Page 4: Table Of Contents
▪ A subset of the latest technical data is available on the regional 15 Commissioning Daikin website (publicly accessible). 15.1 Checklist before commissioning..........19 ▪ The full set of latest technical data is available on the Daikin 15.2 To perform a test run..............19 Business Portal (authentication required). 16 Configuration 16.1... -
Page 5: Specific Installer Safety Instructions
(insulation material) for the lining of Make sure installation, servicing, maintenance, repair and the duct and apply vibration insulation rubber to the applied materials follow the instructions from Daikin hanging bolts. (including all documents listed in “Documentation set”) ▪... -
Page 6: For The User
By ensuring waste batteries are disposed of ▪ Do NOT operate the unit with wet correctly, you will help to prevent potential negative consequences hands. for the environment and human health. Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10... -
Page 7: Instructions For Safe Operation
Use of wire or the room sufficiently if equipment with copper wire may cause the unit to burner is used together with the break down or cause a fire. system. FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10... - Page 8 Leaving the unit running under such the outdoor unit specifications for the circumstances may cause breakage, type of refrigerant to be used. electrical shock or fire. Contact your dealer. Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10...
-
Page 9: About The System
For combination with R32 outdoor unit Discharge air Outdoor units Temperature Cooling Heating Refrigerant piping + interconnection cable Drain pipe RZAG125 Outdoor –20~52°C DB –20~24°C DB Earth wiring –20~18°C WB Indoor 17~38°C DB 10~27°C DB 12~28°C WB FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10... -
Page 10: About Operation Modes
▪ Depending on the settings, the user interface can display the TIME TO CLEAN AIR FILTER notification. Clean the air filter when the notification is displayed. Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10... -
Page 11: To Clean The Air Outlet
OFF switch does NOT function properly. Global warming potential (GWP) value: 2087.5 If water leaks from the unit. Stop operation. The operation switch does NOT function Turn OFF the power properly. supply. FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10... -
Page 12: Relocation
▪ Installation options: Installation shall be done by an installer, the choice of materials and installation shall comply with the applicable legislation. In Europe, EN378 is the applicable standard. Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10... -
Page 13: Mounting The Indoor Unit
▪ When installing an air inlet duct, select fixing screws that stick out 5 mm on the inside of the flange to protect the air filter from damage during maintenance of the filter. FDA125A5VEB Installation and operation manual Split system air conditioners... -
Page 14: Guidelines When Installing The Ducting
Do NOT install operating ignition sources (example: open piping flames, an operating gas appliance or an operating electric heater) in the duct work. Make sure condensation water can be evacuated properly. This involves: Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10... - Page 15 T-joints with the correct gauge for the operating capacity of the units. Push in the plug. ▪ Set the plug and push it in using a Phillips screwdriver. (mm) T-joint Drain plug Philips screwdriver FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10...
-
Page 16: Piping Installation
ISO14903 can be used. protected against corrosion. Installation and operation manual FDA125A5VEB Split system air conditioners 4P494410-1D – 2022.10... -
Page 17: Electrical Installation
2 User interface cable: Route the cable through the frame, by the utility. connect the cable to the terminal block, and fix the cable with a cable tie. FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10... -
Page 18: Commissioning
1 2 3 L N General commissioning checklist. Next commissioning instructions in this chapter, a general commissioning checklist is also available on the Daikin 1 2 3 1 2 3 1 2 3 Business Portal (authentication required). The general commissioning checklist is complementary to... -
Page 19: Checklist Before Commissioning
• M: Mode number – First number: for group of units – Number between brackets: for individual unit • SW: Setting number / C1: First code number • —: Value number / C2: Second code number • : Default FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10... -
Page 20: Technical Data
▪ A subset of the latest technical data is available on the regional Connector (frame ground) Daikin website (publicly accessible). Harness ▪ The full set of latest technical data is available on the Daikin H*P, LED*, V*L Pilot lamp, light emitting diode Business Portal (authentication required). - Page 21 (IGBT) power module Wireless remote controller Terminal Terminal strip (block) Electronic expansion valve coil Y*R, Y*S Reversing solenoid valve coil Ferrite core ZF, Z*F Noise filter FDA125A5VEB Installation and operation manual Split system air conditioners 4P494410-1D – 2022.10...
