9. Cleaning / maintenance
CAUTION!
Risk of physical injury and material damage if used incorrectly!
• Remove the batteries before starting the cleaning tasks.
Check the easy running of the moving door at all times. Clean the guide rails and use lubricant if necessary. Remove dirt and any objects from
the door's closing area in order to protect the motor and avoid transporting dirt via the cord into the inside of the electronics unit. Regularly
check the condition of the cord for wear and replace it in good time. Use our replacement cord to do this (ref.no. 70552).

10. Maintenance and repair

The device does not require maintenance, but should be thoroughly cleaned at regular intervals. In the event of a fault, the device must be taken
out of use immediately. If a repair is required, please contact a qualified electrician or send the device for repair to the manufacturer.
Only use original spare parts. The controller recognises when the battery charge is too low. The controller closes the door in the evening as usual,
and keeps it closed in the morning. The batteries must be changed in order that the door opens and closes automatically.
11. Errors and possible solutions
Error pattern
Door does not open and close
depending on the light sensor
Door does not move down
Door does not fully move up and
always remains stationary at the
same point, or door does not fully
move down and always remains
stationary at the same point

12. Technical data

Batteries 4 x type AA (not included in delivery)
min. slider weight 0.5 kg
max. slider weight 2.5 kg
External buttons A normally open contact each for Up and Down
Device protection class III
Device protection type IP32
CE declaration of conformity
Albert KERBL GmbH hereby declares that the product / device described in these instructions complies with the fundamental requirements and other relevant
stipulations and regulations. The CE mark confirms compliance with the Directives of the European Union.
Electrical waste
It is up to the operator to dispose of the product responsibly after its useful life in accordance with local regulations. Consult the relevant regulations for your country.
The device must not be disposed of in household waste. Under the terms of the EU Directive on the disposal of old electrical and electronic equipment, the device can
be taken to local authority-run refuse sites or recycling plants free of charge, or returned to dealers who offer a returns service. Correct disposal protects the environment
and prevents any possible harmful impacts on humans and the environment.
Possible cause
Light sensor is not set properly
Automatic mode is not activated, because the door
was actuated through an external sensor.
Too little weight on the rope, either because
• the door is too light or
• the door is jammed and does not therefore
move down
Door is obstructed, making it difficult to move
(for example: Dirt in the guide rail)
Solution
Set the threshold value for the light sensor by
pressing the setting button in the casing back in
(see section 8.1).
In the next day cycle, the controller returns auto-
matically to automatic mode. The indicator LED
flashes in automatic mode 1 x (door open) or 2 x
(door closed).
• use other door/slider
• align guide rails
• use lubrication
• add weight to door
Door must be smooth-running.
• remove dirt
• align guide rails
• use lubrication
• add weight to door
13. Accessories / replacement articles
Réf.no. 70560 Sliding door 220 x 330 mm, incl. guide rails
Réf.no. 70570 Sliding door 300 x 400 mm, incl. guide rails
Réf.no. 70580 Sliding door 430 x 400 mm, incl. guide rails
Réf.no. 70551 Pulleys, pack of 4
Réf.no. 70552 Replacement cord with bead
Réf.no. 70554 Light sensor
Réf.no. 70558 Extension Cable for Light Sensor
Réf.no. 70559 Self-locking for automatic chicken door
Réf.no. 70565 External Button
Accessories and replacement articles must be ordered separately.
