Summary of Contents for Tascam Sonicview 16

Page 1 D01407220B Sonicview 16 Sonicview 24 Digital Mixer REFERENCE MANUAL V1.1.0...
Page 2 SEND OVERVIEW menu ..............156 Using SB-16D units ................61 Mute Group and DCA functions ............158 SB-16D control .................. 69 Mute Group function ..............158 Using GPIO extension functions ..........79 DCA (Digital Control Amplifier) functions ......158 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 3 16 – Parameter tables ............214 SNAPSHOT IMPORT / EXPORT screen ..........173 Sonicview 16/24 Mixer Basic Parameters ........214 Exporting snapshots ..............174 Sonicview 16/24 Mixer Basic Parameters (FX) ......219 Importing snapshots..............174 Sonicview 16/24 Preset List ............222 Various LIBRARY Screens ..............176 LIBRARY screen overview ............176 MODULE RECALL SAFE screens .............179...
Page 4 1 – Introduction Overview Conventions used in this manual The Sonicview 16 has 2 touchscreens and 16 channels of mic In this manual, we use the following conventions: preamps while the Sonicview 24 has 3 touchscreens and 24 mic o This unit has two types of buttons that can be operated: preamps.
Page 5 4 internal effects, 4 effect send buses, and 4 stereo effect o 32-in/32-out USB audio interface port return channels Internal processing Input and output ports o 96kHz/54-bit floating-point arithmetic o 16 or 24 mic/line inputs o 2 stereo RCA inputs TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 6 By turning an LCD knob while pressing the MENU key, the contrast of the channel screen that corresponds to that knob can be adjusted. (See “12 – List of shortcut operations” on TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 7 LAYER” will be shown on a black band at the bottom of the screen. o Use the PREFERENCES Screen to set the brightness and contrast of the channel screens. (See “PREFERENCES screen” on page 34.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 8 (See “USER DEFINED CONTROLS screen” on page 42.) NOTE Press one of these keys while pressing the MENU key to open the screen that corresponds to its assigned function. (See “12 – List of shortcut operations” on page 206.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 9 (See “Changing set module colors” on Load an SD card to play files on it and record to it, as well as page 163.) to load data into and back up data from this unit. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 10 (See “USER DEFINED CONTROLS screen” on page 42.) o Press one of these keys while pressing the MENU key to open the screen that corresponds to its assigned function. (See “12 – List of shortcut operations” on page 206.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 11 This unit has some channels with two types of input jacks (XLR and TRS). Do not input signals through both the XLR and TRS jacks of the same channel at the same time. If signals are TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 12 This is an Ethernet port. Use this to connect to a network, primarily for the purpose o XLR (1: GND, 2: HOT, 3: COLD) of remote control of this unit using the dedicated TASCAM . Dante PRIMARY connector Sonicview Control application.
Page 13 Operates with low signal input of 50 msec or longer OUT: For command and tally output i Internal circuit is open collector (10Ω output impedance) i 20V dielectric strength, 35mA maximum current +5V: 50mA maximum supplied current TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 14 The parameters of this unit have unified image colors, making identification of parameter types easy by color. i GAIN/Level: Red i GATE: Yellow-green i EQ: Blue i COMP: Green i FX: Yellow-green i AUX mode bus: Orange i GROUP mode bus: Purple i PAN: Yellow i FADER: Light blue TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 15 CH 1–40 Module Home Screen details Input source Input source name name abbreviation ANALOG Dante SLOT 1 ST IN 1 PLAYER TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 16 “ANALOG” or “SB-16D connected by built-in Dante”. Set to PRE o Tap this area to show the selection frame. When the selection frame is shown, corresponding LCD knobs can be used to adjust the parameters shown. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 17 (C). (See “12 – List of shortcut operations” on page 206.) o When the selection frame is shown, tap this area to open the MODULE (SEND/ PAN) Screen. (See “MODULE (SEND/ PAN) Screen” on page 140.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 18 This shows the input settings of the selected input source. Input area display when the input source is not “ANALOG” or “SB- 16D connected by built-in Dante” Input area display when the input source is “ANALOG” or “SB-16D connected by built-in Dante” TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 19 (See “MODULE (EQ) Screen” on page 134.) b These indicators appear to light as shown below depending on the input level. Red: -3 dBFS, Green: -40 dBFS c This shows the input signal phase setting status. Normal Reversed TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 20 Tap this button to open the MODULE (SEND/PAN) Screen. (See “MODULE (SEND/PAN) Screen” on page 140.) d Purple rounded buttons are shown when GROUP mode MIX 1–22 buses are ON. These appear but cannot be turned on/off on the Home Screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 21 (C). (See “12 – List of shortcut operations” on page 206.) o When the selection frame is shown, tap this area to open the MODULE (SEND/ PAN) Screen. (See “MODULE (SEND/ PAN) Screen” on page 140.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 22 This shows the response graphs and gain reduction meters of dynamics effects. o Tap this area to open the MODULE (COMP/DUCKER) Screen for the selected module. (See “MODULE (COMP/ DUCKER) Screen” on page 138.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 23 Tap this button to open the MODULE (SEND/PAN) Screen. (See “MODULE (SEND/PAN) Screen” on page 140.) d Purple rounded buttons are shown when GROUP mode MIX 1–22 buses are ON. These appear but cannot be turned on/off on the Home Screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 24 (C). (See “12 – List of shortcut operations” on page 206.) o When the selection frame is shown, tap this area to open the MODULE (SEND/ PAN) Screen. (See “MODULE (SEND/ PAN) Screen” on page 140.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 25 This shows the names and-user module names of modules that have been assigned to the corresponding DCAs. o Tap this area to open the DCA/Mute Group SETUP Screen DCA Assign page. (See “DCA Assign page” on page 158.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 26 Tap a submenu item to open a settings screen. button Tap this button to close the Menu Screen. Tap “Front Panel Setup” in the menu item area to show its submenu items. Tap “Talkback Setup” to open the MONITOR SETUP screen TALKBACK/OSCILLATOR page. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 27 48 GPIO Output Setup Assign functions to the GPIO output connector page 49 Set the brightness of the lamp connected to the LAMP jack LAMP Dimmer Setup page 34 on the back of the unit TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 28 192 Recorder / Player Recorder / Player Use built-in recorder/player page 194 Save current mixer settings in built-in memory Save Current Settings page 92 (We recommend doing this before turning the unit off ) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 29 2 – Names and Functions of Parts TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 30 Menu Screen before turning the unit off. screws might not be tightened securely. Insert the (See “Saving the current settings” on page 92.) expansion card securely into the unit again. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 31 Moreover, disconnecting during a firmware update could result in the unit becoming unable to start up or operate properly. i Recording (SD cards only) i Playing back i During IMPORT/EXPORT of snapshot data TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 32 (Set the IF-DA64 (Dante card) “Sampling rate” with Dante the WORD/THRU OUT connector Controller.) to THRU output of the signal THRU OUT/TERM-OFF from the WORD IN connector and turns WORD IN connector termination resistance (75Ω) off. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 33 WORD IN connector. Synchronize with the clock of a connected Dante Dante system. Synchronize with the digital signal clock SLOT1 received through SLOT 1. Synchronize with the digital signal clock SLOT2 received through SLOT 2. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 34 1 USB KEYBOARD TYPE buttons Set the type of USB keyboard connected to the USB port on the top of the unit. The selected button will be highlighted. Button Meaning US English keyboard JPN (default) Japanese keyboard TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 35 — – — Level -18dBFS — – – -20dBFS — – – at the top right of the SHORTCUT HELP OPERATION –: Selectable —: Not selectable window or the Close Help button to close it. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 36 “METER SETUP screen” on page 38.) NOTE Using the User Defined Control function, this screen can also be opened with a USER KEY, footswitch or the GPIO-IN. (See “USER DEFINED CONTROLS screen” on page 42.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 37 The button for the currently selected page is highlighted and corresponding level meters are shown in the meter area (9). o Tap one of these buttons to switch to showing the corresponding level meters. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 38 Swipe the options up and down to select the point where colors METERING POINT page change. Set the metering points for each module type on this page. icons to set metering points. When a metering point is selected, that icon will appear highlighted ( ). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 39 The following controls and operations will not be locked. i Headphone volume i MONITOR OUT volume i TALKBACK volume i POWER switch i Pressing HOME and MENU keys simultaneously i Touchscreen operations on the LOCK SETUP Screen TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 40 (default) for the CH 1–40 modules. Tap the OK button to change the insert points for all CH 1–40 When the stereo link is on, the button will appear modules at the same time. highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 41 MODE area. o “ST” shows the number of AUX mode module pairs that have the stereo link setting on. o “MONO” shows the number of AUX mode modules that have the stereo link setting off. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 42 Switch the number of the Snapshot available Recall for RECALL shown at the top of the Menu Next Screen to the Snapshot that is one later, and then recall it. (See “Snapshot functions” on page 164.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 43 LAST TAB USER KEY will close it. Show the RECORDER PLAYER Screen on the right touchscreen and light the corresponding RECORDER/PLAYER USER KEY. When this screen is open, pressing the corresponding USER KEY will close it. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 44 Snapshots stored with this function are named “USER KEY” followed by a three-digit slot number (for example, “USER KEY 018”). i When the Function is set to Snapshot and Parameter 2 is set to No, if Parameter 3 matches the current Snapshot number, the corresponding USER KEY will light. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 45 When MUTE is off for the specified module and the FADER Fader Start/Stop FX RTN 1–4 level is above the fader start level setting value, LOW level signal output will be latched. MIX 1–22 MAIN L/R TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 46 The colors that USER KEY light when their functions are activated can be set. Tap these buttons to open a color palette window. Tap a color in the color palette to close the window and change the control name display color. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 47 Orange Sends On Fader Mix7 top USER DEFINED CONTROLS Screen. USER KEY 12 Orange Sends On Fader Mix8 w Scroll knob icon This icon shows that LCD knob 8 (lit light blue) can be used to scroll. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 48 The GPIO input connector of a mounted SB-16D does not have functions assigned when shipped from the factory. Tap the Foot Switch Polarity slider in the window to set the footswitch polarity. Options: Normal (default), Invert TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 49 This sets the trigger level of the fader start/stop function (default: -60 dB). Tap the button on the USER DEFINED CONTROLS Screen Tap the CANCEL button to close the window and return to to open a settings window. normal display. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 50 Tap this button to open a color palette window. Layer Key SETUP layer key setting screen Tap a color in the color palette to change the layer key name display color and close the palette window. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 51 Tap this button to confirm setting changes and close to the layer settings screen. 0 Scroll knob icon This icon shows that LCD knob 8 (lit light blue) can be used to scroll. 1 Page selection buttons Tap these buttons to switch the page shown. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 52 5 Custom layer slot buttons In sets of 8, this shows the names of modules assigned to the custom layer that is being edited. Modules that are not assigned will appear blank ( TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 53 Tap the CANCEL button to cancel setting changes. NOTE In either procedure, multiple buttons can be selected in step 1 and assigned consecutively at one time. Tap the APPLY button to confirm setting changes. Tap the CANCEL button to cancel setting changes. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 54 When this is ON, the button will appear highlighted. i If a bus is selected as the monitoring source, sound output from the unit will be monitored. Monitoring will also be silent if the Metering Point setting is “OUTPUT” for the selected TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 55 This button will appear highlighted when soloing is on for any of the modules. o When this button is highlighted, tap it to end soloing on all channels. NOTE This has the same function as the SOLO CLEAR key on the top panel. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 56 Dante connectors. Select the inputs of the expansion card SLOT 1 installed in SLOT 1. Select the inputs of the expansion card SLOT 2 installed in SLOT 2. USB IN Select USB audio interface inputs. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 57 Options: 100 Hz, 440 Hz, 1 kHz (default), 10 kHz This function is assigned to the following GPIO-IN on the Turn LCD knob 8 (lit blue) to adjust it. GPIO-IN page by default. i GPIO-IN 6 (Talkback ON/OFF) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 58 Redundant or Switched mode can be selected. (default: Redundant) This shows the IP address setting mode. Tap this area to open a window where Addressing AUTO (DHCP) or STATIC can be selected. (default: AUTO (DHCP)) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 59 Dante device connected to the Sonicview. Dante routing will not be set even if an SB-16D is mounted. Dante Controller Use Dante Controller for routing. Use this setting when connecting Dante devices other than an SB-16D. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 60 See the following for operation procedures. o “Mounting of devices connected to the Dante network” on page 62 o “Unmounting devices” on page 63 o “Mounting devices that are not on the Dante network” on page 64 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 61 Dante I/O will be assigned to Dante routing (when virtually-mounted), “Virtual” will be shown. automatically when mounted according to the mounting position in the Mounted Device area (4). See the table in “Dante routing” on page 68 for details. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 62 If this Sonicview has control privileges, this completes permission waiting state and end the mounting operation. mounting. If control privileges are set to a different Sonicview, a message confirming whether or not to acquire control privileges will appear. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 63 “No one has control. ” will be shown in the control privilege display area on other Sonicview units that have this device i Tapping the DENY button will open a message mounted. confirming refusal of the request. Tap the OK button to close the message. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 64 The selected mount destination will be shown with a yellow frame, and the central button will become highlighted ( ). Tap the central button to mount it in the selected position on the right side. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 65 Tap the APPLY button to confirm setting changes. This resolves the duplication, and returns to the regular The selected ID number will be shown. screen. This resolves the duplication, and returns to the regular screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 66 IF-DA64 is required to enable Pre Amp Control. If an ID becomes duplicated when there is a remaining [CANCEL] alert message that occurred when switching from virtual mounting to actual mounting, the error message will appear TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 67 If the above responses do not resolve the issue, turn the SB- 16D power off once and wait a few seconds before turning the power on again. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 68 Dante I/O 1–16 for NOTE the mounted SB-16D. Routing for mounted SB-16Ds will be retained as is. If an SB-16D is mounted after the routing control setting is set to “Dante Controller”, routing will not occur automatically. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 69 Sonicview and control privileges are held, or it is virtually mounted Example of appearance when mounted and control privileges are held In this case the same preamp settings will be shown as would be when routing the built-in analog input jacks. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 70 Tap Menu Screen > Rear Panel Setup > Dante Setup to open the Dante SETUP screen and tap the I/O Device tab. Tap the button for the device you want to control. This opens the control screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 71 “Controlled by [Dante device module name of the Sonicview that has control privileges]” will be shown. o In the following cases, nothing will be shown. i If no device has control privileges for that SB-16D i If the device is virtually mounted TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 72 For this reason, settings cannot be changed on this Settings screen if mounted. i For virtually mounted devices, Sampling rate (6), Digital Reference (7) and Analog Reference (8) button settings will all appear gray and cannot be operated. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 73 CANCEL button: Tap this button to discard the changes in the DC Power settings window and close it. g SET button: Tap this button to confirm the values in the DC Power settings window and close it. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 74 SB-16D input/ output signals In this mode, the operation of each GPIO Individual Individual mode port is set individually. Tap an option to switch the overall operation mode for the GPIO port of the SB-16D. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 75 SB-16D input/output signals becomes shorted (Make). In this mode, when the input/ output signal selected in the input/ Mute-Break output signal selection status area (5) is muted, the selected OUT port becomes open (Break). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 76 91.) This shows the Dante network link status. LINK Status This will be shown in red if it is not 1 G. This shows the MAC address of the MAC Address Primary/Secondary Dante port. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 77 When the Addressing item is set to “STATIC”, tapping this area will open the SUBNET MASK Screen. (See “IP Address/ Subnet Mask/Default Gateway setting procedures” on page 91.) This shows the MAC address for SB-16D MAC Address control. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 78 If check marks (4) are added to both, only settings that are Tap the CANCEL button to close the window without not related to the Dante network and Dante will be restored changing the settings. to their factory defaults. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 79 Ports with operation mode set to Local in the list will be shown in gray. Tap the port you want to set in the list and assign functions using the same procedures as with the unit’s built-in GPIO. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 80 Tap Menu Screen > Rear Panel Setup > Dante Setup to open of the module (at left) the Dante SETUP screen and tap the Controller Settings tab. Module with Dante IN INPUT 1–16 of the mounted 1–16 assigned SB-16D 1st in the list TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 81 SB-16D units one at a time from the top in the Mounted 33–48 assigned SB-16D 3rd in the list Device list. Module with Dante IN INPUT 1–16 of the mounted 49–64 assigned SB-16D 4th in the list TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 82 Dante Dante Dante Dante SLOT 1 I/O 17–32 of this Dante I/O 1–16 of the SB- Primary Secondary Primary Secondary Primary Secondary Primary Secondary unit 16D mounted 4th in the list SB-16D SB-16D SB-16D SB-16D TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 83 The following message will be shown. Tapping the REQUEST button and following the procedures from step 5 in “Mounting of devices connected to the Dante network” on page 62 to acquire TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 84 Set the Dante routing control method. Tap Menu Screen > Rear Panel Setup > Dante Setup to open the Dante SETUP screen and tap the Controller Settings tab. Set the Routing control setting to “This Console”. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 85 Module that can operate SB- on the Home Screen and 16D preamps MODULE screen of the module (at left) Module with Dante IN 1–16 INPUT 1–16 of the mounted assigned SB-16D at the top of the list TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 86 Settings made using Dante Controller are stored in the built- in memory of each Dante device. Unless settings are modified, connections will not change even if Dante Controller is quit or the computer is disconnected from the Dante network. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 87 NOTE The Dante module in this unit and IF-DA64 Dante cards (sold separately) have built-in switching hubs. For this reason, when counting Dante devices, count this unit and IF-DA64 cards as two devices each. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 88 Sync to External: ON Preferred Leader: ON Preferred Leader: OFF 1 STATUS This shows the operation status of the installed IF-DA64. STATUS Meaning The installed IF-DA64 is operating Available normally. The installed IF-DA64 is not operating Unavailable normally. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 89 LCD knobs to adjust the values. i Left of /: 1×Fs channel mode NOTE i Right of /: 2×Fs channel mode The IF-AN16/OUT will always operate at 96 kHz even when synchronized to a master clock that is 48 kHz. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 90 Tap the Change button to open the Change password screen. purpose of remote control of this unit using the dedicated TASCAM Sonicview Control application. For details about the TASCAM Sonicview Control application, see its manual. You can download the application manual from the TEAC Global Site (https://teac-global.com/).
Page 91 To change a setting, tap it to move the cursor to that field. A USB keyboard that is connected to the top panel USB port can also be used to input and edit characters. Repeat steps 2–3 as necessary to input setting values in each field. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 92 Tap the SAVE button to save the unit’s settings to its internal memory. o The message shown below will appear while saving. o “Saved. ” will momentarily appear after saving completes and then this message will disappear. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 93 4 – Mixer configuration and settings TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 94 When set to “LOCK”, tap this button to open a confirmation message. Tap the UNLOCK button to close the message and set it to “UNLOCK”. Tapping the CANCEL button on the confirmation message will close it and maintain the locked state. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 95 OSC button and switch to the MONITOR SETUP (MONITOR/SOLO) Screen. (See “Making talkback and built-in oscillator settings” on page 57.) o If the selected input source is not shown elsewhere on this screen, it will be shown on the Others button. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 96 INPUT SOURCE selection button will show the selected When the LOCK/UNLOCK button (1) is set to “UNLOCK”, tap input source. the 8ch BLOCK, 16ch BLOCK (Sonicview 16) or 24ch BLOCK NOTE (Sonicview 24) button on the MODULE (INPUT) Screen to open a window where multiple input sources can be set at i When the LOCK/UNLOCK button is set to “LOCK”, the 8ch...
Page 97 Turn LCD knob 2/4/5/7 (lit blue) to adjust it. Screen where DIRECT OUT output ports can be selected. (See “DIRECT OUT PORT SELECT screen” on page 104.) NOTE The knob used for this operation depends on DIRECT OUT POINT and DELAY POINT settings. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 98 MIX 1–22 modules o Tap this button to open the INSERT RETURN PORT SELECT Screen where INSERT RETURN signal input ports can be selected. (See “INSERT RETURN PORT SELECT screen” on page 107.) MAIN L/R Master module TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 99 If it is a virtually-mounted SB-16D, will appear. o Tap this button to open the OUTPUT PORT SELECT Screen MAIN L/R Master module where output ports can be selected. (See “OUTPUT PORT SELECT screen” on page 108.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 100 Tap this button when set to “UNLOCK” to switch it to “LOCK”. o If the selected output port is not shown elsewhere on this screen, the output port name will be shown on the Others button. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 101 When the LOCK/UNLOCK button is set to “LOCK”, the 8ch BLOCK and 16ch BLOCK buttons are disabled. i If routing operation is set to “LOCK” on another touchscreen while a multiple setting window is open, it will close automatically. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 102 If routing operation is set to “LOCK” on another touchscreen locked state. while a multiple setting window is open, it will close automatically. o Tap this button when set to “UNLOCK” to switch it to “LOCK”. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 103 Drag the display to scroll the screen. The screen can also be scrolled by swiping up and down on the input source selection button (2) area as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 104 “SB #[ID] [port number]” will be shown. locked state. If it is a virtually-mounted SB-16D, will appear. o Tap this button when set to “UNLOCK” to switch it to “LOCK”. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 105 Drag the display to scroll the screen. The screen can also be scrolled by swiping up and down on the output port selection button (4) area as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 106 NOTE o Tap this button when set to “UNLOCK” to switch it to The signal from a single module can be assigned to multiple “LOCK”. output ports. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 107 Drag the display to scroll the screen. The screen can also be scrolled by swiping up and down on the input source selection button (3) area as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 108 3 L/R selection buttons These select whether to set the output ports of the left or right channels of stereo modules. Tap these buttons to switch between left and right. The selected button will be highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 109 Tap the OK button to change the setting and close the window. Tap the CANCEL button to close the window without changing the setting. NOTE The signal from a single module can be assigned to multiple output ports. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 110 The area below -60 dBFS at the bottom of the level meters will light when above -70 dBFS. Tap menu items to, for example, change parameter settings for the selected module. (See “MODULE menu” on page 146.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 111 Master modules. i The COMP and DUCKER buttons are only shown for CH 1–40, MIX 1–22 and MAIN L/R master modules. i The OUTPUT button is only shown for MIX 1–22 and MAIN L/R master modules. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 112 (Default: off ) When this is on, the button will appear highlighted. NOTE This can also be set on the MODULE SAFE page of the SNAPSHOT RECALL SAFE Screen. (See “MODULE SAFE page” on page 172.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 113 Analog GAIN after setting switching pad setting If it is a virtually-mounted SB-16D, will appear. Analog GAIN: +12 – +46 Same value PAD ON/Analog GAIN: -8 – +11 PAD OFF/Analog GAIN: +47 – +66 +46 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 114 When signals at the Analog Reference Level (+6 dBu, +4 dBu, 0 dBu) are input, the Analog GAIN value that becomes the Digital Reference Level (-9 dBFS, -14 dBFS, -16 dBFS, -18 dBFS, -20 dBFS) at the digital stage is shown as “0”. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 115 “SB #[ID] [port number]” will be shown. If it is a virtually-mounted SB-16D, will appear. o Tap this button to open the DIRECT OUT SELECT Screen. (See “DIRECT OUT PORT SELECT screen” on page 104.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 116 Turn LCD knob 2/3/5/6 (lit green) to adjust it. NOTE i The DELAY POINT for CH 1–40 modules can also be changed as explained in “CH 1–40 CONFIG page” on page 40. i The knob used for this operation depends on DIRECT OUT TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 117 DCA Assign page. (See “DCA Assign page” on page 158.) Screen. (See “INPUT SOURCE SELECT screen” on page 5 MUTE GROUP 1–8 buttons 102.) Tap these buttons to change Mute Group assignment states. (Default: off ) Assigned buttons will be highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 118 PAD button setting Range Analog GAIN: +12 – +46 Same value +3 (default) – +57 PAD ON/Analog GAIN: -8 – +11 -17 – +37 PAD OFF/Analog GAIN: +47 – +66 +46 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 119 (C). 0 dBu) are input, the Analog GAIN value that becomes the Digital Reference Level (-9 dBFS, -14 dBFS, -16 dBFS, -18 dBFS, -20 dBFS) at the digital stage is shown as “0”. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 120 (See “MODULE (SEND/PAN) Screen” Assigned buttons will be highlighted. on page 140.) NOTE Tap this area while pressing the HOME key on the top panel to set the balance to center (C). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 121 Tap these buttons to change Mute Group assignment states. (Default: off ) Assigned buttons will be highlighted. 7 DCA 1–8 buttons Tap these buttons to change DCA assignment states. (Default: off ) Assigned buttons will be highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 122 SLOT 2 Reversed o Phase button display when the selected module is stereo Normal o Tap this button to open the INSERT RETURN PORT SELECT Screen. (See “INSERT RETURN PORT SELECT screen” on Reversed page 107.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 123 MIX 1–22 and FX 1–4 buses. (See “9 ALL SEND button ( )” on page 24.) o Tap this area to open the MODULE (SEND/PAN) Screen for the selected module with the bus selected for the tapped area. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 124 2 INPUT SOURCE buttons o When the LOCK/UNLOCK button (3) is set to “UNLOCK”, tap these buttons to select the input source of the selected module. Only the one button for the selected input source will be highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 125 Red: -3 dBFS, Green: -40 dBFS o When the input source of the selected module is an “ANALOG” stereo module, 2 Analog GAIN knobs will be shown. Use LCD knobs 1–2 (lit red) to adjust them. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 126 If routing operation is set to “LOCK” on another touchscreen PAD ON/Analog GAIN: -10 – +9 while a multiple setting window is open, it will close automatically. PAD OFF/Analog GAIN: +45 – +64 +44 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 127 This cannot be used when the LOCK/UNLOCK button (3) is 16 (Sonicview 16) or 24 (Sonicview 24) channels can be set set to “LOCK”. at the same time. (See “Setting input sources for multiple i If routing operation is set to “LOCK”...
Page 128 The BATCH SETUP window will close. 1 FX TYPE button Tap this button to open the effect type selection window for the selected module. Tap a button to select an effect type. Selecting will close the selection window. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 129 Use this to adjust the output level from the effect. Range: -∞ dB – +10 dB (default: 0.0 dB) When the selection frame is shown, use the corresponding LCD knob 8 to adjust the value. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 130 FEEDBACK 0 - 100 FEEDBACK 0 – 100 HI DAMP 500 Hz – 16.0 kHz 3.36 kHz WET LEVEL L 0 – 100 WET LEVEL C 0 – 100 WET LEVEL R 0 – 100 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 131 PITCH 2 -24 – +24 DEPTH 0% – 100% FINE 2 - 50 Cent – +50 Cent +10 Cent DELAY TIME 0 msec – 100 msec 40 msec PHASE 0 deg – 180 deg 180 deg TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 132 When on, this button, the dynamics input/output response graph and parameters will appear highlighted. o When off, a large “OFF” will appear in the top left of the dynamics input/output response graph area (2). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 133 -60 dB – 0 dB -40 dB 1:1, 2:1, 4:1, 8:1, 16:1, 32:1, RATIO 64:1 KNEE HARD, MID, SOFT ATTACK 0 ms – 125 ms 10 ms RELEASE 5 ms – 5.00 s 250 ms TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 134 Q for that band can be adjusted. o When EQ is off, a large “OFF” will appear in the bottom FX RTN 1–4 module right of the graph area. NOTE HPF is only shown for CH 1–40 modules. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 135 This shows the level of the signal output from the EQ. OFF automatically. 0 EQ parameters (LO band) i When using a Sonicview 16 that has two touchscreens with This shows the EQ LO band parameters and can be used to the TASCAM Sonicview Control application, the maximum adjust them.
Page 136 When this is on, this button, the GEQ overall settings graph (4) and the GEQ setting display area (8) will appear highlighted. 3 LIBRARY button Tap this button to open the GEQ LIBRARY Screen. (See “Various LIBRARY Screens” on page 176.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 137 GEQ only will be shown highlighted. OFF automatically. i When GEQ is off, a large “OFF” will appear in the bottom i When using a Sonicview 16 that has two touchscreens with right of the area. the TASCAM Sonicview Control application, the maximum...
Page 138 Tap this button to turn KEY IN FILTER on/off. (Default: OFF) 0 KEY IN FILTER TYPE button o This shows the KEY IN FILTER type. o Tap this button to open the type selection menu. MAIN L/R Master module Options: HPF, BPF (default), LPF TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 139 -30 dB, -24 dB, -18 dB, -12 dB, THRESHOLD -18 dB -6 dB -∞, -24 dB, -18 dB, -12 dB, -9 dB, ATTENUATE -18 dB -6 dB, -3 dB HOLD 0.1sec – 5.0sec 1.0 sec RELEASE 0.1sec – 5.0sec 3.0 sec TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 140 When the DYNAMICS TYPE is Comp, the KEY IN SOURCE is the Pre Comp signal. i When the DYNAMICS TYPE is DUCKER, the KEY IN SOURCE is the POST Fader/MUTE signal. CH 1–40 modules CH 1–40 modules with Stereo Link on ST IN 1–2 modules TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 141 SEND level for that bus to 0 dB. i Tap the SEND PAN area while pressing the HOME key on the top panel to set the SEND PAN for the tapped bus to center (C). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 142 (“FX 1–4 bus SEND OVERVIEW Screen” on page 152). i Tap the SEND level area while pressing the HOME key on the top panel to set the SEND level for that bus to 0 dB. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 143 This is only shown when the selected module is a CH 1–40 module with the Stereo Link setting on, or a ST IN 1–2 or FX RTN 1–4 module. i If L-Mono or R-Mono is selected, the BAL setting will function as a PAN setting. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 144 SB-16Ds will be highlighted yellow. o If the selected output port is not shown on one of the main buttons, the output port name will be shown on the Others button. MAIN L/R Master module TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 145 Tap this button when set to “UNLOCK” to switch it to “LOCK”. NOTE The LOCK/UNLOCK button (1) setting is shared by the following routing setting screens. i MODULE (INPUT) Screen i MODULE (OUTPUT) Screen i INPUT SOURCE SELECT Screen i OUTPUT PORT SELECT Screen TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 146 MODULE (INPUT) Screen of the selected module. This redoes pasting to the MODULE REDO Paste INPUT (INPUT) Screen of the selected module. Tap this area to open the LIBRARY MODULE Library Screen for the selected module. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 147 PAN) screen only exist for stereo input modules. (See “MODULE (SEND/PAN) Screen” on page 140.) For this reason, MODE/IMAGE parameters can only be copied and pasted when both the source and destination are stereo input modules. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 148 MASTER faders, master section MUTE, SOLO and SEL keys and color bars, L/R SEND indicators and channel screens. NOTE This screen will not be shown for a MIX bus with BUS mode set to GROUP. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 149 The SEND OVERVIEW button at the top of the MODULE Screen for a MIX 1–22 module can also be tapped to open this screen. PRE/POST (INPUT) page SEND LEVEL (INPUT) page SEND PAN (INPUT) page SEND LEVEL (BUS) page TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 150 3 / buttons modules to the MIX 1–22 buses. Tap these buttons to move left and right in order between MIX 1–22, FX 1–4 and MAIN L/R buses to show and activate them for operation. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 151 Tap these buttons to switch settings for send positions to MIX 1–22 buses. (See “15 – Block diagram” on page 213.) Display Explanation Pre-fader POST (default) Post-fader Tap the buttons to switch their send positions. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 152 1–4 module that corresponds to the FX 1–4 bus shown. 3 / buttons Tap these buttons to move left and right in order between MIX 1–22, FX 1–4 and MAIN L/R buses to show and activate them for operation. ON/OFF (BUS) page TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 153 They are shown dimly and cannot be o When a selection frame is shown, use corresponding LCD operated on this screen. knobs (lit green) to adjust SEND levels. Range: -∞ dB – +10 dB (default: -∞ dB) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 154 Tap this button to open the MODULE Screen for the selected MAIN L/R Master module. 3 / buttons Tap these buttons to move left and right in order between MIX 1–22, FX 1–4 and MAIN L/R buses to show and activate them for operation. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 155 This shows a list of setting states for pan/balance from the MIX 1–22 modules to the MAIN L/R bus. o When a selection frame is shown, use corresponding LCD knobs (lit yellow) to adjust the pan/balance. Range: L100 – C – R100 (default: C) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 156 NOTE i When the selected bus is MAIN L/R, this will change the FADER level setting. i When the selected bus is MAIN L/R, the “Copy from Fader Level” menu item will not be shown. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 157 This copies the MAIN L/R bus pan/balance settings to the Copy from MAIN L/R PAN selected bus pan/balance settings. NOTE When the selected bus is MAIN L/R, the “Copy from MAIN L/R PAN” menu item will not be shown. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 158 DCA 1 cannot be assigned to DCA 2, and DCA 1 DCA. and DCA 2 cannot be assigned to DCA 3.) Buttons selected by tapping will be highlighted. DCA modules that cannot be assigned have frames around their module button areas (4). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 159 Tap OK to clear all assignments. Mute Group Assign page Tap OK to clear all assignments. 1 MuteGrp buttons Tap these buttons to select a Mute Group for changing assignments. The selected Mute Group button will be highlighted. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 160 The Mute Group MUTE function is assigned to the following by default on the User Key and GPIO-IN pages. DCA 1 MODULE NAME Screen i USER KEY 1–4 (Mute Group 1–4) i GPIO-IN 1–5 (Mute Group 1–5) Mute Group MODULE NAME Screen TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 161 Tap the Copy button to copy the characters shown in the keyboard input area to the copy buffer. o Tap the Paste button to paste the characters in the copy buffer to the keyboard input area. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 162 The Shift button automatically deactivates after inputting one character. o Setting for inputting numbers and lowercase letters Caps lock button Shift button o Setting for inputting numbers and uppercase letters Caps lock button On (highlighted) Shift button TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 163 The screen can also be scrolled by tapping the icon categories on the left side of the screen. i Tapping the keyboard input area on a NAME screen will reopen the keyboard. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 164 “001”. This setting data is saved. Moreover, when recalling snapshots, specified parameters can be protected so that they are not changed. (For example, routings can be kept the same when recalling snapshots.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 165 Tapping the CANCEL button on the confirmation message will close the message without storing. After storing completes, a storing completion message will appear for about two seconds. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 166 “USER KEY + data slot number”. or “Prev” This recalls the settings stored in the data slot one before/ after (excluding presets) the snapshot shown by the number (1)/name (2) at the top of the Menu Screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 167 Parameter 3 of that control. NOTE Limitations on recalling snapshot data from a different model (Sonicview 16/Sonicview 24) When recalling snapshot data from a different model, a confirmation message like the following will be shown. Message when recalling Sonicview 16 snapshot data on a Sonicview 24 This is Sonicview 16 data.
Page 168 Menu Screen. renamed. icon This has the same function as the icon on the Menu Screen. (EDIT) icon This has the same function as the icon on the Menu Screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 169 Tap this button to undo/redo snapshot recall. RECALL UNDO cancels the last snapshot recall and restores settings to their state before the recall. RECALL REDO cancels the undo operation and restores settings to their state before the undo. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 170 2 Copy button Tap this button to copy the settings data of the selected snapshot. NOTE The LIBRARY Screen for snapshots is the only one that has Copy and Paste functions. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 171 Snapshot List Screen. i The icon is shown until new snapshot setting data is copied or until the unit power is turned off. The icon will also disappear if the copy source is deleted, overwritten or renamed. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 172 Settings included in INPUT/OSC PARAMETERS Analog Gain Analog Gain GANG On/Off PAD On/Off Phantom On/Off Phase D.Trim HPF Freq HPF On/Off CH OSC INPUT OSC On/Off OSC Assign OSC Level OSC Type OSC Freq TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 173 4 Snapshot List scroll knob and scrollbar Drag the scrollbar to scroll the screen. The Snapshot List (3) can also be scrolled by swiping up and down as well as by turning LCD knob 4. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 174 (See “SNAPSHOT IMPORT / EXPORT screen” on page 173.) Connect the import source media. Use the media selection button (1) to select the media to use as the import source. (See “1 Media selection button” on page 173.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 175 Tap the REPLACE button to import and overwrite snapshot data with a different name and close the confirmation message. i The following message will be shown if the import destination slot is locked. Cannot Import. Target Locked. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 176 This shows the name of the module active for library storing and recalling. The parameters included in module libraries are the same as the parameters used for Copy MODULE. (See “MODULE menu” on page 146.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 177 (See i Tap the Replace button to overwrite the library settings “MODULE RECALL SAFE screens” on page 179.) data with the same name and close the confirmation message. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 178 MODULE Screen. o If no data slot is selected or a data slot that does not have saved data is selected, this button will appear gray. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 179 The selected All System Data i The following parameters are not included in module file will be removed from the list of saved files (1). libraries. i Analog Gain i Analog Gain GANG On/Off i Phantom On/Off i Routing TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 180 Drag the scrollbar to scroll the screen. The list of saved files (1) can also be scrolled by swiping up and down as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 181 ATTENTION Use caution, because loading All System Data will replace all Snapshot and LIBRARY settings data with the loaded data. To keep the current data, save it before loading. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 182 Tap the CANCEL button to close the confirmation message. i Tapping the BACKUP button will back up (export) the All System Data file from the internal storage to the selected external media and close the confirmation message. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 183 ALL SYSTEM DATA Screen. i One of the following messages will be shown if the internal storage does not have enough open space. Cannot Restore. Internal memory is full. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 184 Tap this area to open the RECORDER/PLAYER Screen. (See “RECORDER/PLAYER Screen” on page 194.) 5 TEMPERATURE o These show the temperature states of the system, CPU and DSP. o Tap this area to open the PREFERENCES Screen. (See “PREFERENCES screen” on page 34.) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 185 These appear when all errors/alerts cannot be shown on the display at the same time. When errors and alerts occur (“Sonicview 16/24 Error Screen SYSTEM error/alert message list” on page 188), they are listed Drag the scrollbar to scroll the screen. Errors can also be on this page.
Page 186 (3) if it has been closed. o When an alert occurs, a message window like the following will appear on the right touchscreen (“Sonicview 16/24 Error Screen SYSTEM error/alert message list” on page 188). Error/alert messages open on the Home Screen i Tap the CLOSE button to close the message.
Page 187 This appears when the entire license document cannot be shown on the display at the same time. Drag the display to scroll the screen. The list can also be scrolled by swiping up and down as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 188 9 – Various information displays Sonicview 16/24 Error Screen SYSTEM error/alert message list Error/alert type Message Meaning Note “Master clock name” clock has no There is no signal from the master signal. Switched to Internal. clock. “Master clock name” clock is The master clock is unlocked.
Page 189 A virtually mounted SB-16D has This message will not be shown SB-16D mounting alert SB-16D ID#xx-xx connected. been connected to the Dante if this alert occurs within three network and became mounted. minutes of starting up. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 190 The duplicated ID conflict of SB-16D ID #xx-xx conflict has been INFORMATION Screen ERROR mounted SB-16D units has been resolved. page as an error record. resolved. This is not shown at the top of the screen. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 191 Always use this unit to format medias to be used with it. Operation of this unit might be affected when using an SD card or USB flash drive that has been formatted by a computer or other device. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 192 If there are more files than can be shown on the display at once, swipe the list up or down to scroll it. i The screen shown above is an example. The actual appearance will differ. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 193 UPDATE button. The startup screen will be shown briefly and then updating will start. ATTENTION i Be careful not to let the power be interrupted during the update. i If the power is interrupted during the update, the unit might become unstartable. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 194 999. “Rec Limit” will be shown in the recording folder name area for folders that already have 999 tracks or that contain files with names ending “999.wav” and recording will no longer be possible. Switch to a different folder to record. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 195 This shows the levels output from the player. 6 Time Bar This shows the current playback position relative to the length of the take. Drag the knob on the bar to change the playback position. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 196 These show the names of the input modules to which the player outputs are assigned. “No assign” is shown when no player output is assigned. If they have been assigned to multiple input modules, they will be shown in order from the lowest number. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 197 Tap this area to enter the tapped folder. w File list This shows the names and lengths of playable files on the current level in name order. i SD card volume name i Various SD card capacity data TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 198 LCD Example of mixer Root directory for selecting media knob 8. NOTE If the total number of files and subfolders in the folder exceeds 999, files and folders might not be shown correctly. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 199 File list This shows the names and lengths of playable files on the current level in name order. Tap this area to select audio files and make them subject to playback by adding check marks (4). TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 200 Drag the scrollbar to scroll the screen. The file list can also be scrolled by swiping it up and down as well as by turning LCD knob 8. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 201 Tap the Set REC FOLDER button (9). Tap the Set PLAY FOLDER button (9). This sets it as the recording folder, and “REC FOLDER” appears. This sets it as the playback folder, and “PLAY FOLDER” appears. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 202 Uncompress the saved software (zip file) on the computer desktop or another location. Double-click the “TASCAM Sonicview USB.exe” file in the folder that appears after uncompression to launch the installation software. ATTENTION...
Page 203 (Windows Double-click “Sound” in the Control Panel. 11/Windows 10). NOTE Select “TASCAM Sonicview USB ” from the list, and double- click it. If the Control Panel is set to be viewed as icons, a “Sound” icon will appear.
Page 204 11 – USB audio interface functions Open the Recording tab, and select “Sonicview 16/24”. Simultaneous ASIO/WDM playback The driver for this unit can simultaneously play ASIO output from a DAW and WDM output from Windows Media Player, for example. The sample rates of both sources must be set to the same value for simultaneous playback to be possible.
Page 205 11 – USB audio interface functions Open the Playback tab, and select “Speakers (Sonicview 16/24)”. Click “Properties” for “Speakers (Sonicview 16/24)” to open the Speakers Properties Screen. 10. Open the Advanced tab, and set the Default Format. Set the sample rate and bit depth for the Default Device on the Play tab to the same values set on the Record tab.
Page 206 MODULE (SEND/ PAN) Screen for module where Parameter 1 is set Turn an LCD knob while pressing the This adjusts the contrast of the channel screen that corresponds to that knob. MENU key on the top panel TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 207 If you are having trouble with the operation of this unit, please try the following before seeking repair. If these measures do not solve the problem, please contact the store where you purchased this unit or TASCAM customer support service.
Page 208 Channel Screen, and press and hold the HOME and MENU keys for at least five seconds to restart the system. Note that while restarting audio output will stop. Since restarting will take some time to complete, conduct it when it will not cause trouble. TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 209 48kHz: 256 ports maximum (Sonicview 24), Signal processing 248 ports maximum (Sonicview 16) o Mixer engine: 96kHz/54-bit floating-point arithmetic i MIC/LINE: 24 (Sonicview 24), 16 (Sonicview 16) o ADC: 96 kHz/32-bit i ST IN (RCA): 4 (2 stereo) o DAC: 96 kHz/24-bit...
Page 210 +18 dBu (D.Ref: -14 dBFS, A.Ref: +4 dBu) +20 dBu (D.Ref: -16 dBFS, A.Ref: +4 dBu) +22 dBu (D.Ref: -18 dBFS, A.Ref: +4 dBu) +24 dBu (D.Ref: -20 dBFS, A.Ref: +4 dBu) D.Ref: Digital Reference Level setting A.Ref: Analog Reference Level setting TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 211 Please access to a product Control input/output ratings page of this product from the TEAC Global Site (https://teac- global.com) to find the list or contact the TASCAM customer support service. FOOTSWITCH jack File System Connector: 6.3mm (1/4”) TS phone jacks (Tip: HOT, Sleeve:...
Page 212 Windows 11 64-bit Windows 10 64-bit 472.0mm Computer hardware requirements Windows computer with a USB 2.0 (or higher) port* * Operation is not guaranteed using the TASCAM driver with ARM64 CPUs. Sonicview 24 Supported operating systems macOS Monterey (12) macOS Big Sur (11) macOS Catalina (10.15)
Page 213 Do not connect both the XLR and 1/4" Line input on the same channel. Comp Key-in Trigger Source : SELF, CH1-40 Pre Comp, MIX1-22 Pre Comp, MAIN L/R Pre Comp Ducker Key-in Trigger Source : SELF, CH1-40 Post Fader/Mute, MIX1-22 Post Fader/Mute, MAIN L/R Post Fader/Mute TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 214 16 – Parameter tables Sonicview 16/24 Mixer Basic Parameters Libraries Name User Preset Snapshot MODULE INPUT MODULE FX RTN MODULE OUTPUT GATE/EXP/DE-ESSER COMP/DUCKER Input Modules Fine Step Coarse Steps (when LCD knob (when LCD knob Function Parameter steps turned without being...
Page 215 0.0 meter – 117.3 meter 0.1 meter/click 2.0 meter/click Delay Time 0.0 feet – 384.8 feet 0.1 feet/click 5.0 feet/click DELAY 0.00 msec – 341.32 msec 0.02 msec/click 5.00 msec/click Delay Point INPUT/PRE FADER Delay Edit Unit meter/feet/msec TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 216 -12 dB – +42 dB When Analog Reference Level is 0 dBu and Digital Reference Level is -18 dBFS When PAD OFF +6 dB – +60 dB When PAD ON -14 dB – +40 dB TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 217 (-10 dB - +10 dB: 0.05 (-10 dB - +10 dB: 2 dB/ dB/click) click) MUTE OFF/ON Phase Sw Normal/Reverse Main L/R Assign OFF/ON Pan Bal L100 – C – R100 1 point/click 10 point/click TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 218 Monitor Monitor Delay Switch OFF/ON 0.0 meter – 117.3 meter 0.1 meter/click 2.0 meter/click Monitor Delay Time 0.0 feet – 384.8 feet 0.1 feet/click 5.0 feet/click 0.00 msec – 341.32 msec 0.02 msec/click 5.00 msec/click TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 219 16 – Parameter tables Sonicview 16/24 Mixer Basic Parameters (FX) FX common Fine Step Coarse Steps Function Parameter steps (when LCD knob turned (when LCD knob turned without being pressed) while being pressed) 1 point/click 40 point/click FX Input Level -∞...
Page 220 1 msec − 3000 msec 3000 1 msec/click 100 msec/click Delay time L/C/R FEEDBACK 0 − 100 1 point/click 5 point/click Feedback amount WET LEVEL L/C/R 0 − 100 1 point/click 5 point/click Wet level TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 221 10 deg/click modulation phase difference Shift amount (in PITCH 1/2 -24 − +24 1 point/click 2 point/click semitones) PITCH Shift amount (in FINE TUNE 1/2 -50 Cent − +50 Cent 1 cent/click 5 cent/click cents) TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 222 EXP Tom -28 dB 60 msec 380 msec Threshold Knee Center Feq P010 DE-ESSER DE-ESS Vocal 2k -28 dB 2.5 kHz 3.45 Threshold Knee Center Feq P011 DE-ESSER DE-ESS Vocal 4k -28 dB 4.2 kHz 4.32 TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 223 4.76 kHz Gain Gain -4.0 dB Gain Gain +6.0 dB Low Mid Hi Mid 1.41 1.04 P012 Rack Tom 2 Freq Freq 397 Hz Freq Freq 4.24 kHz Gain Gain -4.0 dB Gain Gain +4.0 dB TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 224 Attack Release Output Gain P010 Vocal Cho -28 dB 3.33:1 30 msec 150 msec +1 dB Threshold Ratio Knee Attack Release Output Gain P011 Vocal Female -25 dB 2.50:1 25 msec 150 msec +3 dB TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 225 P012 FLANGER Flanger 0.20 Hz 40 msec 180 deg RATE STAGE RESONANCE PHASE P013 PHASER Phaser 0.40 Hz 180 deg PITCH 1 FINE 1 PITCH 2 FINE 2 P014 PITCH Pitch -10 cent +10 cent TASCAM Sonicview 16/Sonicview 24 V1.1.0...
Page 226 TEAC CORPORATION https://tascam.jp/jp/ Phone: +81-42-356-9143 1-47 Ochiai, Tama-shi, Tokyo 206-8530 Japan TEAC AMERICA, INC. https://tascam.com/us/ Phone: +1-323-726-0303 10410 Pioneer Blvd., Unit #1, Santa Fe Springs, California 90670, U.S.A TEAC UK Ltd. https://www.tascam.eu/en/ Phone: +44-1923-797205 Luminous House, 300 South Row, Milton Keynes, Buckinghamshire, MK9 2FR, UK...

This manual is also suitable for:
