426, 12" x 2", in-line lead removal element that
reduces lead from incoming water supply.
DISCLAIMER: Continued product improvements make specifications subject to change without notice. Check www.hawsco.com for the latest product information and updates.
1455 Kleppe Lane | Sparks, NV 89431 | [p] 775.359.4712 | [f] 775.359.7424 | [e] info@hawsco.com | www.hawsco.com | 2 March, 2009

SPECIFICATIONS

Model HWCT8 barrier-free, full recessed electric drinking fountain
features a large basin with matching panel and grille manufactured
of 18 gauge, Type 304 Stainless Steel with a satin finish. It is
designed to be installed above a wheelchair access area. The
refrigeration system is balanced
usage/longer life by utilizing a high displacement compressor, a
counterflow cooling evaporator/chiller, efficient capillary sizing, a
large capacity dryer-strainer, and a fan-cooled condenser with
maximum heat exchange. 115V, 60 Hz. Environmentally friendly
R134a refrigerant is controlled by calibrated capillary tube. Model
HWCT8 features front mounted push-button valve, vandal-resistant
bubbler head and provides 8 gph of chilled water. Capacity is
based on ARI standard rating conditions of 80°F inlet water
temperature, 90°F room temperature, 50°F drinking water
temperature.

APPLICATIONS

Perfect for either public or private indoor/outdoor settings, Model
HWCT8 is a great fit in areas where aesthetics are important to the
overall appeal of the architecture. Specifically, this type of fully
recessed wall mounted drinking fountain may be placed in settings
such as: schools and other locations in and around office buildings
where the temperature remains above freezing.
Model meets all current Federal Regulations for the disabled
including those in the Americans with Disabilities Act.
manufactures drinking fountains, electric water coolers and electric
drinking fountains to be lead-free by all known definitions including
ANSI/NSF Standard 61, Section 9, California Proposition 65, and
the Federal Safe Drinking Water Act. Haws electric water coolers
comply with ARI Standard 1010 and ANSI A117.1, and be listed by
Underwriter Laboratories to U.S. and Canadian standards.
to provide low energy
Haws
