Disclaimer:
This installation manual is intended for profes-
sional service companies. Appropriate back-
ground knowledge about work on vehicle elec-
trics and electronics is therefore required.
Improper interventions into the vehicle elec-
tronics and their components can under cer-
tain circumstances cause them to no longer
function as intended. This can considerably
endanger the installer (work, e.g., on the airbag
system) and the roadworthiness of the vehicle
and can result not only in property damage, but
also in personal injury.
Therefore, have all work on the vehicle elec-
tronics carried out by a qualified shop.
1
WiPro III Installation Manual
Ford Transit + Transit Custom
7th generation, 2014 – 2015
Thitronik GmbH is not liable for damage to
property and/or personal injury resulting from
improper, incorrect or only partially completed
installation work. The installing service compa-
ny is obligated to ensure that its connection
work neither is faulty in itself nor can lead to
faults or dangers on the vehicle.
The instructions in the WiPro installation man-
ual remain applicable. Unused inputs and out-
puts must be isolated.
Should the given vehicle conditions differ from
those described herein, please contact the
manufacturer or our technical support team.
Updated 12/20
Advertisement
Related Manuals for Thitronik WiPro III
Summary of Contents for Thitronik WiPro III
- Page 1 Ford Transit + Transit Custom 7th generation, 2014 – 2015 Disclaimer: This installation manual is intended for profes- Thitronik GmbH is not liable for damage to sional service companies. Appropriate back- property and/or personal injury resulting from ground knowledge about work on vehicle elec- improper, incorrect or only partially completed trics and electronics is therefore required.
- Page 2 3. Close the housing again and continue with the installation. 4. The following cable colors are equipped, but are not used in this transit model: blue and blue/black. WiPro III Installation Manual – Ford Transit 7. Generation 2014 – 2015...
- Page 3 Exposed on-board computer, remove three bolts/nuts (10-mm socket); fold the on-board com- puter forwards and remove. Connector C4 (blue) Suitable earthing point (terminal 31); attach black wire from the WiPro here (ring eyelet). WiPro III Installation Manual – Ford Transit 7. Generation 2014 – 2015...
- Page 4 Step 6: Teach in wireless accessories All wireless accessories (including the components included with the central control unit) must be taught in on the WiPro III once. The accessories must bear the exten- sion ‘868’ – this is the frequency in MHz.
- Page 5 4. Press a button on the Thitronik handheld radio transmitter to disarm the system or interrupt the alarm. 5. The alarm memory on the WiPro III outputs a flashing sequence via the status LED after the alarm has been interrupted (see Section 2 of the operating manual).
- Page 6 Mounting of wireless magnetic contacts 868 to windows, doors, hatches etc. Item no.: 100757, 100758...
- Page 7 1. The orientation of the transmitter housing on the window frame depends on the available space (frame profile, dis- tance to the roller blind or window). Variant lying Variant lying right left Magnet Magnet Transmitter housing Transmitter housing Window frame Window frame 2.
- Page 8 Alternative mounting variants Should upright mounting on the window frame Variant upright Variant or mounting on the windowpane be neces- windowpane sary, e.g., for space reasons, the transmitter LED must also be aligned pointing away from the magnet. Door or hatch mounting Fixing options Ideally, the transmitter housing is aligned and The wireless magnetic contacts are ideally...
- Page 9 Alignment of circuit board in transmitter housing (as-delivered condition) and positions of components. Top view of Cross section Bottom view of circuit board circuit board Transmitter Transmitter cover Reed switch Battery Transmitter housing Long housing leg Short housing leg Battery Battery Positioning the magnet As long as the magnet is in the yellow area, its...
