COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK
Cotes dehumidifier
Manual number:
Revision:
COTES CRP/CRT FLEXIBLE
How to install, set up, operate and service your
Cotes CRP/CRT Flexible dehumidifier
CRP/CRT
140729
A
page 1/92

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRP FLEXIBLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cotes CRP FLEXIBLE

Summary of Contents for Cotes CRP FLEXIBLE

  • Page 1 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 1/92 Cotes dehumidifier CRP/CRT Manual number: 140729 Revision: COTES CRP/CRT FLEXIBLE How to install, set up, operate and service your Cotes CRP/CRT Flexible dehumidifier...

  • Page 2: Table Of Contents

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 2/92 CONTENTS SECTION 1 / GENERAL BACKGROUND ABOUT THIS HANDBOOK ABOUT MANAGING HUMIDITY ABOUT COTES SECTION 2 / THE DEHUMIDIFIER ABOUT THE COTES CRP/CRT RANGE OF DEHUMIDIFIERS HOW IT WORKS FEATURES AND BENEFITS...

  • Page 3: Section 1 / General Background

    This handbook is mainly intended for use by technicians who install and operate this Cotes dehumidifier unit, who carry out preventive maintenance and who replace defective parts.
  • Page 4 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 4/92 SYMBOLS USED IN THIS HANDBOOK This tells you to perform a particular action Important to note, because items in the dehumidifier can cause injury or affect people’s health You need to pay special attention to this NOTE It is each operator’s responsibility to read and understand this manual and other information...

  • Page 5: About Managing Humidity

    Cotes humidity management technologies enable you to control the levels of moisture in the air inside any building, installation or facility, using only a bare minimum of energy.

  • Page 6: About Cotes

    6/92 ABOUT COTES World leader Cotes is one of the world’s leading experts in the field of adsorption dehumidification, providing technology and expertise that enable companies to achieve better control of the humidity always present in the air. Better management of the humidity in the air also makes it possible to improve and optimise a wide range of industrial processes, prevent damage and corrosion in many types of structures, and reduce energy consumption in all kinds of installations where air specifications are important.

  • Page 7: Section 2 / The Dehumidifier

    (quickly), or reducing the humidity more slowly but using less energy. Dehumidifiers in the CRP/CRT Flexible range can be powered by different energy sources. Cotes provides models fueled by Electricity (E), Steam (D) or Gas (G) as standard – but the use of other energy sources or mixed-energy configurations can be designed to meet costumer request.
  • Page 8 All the components, ancillary equipment and features are optimized for better performance, exceptional service life and easy maintenance. All components (except HR module) are mounted inside the Cotes CRP/CRT cabinet, which can be extended to house extra components if needed.
  • Page 9 CAPACITY CONTROL configuration In addition to the STANDARD configuration, the CAPACITY CONTROL configuration provides: • Modulating capacity by a 0-10 V external signal. Can be controlled by BMS system or Cotes controller FLEXIBLE configuration All dehumidifiers in the CRP/CRT Flexible range can be customised to suit a specific need – hence the name.
  • Page 10 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 10/92 It is only possible to deviate from these ranges if such deviations were specifically mentioned when the order was placed, and special considerations have been incorporated into the unit in order to deal with this.

  • Page 11: How It Works

    HOW IT WORKS Two flows of air The effect of Cotes adsorption dehumidifiers basically stems from the action of two flows of air. The drying process (1–5, black) The incoming moisture-laden flow of air (process air) enters one side of the cabinet and gets filtered by a process air filter.
  • Page 12 Cotes dealer, or Cotes. Heat recovery unit (HR module) Cotes adsorption dehumidifiers can be fitted with a heat exchanger to make sure that part of the thermal energy from the regeneration air leaving the unit is extracted, and reused for preheating the incoming regeneration air.
  • Page 13 The heat recovery unit can be fitted to any CRP/CRT dehumidifiers, but you have to install the appropriate ducting and damper for outgoing regeneration air. For details about the heat recovery unit fitted to this Cotes dehumidifier, please contact your Cotes dealer, or Cotes.
  • Page 14 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 14/92...

  • Page 15: Features And Benefits

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 15/92 FEATURES AND BENEFITS Highlighted features How customers benefit Appearance/cabinet Eye-catching industrial design. Visually attractive units that can be mounted in highly visible positions. Outer surfaces made of stainless steel, as Helps keep technical installations looking standard.
  • Page 16 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 16/92 Highly durable rotor bushes. Savings on maintenance and service work. Greater operating efficiency. Air flow Savings on energy costs. Available with frequency-controlled ventilator. Less noise. Access Savings on maintenance and service work.

  • Page 17: Section 3 / Technical Details

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 17/92 SECTION 3 / TECHNICAL DETAILS SERIAL NUMBER/IDENTIFICATION The serial number/identification code for your particular model is located on the end of the dehumidifier marked with A on the drawing. SOUND LEVEL The sound level is measured in accordance with EN292-2.

  • Page 18: Capacity

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 18/92 CAPACITY The inlet conditions of the air to be dried determine how much water vapour the dehumidifier will remove. The capacity diagram below shows how much water vapour will be removed per kg air passing through.
  • Page 19 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 19/92 Temperature Humidity Proces Air Inlet [g/kg] COTES.COM...
  • Page 20 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 20/92 Temperature Humidity Proces Air Inlet [g/kg]...

  • Page 21: Assemblies And Components

    ASSEMBLIES AND COMPONENTS Customised to meet your needs Cotes dehumidifier units are based on a modular design that enables our customers to select from a broad range of carefully selected components and assemblies, to meet specific installation and operating requirements.

  • Page 22: Included Appendicies And Special Notes

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 22/92 INCLUDED APPENDICIES AND SPECIAL NOTES This manual gives general data regarding all dehumidifiers in the CRP/CRT range. For data concerning the specific dehumidifier please see the appendix section. The following data are found in the appendix:...

  • Page 23: Section 4 / Installation

    Handling Cotes dehumidifiers are built to be very robust, so there is no need for special handling, apart from normal sensible care and attention. Note the weight of the dehumidifier as specified in appendix We recommend that you use a forklift to move the dehumidifier around and place it in position.
  • Page 24 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 24/92 Things to be careful about Electrical work should only be carried out by an authorised electrician. NOTE Electrical work should only be carried out by an authorised electrician. Connections needed – electrical First, make sure that the main switch is OFF.
  • Page 25 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 25/92 A damper for adjusting the regeneration air flow must be installed unless an inverter for regeneration is include in the dehumidifier (not standard). If not, the regeneration air flow will – in most cases – be too high, making it impossible to reach the desired temperature for the regeneration air and thus making the unit less efficient.
  • Page 26 Please consult appendix 1 for details about how to connect the steam coils. Cotes recommend that the installation be fitted with a valve that closes the flow of steam when the dehumidifier is not operating.
  • Page 27 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 27/92 while servicing the machine.

  • Page 28: How To Install Heat Recovery Unit

    Handling Cotes HR heat recovery units are built to be very robust, so there is no need for special handling, apart from normal sensible care and attention. Note that the weight of the heat recovery module is found in appendix 1. We recommend that you use a forklift to move such units around and to place them in position on top of the unit (recommended) or in another suitable place.

  • Page 29: How To Commission This Dehumidifier

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 29/92 HOW TO COMMISSION THIS DEHUMIDIFIER NOTE Only trained/authorised electricians are allowed to carry out any work required in the electrical box of this Cotes dehumidifier. When the cover of the electrical cabinet is open, the power supply must be switched off at the mains switch and the switch must be locked by using a lock.
  • Page 30 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 30/92 c) Set damper positions/air flow settings at commissioning Dampers/settings should initially be set in the following positions. Damper in the regeneration air outlet: fully open Damper in the process air outlet: half closed Some units process flow less than 12,000 m3/h are equipped with an adjustable EC fan for the process air.

  • Page 31: Section 5 / Operation

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 31/92 SECTION 5 / OPERATION HOW TO OPERATE THIS DEHUMIDIFIER The dehumidifier needs to be turned on at the main switch. After a while the PLC overview screen will appear (Configuration-B, Configuration-C and Configuration-D only).
  • Page 32 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 32/92 Rotor speed in rph. Regeneration air temperature. Shows the temperature of the heated regeneration air. If the temperature is shown in red, an overheating alarm is triggered. Regeneration air flow (Configuration-C and Configuration-D only). The white number indicates the air flow, given by the chosen program.
  • Page 33 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 33/92 MAIN menu What you see: START/STOP Turn the dehumidifier on and off. HUMIDITY menu. This is where you decide the levels of humidity that the dehumidifier provides. PROGRAMS menu. This is where you decide how you want the dehumidifier to operate (Always On, RH On/Off, Capacity Control (Configuration-B only), Energy, Quiet, or Custom programs (Configuration-C and Configuration-D only), and Energy+ (Configuration-D only).
  • Page 34 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 34/92 HUMIDITY menu What you see: SENSOR 1. This button is only shown when a sensor is connected. Pressing this button leads to a pop-up menu where you can adjust the humidity target values for that particular sensor.
  • Page 35 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 35/92 HUMIDITY / SENSOR 1 menu What you see: ACTUAL values measured by sensor 1 Measures both %RH and ˚C. Dew point measurement is available in Configuration-B, Configuration-C and Configuration-D. Controlling RELATIVE HUMIDITY with the dehumidifier. Pressing the RELATIVE HUMIDITY checkbox at the top makes the dehumidifier control relative humidity as measured by the sensor (default setting).
  • Page 36 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 36/92 Controlling DEW POINT with the dehumidifier The MIN and MAX values can be changed the same way, by pressing the blue numbers. Threshold values define the hysteresis for RH On/Off, Energy, Quiet and Custom programs. When the actual dew point measured by the external sensor exceeds the MAX value (+1 TDP), the dehumidifier starts.
  • Page 37 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 37/92 HUMIDITY / SENSOR 2 menu (Configuration-C and Configuration-D only) What you see: ACTUAL values measured by SENSOR 2 Measures both %RH and ˚C. Dew point measurement is available in Configuration-C and Configuration-D for sensor 2.
  • Page 38 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 38/92 Energy, Quiet and Custom programs. When the actual dew point measured by the external sensor exceeds the MAX value (+1 TDP), the dehumidifier starts. When the dew point measured by the external sensor is below the MIN value (-1 TDP), the dehumidifier stops.
  • Page 39 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 39/92 PROGRAMS menu (when at least SENSOR 1 is attached) What you see: ALWAYS ON The dehumidifier is running at full power all the time. RH ON/OFF The dehumidifier is controlled by an external sensor. When the values measured by this sensor are below the MIN value you have set, the dehumidifier is turned off.
  • Page 40 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 40/92 The dehumidifier is turned off when the values measured by the sensor(s) are below the threshold MIN value you have set. See page 35 and 37 for more details. QUIET (Configuration-C and Configuration-D only). The focus here is on making sure the dehumidifier runs as quietly as possible.
  • Page 41 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 41/92 PROGRAMS menu in PROCESS mode (for Configuration-D when no external sensors are attached) What you see: ALWAYS ON The dehumidifier is running at full power all the time. ENERGY+ The focus here is on keeping a target absolute humidity (g/kg), as defined in the humidity menu.
  • Page 42 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 43 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 44 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 45 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 46 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 47 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 48 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 49 If your Cotes dehumidifier is operating perfectly, the frame surrounding each button will be green. If a particular component in your Cotes dehumidifier is approaching the end of its planned service life, the frame surrounding the particular button will be yellow (a warning indication).
  • Page 50 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 51 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 52 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 52/92 Return to main menu Return to SERVICE When you have pressed the ORDER button, you will see ordering details. When you have pressed the REPLACE button and entered the appropriate operator code, you will see the screen shown above.
  • Page 53 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 54 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 55 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 55/92 Return to SERVICE When you have pressed the ORDER button, you will see ordering details. When you have pressed the REPLACE button and entered the appropriate operator code, you will see the screen shown above.
  • Page 56 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 57 REMAINING LIFE = Estimated service life left for the component or group of components. ORDER to get details about how to order spare parts. When you press the ORDER button, you get the appropriate part number, and details of where to contact your Cotes dealer and/or Cotes to order the part.
  • Page 58 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 58/92 Return to SERVICE When you have pressed the ORDER button, you will see ordering details. When you have pressed the REPLACE button and entered the appropriate operator code, you will see the screen shown above.
  • Page 59 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 59/92 ALARM This is where you can see any alarms relevant to the operation of your Cotes dehumidifier. What you see: INFORMATION ALARMS These are solely for your information, and you do not have to do anything.
  • Page 60 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 60/92 SETUP menu What you see: DATE AND TIME – this is where you adjust the date and time, if necessary. TIMER – this is where you adjust the timer setting. ADVANCED – this is where you enter the height above mean sea level, and the regeneration air fan (Configuration-B only).
  • Page 61 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 61/92 SET / DATE / TIME What you see: You see actual settings of date and time. If you want to change these, press SET NEW TIME. When you press on any blue number, a drop-down keyboard appears. Enter a new value, and...
  • Page 62 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 62/92 SET / TIMER What you see: TIMER PROGRAM – this is where you select which program is to run when the timer is on. Pressing on this button brings up the TIMER PROGRAM MENU. You can see the chosen timer program in the upper right corner.
  • Page 63 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 63/92 SET / TIMER / HUMIDITY What you see: SENSOR 1. This button is only shown when a sensor is connected. Pressing this button leads to a pop-up menu where you can adjust the humidity target values for that particular sensor.
  • Page 64 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 64/92 SET / TIMER / HUMIDITY / SENSOR1 What you see: Actual values measured by sensor 1 (measures both %RH, °C and actual dew point temperature). Controlling RELATIVE HUMIDITY with the dehumidifier. Pressing the RELATIVE HUMIDITY checkbox at the top makes the dehumidifier control relative humidity as measured by the sensor (default setting).
  • Page 65 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 65/92 If the Capacity Control program is selected (Configuration-B only), only the TARGET and MIN values are shown. Here the target value is the desired target value that the dehumidifier must reach. The dehumidifier stops when the actual dew point is below the MIN value.
  • Page 66 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 66/92 If the Capacity Control program is selected (Configuration-B only), only the TARGET and MIN values are shown. Here the target value is the desired target value that the dehumidifier must reach. The dehumidifier stops when the actual %RH is below the MIN value.
  • Page 67 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 67/92 SET / TIMER / PROGRAM What you see: This only applies to the dehumidifier in timer mode. ALWAYS ON The dehumidifier runs at full power all the time. RH ON/OFF The dehumidifier is controlled by an external sensor. When the values measured by this sensor are below the MIN value you have set, the dehumidifier is turned off.
  • Page 68 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 68/92 air, the level of heat and the rotation of the humidity-absorbing rotor are all controlled by measurements made by high-precision internal sensors. The dehumidifier is turned off when the values measured by the sensor(s) are below the threshold MIN value you have set.
  • Page 69 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 70 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 71 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 72 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 73 If the settings are incorrect or ill-advised, this can have substantial effects on your installations or processes, and may even damage the dehumidifier. Cotes cannot take responsibility for any changes you make in the standard programs, or for the results of any such changes.
  • Page 74 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 74/92 SET / LANGUAGE What you see: These are the languages you can choose the interface for this Cotes dehumidifier. Choose the language you prefer to use to operate this system. SET / LOGIN What you see: This is where you enter your operator code (1234), and press ENTER.
  • Page 75 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 75/92 SET / ADVANCED What you see: HEIGHT ABOVE SEA LEVEL (Configuration-C and Configuration-D only). This is used to ensure correct calculation of air densities in different programs. REGENERATION AIR FAN (Configuration-B only). This is where you set the regeneration air fan.
  • Page 76 What you see: DEHUMIDIFIER – information about your Cotes dehumidifier, including its service history CONTACT – information about where/how to contact Cotes or a Cotes dealer PERFORMANCE LOG – the performance log for your Cotes dehumidifier Return to main menu...
  • Page 77 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 77/92 INFO / DEHUMIDIFIER What you see: DEHUMIDIFIER TYPE – defines the type and configuration of the dehumidifier SERIAL NUMBER – dehumidifier serial number BUILD – date of build SOFTWARE REVISION – which software revision is installed in the PLC controller RUNNING HOURS –...
  • Page 78 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 78/92 INFO / SERVICE HISTORY What you see: SERVICE HISTORY – List of service performed on dehumidifier. It is up to you and your company whether you wish to enter relevant service information here.
  • Page 79 DEALER – who sold the dehumidifier to the customer. 0 = empty space where you can enter data manually. Press the blue 0 (zero) and enter 1 to 17. Each Cotes dealer has its own pre-defined data incorporated into the PLC controller.
  • Page 80 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 80/92 INFO / PERFORMANCE LOG What you see: DATE – the date the data was logged TIME – the time the data was logged RH1 – the actual %RH measured by SENSOR 1 DP1 –...

  • Page 81: Section 6 / Service And Repair

    HOW TO SERVICE AND REPAIR THIS DEHUMIDIFIER Service and maintenance work on this dehumidifier Cotes designs its dehumidifier units so that they are as robust as possible, and only need a minimum of service and maintenance. None of the components require lubrication or adjustment.
  • Page 82 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 82/92 Service/repair work on this dehumidifier Safety instructions Before opening the dehumidifier, make sure that the electric current is switched off at the mains before you open top cover or front door. The main safety switch should also be switched off.
  • Page 83 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 83/92 Replacing steam coil The steam coil is placed inside the cabinet, in the internal regeneration air duct between the inlet and the rotor. The coil must be supported underneath to compensate for the weight during the separation from the duct.
  • Page 84 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 84/92 Troubleshooting Problem Cause Action The unit (or parts of it) One or more fuses/circuit Turn all fuses/circuit breakers on. will not start after a breakers have been triggered power surge/an electrical short circuit...
  • Page 85 – which has to be opened. The regeneration air flow and the regeneration air inlet filter must then be checked. If you have any queries or questions, please contact your Cotes dealer.

  • Page 86: Section 7 / Formalities And General/Legal Info

    AND GENERAL/LEGAL INFO WARRANTIES Warranty conditions The Cotes factory warranty is only valid if a documented programme of service and preventive maintenance has been carried out. Maintenance must have been carried out at intervals of six months or less. Documentation for this must be in the form of a written log/journal, with attested entries.

  • Page 87: Legal Notices

    The information contained in this publication and the products and equipment described herein are subject to change at any time without prior notice. Cotes A/S has no obligation to inform buyers of the products and equipment of such subsequent changes.

  • Page 88: Eu Declaration Of Conformity

    DK-4200 Slagelse www.cotes.com info@cotes.com VAT no. 15 20 03 32 Declares at its own liability that the following models of Cotes adsorption dehumidifiers: CRP4000E covered by this declaration comply with the following directives: Machinery Directive 2006/42/EC Ecodesign 327/2011 directive 2009/125/EF...
  • Page 89 COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 89/92...

  • Page 90: How To Update And Improve This Cotes Dehumidifier

    Extra insulation The doors of the Cotes dehumidifier can be insulated to ensure that the sound pressure level of the unit is reduced and to ensure that all energy (both cooling and heating) is kept inside the unit.

  • Page 91: Who To Contact

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 91/92 WHO TO CONTACT Help when and where you need it Contact Cotes in Denmark or your local dealer: Cotes contact information: Cotes A/S Ndr. Ringgade 70C 4200 Slagelse Denmark +45 5819 6322 info@cotes.com...

  • Page 92: Appendix

    COTES CRP/CRT INSTALLATION, OPERATING AND SERVICE HANDBOOK page 92/92 APPENDIX In enclosed appendix there are specific data for this dehumidifier Appendix 1: Data of components and performance Appendix 2: Flow chart Appendix 3: Drawing Appendix 4: Spareparts Appendix 5: Electrical diagram...
