H-3789
SPIRAL CLOTHES RACK
TOOLS INCLUDED
Large Allen Wrench
Small Allen Wrench
RECOMMENDED TOOL
Phillips Screwdriver
Bottom Post
(Bolt & Lock Washer Attached)
Top Post
PAGE 1 OF 4
1-800-295-5510
uline.com
PARTS
Base
Spiral Tube
(2 End Caps Attached)
Pour le français, consulter les pages 3-4.
Flat Washer
Large Allen Wrench
Collar
Small Allen Wrench
Red Hardware Bag
Spacer x 2
(Screw and Headless
Screw Attached)
0414 IH-3789
Advertisement
Related Manuals for U-Line H-3789
Summary of Contents for U-Line H-3789
- Page 1 Pour le français, consulter les pages 3-4. π H-3789 1-800-295-5510 uline.com SPIRAL CLOTHES RACK TOOLS INCLUDED Large Allen Wrench Small Allen Wrench RECOMMENDED TOOL Phillips Screwdriver PARTS Flat Washer Large Allen Wrench Collar Small Allen Wrench Bottom Post Base Red Hardware Bag (Bolt &...
- Page 2 ASSEMBLY Remove bolt and lock washer from bottom post. 3. Unscrew two screws from straight end of spacers. Connect bottom post to base using bolt, lock Attach spacers to spiral tube using two screws. washer, flat washer and collar. Tighten with large (See Figure 3) Allen wrench.
- Page 3 π H-3789 1-800-295-5510 uline.ca PRÉSENTOIR À VÊTEMENTS EN SPIRALE OUTILS INCLUS Grande clé Allen Petite clé Allen OUTIL RECOMMANDÉ Tournevis Phillips PIÈCES Rondelle plate Grande clé Allen Collet Petite clé Allen Poteau inférieur Base Sac de quincaillerie rouge (boulon et rondelle de blocage inclus)
- Page 4 ASSEMBLAGE Retirez le boulon et la rondelle de blocage du 3. Dévissez les vis de l’extrémité droite des séparateurs. poteau inférieur. Fixez le poteau inférieur à la base Fixez les séparateurs au tube en spirale à l’aide des à l’aide du boulon, de la rondelle de blocage, de deux vis.
