FDA200AXVEB

FDA250AXVEB

Installer and user reference guide

Split system air conditioners

Need help?

Do you have a question about the FDA200AXVEB and is the answer not in the manual?

Questions and answers

Summary of Contents for Daikin FDA200AXVEB

Page 1 Installer and user reference guide Split system air conditioners FDA200AXVEB FDA250AXVEB...
Page 2 Table of contents Table of contents 1 About the documentation About this document..............................Meaning of warnings and symbols ..........................2 General safety precautions For the installer ................................2.1.1 General................................2.1.2 Installation site............................... 2.1.3 Refrigerant — in case of R410A or R32......................2.1.4 Electrical.................................
Page 3 Table of contents 15 About the units and options 15.1 Identification .................................. 15.1.1 Identification label: Indoor unit........................15.2 About the indoor unit..............................15.3 System layout ................................. 15.4 Combining units and options ............................15.4.1 Possible options for the indoor unit......................16 Unit installation 16.1 Preparing the installation site ............................
Page 4 WARNING Make sure installation, servicing, maintenance, repair and applied materials follow the instructions from Daikin (including all documents listed in “Documentation set”) and, in addition, comply with applicable legislation and are performed by qualified persons only. In Europe and areas where IEC standards apply, EN/IEC 60335-2-40 is the applicable standard.
Page 5 A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of the latest technical data is available on the Daikin Business Portal (authentication required). 1.2 Meaning of warnings and symbols DANGER Indicates a situation that results in death or serious injury.
Page 6 About the documentation Symbol Explanation The unit contains rotating parts. Be careful when servicing or inspecting the unit. Symbols used in the documentation: Symbol Explanation Indicates a figure title or a reference to it. Example: " 1–3 Figure title" means "Figure 3 in chapter 1". Indicates a table title or a reference to it.
Page 7 WARNING Improper installation or attachment of equipment or accessories could result in electrical shock, short-circuit, leaks, fire or other damage to the equipment. ONLY use accessories, optional equipment and spare parts made or approved by Daikin unless otherwise specified. WARNING Make sure installation, testing and applied materials comply with applicable legislation (on top of the instructions described in the Daikin documentation).
Page 8 WARNING Make sure installation, servicing, maintenance and repair comply with instructions from Daikin and with applicable legislation (for example national gas regulation) and are executed ONLY by authorised persons. FDA200+250AXVEB Installer and user reference guide Split system air conditioners 4P580572-1B –...
Page 9 General safety precautions WARNING ▪ Take precautions to avoid excessive vibration or pulsation to refrigeration piping. ▪ Protect the protection devices, piping and fittings as much as possible against adverse environmental effects. ▪ Provide space for expansion and contraction of long runs of piping. ▪...
Page 10 General safety precautions NOTICE ▪ The pipework shall be securely mounted and guarded protected from physical damage. ▪ Keep the pipework installation to a minimum. To determine the minimum floor area 1 Determine the total refrigerant charge in the system (= factory refrigerant charge additional refrigerant amount charged).
Page 11 General safety precautions Ceiling-mounted Wall-mounted Floor-standing unit unit unit m (kg) m (kg) A m (kg) A ≤1.842 — ≤1.842 — ≤1.842 — 1.843 28.9 1.843 3.64 1.843 4.45 3.95 4.83 34.0 4.34 5.31 41.2 5.79 49.0 4.74 5.13 6.39 57.5 7.41 66.7...
Page 12 General safety precautions WARNING Take sufficient precautions in case of refrigerant leakage. If refrigerant gas leaks, ventilate the area immediately. Possible risks: ▪ Excessive refrigerant concentrations in a closed room can lead to oxygen deficiency. ▪ Toxic gas might be produced if refrigerant gas comes into contact with fire. WARNING ALWAYS recover the refrigerant.
Page 13 General safety precautions Then A siphon tube is NOT present Charge with the cylinder upside down. ▪ Open refrigerant cylinders slowly. ▪ Charge the refrigerant in liquid form. Adding it in gas form may prevent normal operation. CAUTION When the refrigerant charging procedure is done or when pausing, close the valve of the refrigerant tank immediately.
Page 14 General safety precautions WARNING ▪ ONLY use copper wires. ▪ Make sure the field wiring complies with the national wiring regulations. ▪ All field wiring MUST be performed in accordance with the wiring diagram supplied with the product. ▪ NEVER squeeze bundled cables and make sure they do NOT come in contact with the piping and sharp edges.
Page 15 General safety precautions Install power cables at least 1 meter away from televisions or radios to prevent interference. Depending on the radio waves, a distance of 1 meter may NOT be sufficient. NOTICE ONLY applicable if the power supply is three‑phase, and the compressor has an ON/ OFF starting method.
Page 16 WARNING Make sure installation, servicing, maintenance, repair and applied materials follow the instructions from Daikin (including all documents listed in “Documentation set”) and, in addition, comply with applicable legislation and are performed by qualified persons only. In Europe and areas where IEC standards apply, EN/IEC 60335-2-40 is the applicable standard.
Page 17 Specific installer safety instructions "17 Piping installation" [ 54]) Refrigerant piping installation (see CAUTION ▪ Incomplete flaring may cause refrigerant gas leakage. ▪ Do NOT re-use flares. Use new flares to prevent refrigerant gas leakage. ▪ Use flare nuts that are included with the unit. Using different flare nuts may cause refrigerant gas leakage.
Page 18 Specific installer safety instructions WARNING If the supply cord is damaged, it MUST be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. WARNING Prevent hazards due to inadvertent resetting of the thermal cut-out: power to this appliance MUST NOT be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly turned ON and OFF by the utility.
Page 19 For the user FDA200+250AXVEB Installer and user reference guide Split system air conditioners 4P580572-1B – 2024.07...
Page 20 User safety instructions 4 User safety instructions Always observe the following safety instructions and regulations. 4.1 General WARNING If you are NOT sure how to operate the unit, contact your installer. WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...
Page 21 User safety instructions ▪ Units are marked with the following symbol: This means that electrical and electronic products may NOT be mixed with unsorted household waste. Do NOT try to dismantle the system yourself: dismantling the system, treatment of the refrigerant, of oil and of other parts MUST be done by an authorised installer and MUST comply with applicable legislation.
Page 22 User safety instructions CAUTION ▪ NEVER touch the internal parts of the controller. ▪ Do NOT remove the front panel. Some parts inside are dangerous to touch and appliance problems may happen. For checking and adjusting the internal parts, contact your dealer. WARNING This unit contains electrical and hot parts.
Page 23 User safety instructions Maintenance and service (see "10 Maintenance and service" [ 33]) WARNING Improper detergents or cleaning procedure may cause damage on plastic components or water leakage. Splashed detergent on electric components, such as motors, may cause failure, smoke or ignition. CAUTION: Pay attention to the fan! It is dangerous to inspect the unit while the fan is running.
Page 24 User safety instructions DANGER: RISK OF ELECTROCUTION Disconnect the power supply for more than 10 minutes, and measure the voltage at the terminals of main circuit capacitors or electrical components before servicing. The voltage MUST be less than 50 V DC before you can touch electrical components.
Page 25 User safety instructions WARNING ▪ R410A is a non-combustible refrigerant, and R32 is a mildly flammable refrigerant; they normally do NOT leak. If the refrigerant leaks in the room and comes into contact with fire from a burner, a heater, or a cooker, this may result in a fire (in case of R32), or the formation of a harmful gas.
Page 26 About the system 5 About the system WARNING ▪ Do NOT modify, disassemble, remove, reinstall or repair the unit yourself as incorrect dismantling or installation may cause an electrical shock or fire. Contact your dealer. ▪ In case of accidental refrigerant leaks, make sure there are no naked flames. The refrigerant itself is entirely safe and non-toxic.
Page 27 Total electric power input elec Sound power level (cooling) dB(A) Sound power level (heating) dB(A) Contact details: DAIKIN INDUSTRIES CZECH REPUBLIC s.r.o. U Nové Hospody 1155/1, 301 00 Plzeň Skvrňany, Czech Republic FDA200 14.6 22.4 0.73 FDA250 16.6 0.79...
Page 28 User interface 6 User interface CAUTION ▪ NEVER touch the internal parts of the controller. ▪ Do NOT remove the front panel. Some parts inside are dangerous to touch and appliance problems may happen. For checking and adjusting the internal parts, contact your dealer.
Page 29 Before operation 7 Before operation CAUTION "4 User safety instructions" [ 20] to acknowledge all related safety instructions. NOTICE Do NOT place items which might be damaged by moisture under the indoor unit. Condensation may form if the humidity is above 80%, if the drain outlet is blocked or the filter is polluted.
Page 30 Operation 8 Operation 8.1 Operation range INFORMATION For the operation limits see the technical data of the connected outdoor unit. 8.2 About operation modes INFORMATION Depending on the installed system, some operation modes will not be available. ▪ The air flow rate may adjust itself depending on the room temperature or the fan may stop immediately.
Page 31 Operation 8.2.2 Special heating operation modes Operation Description Defrost To prevent a loss of heating capacity due to frost accumulation in the outdoor unit, the system will automatically switch to defrost operation. During defrost operation, the indoor unit fan will stop operation, and the following icon will appear on the home screen: The system will resume normal operation after approximately 6...
Page 32 Energy saving and optimum operation 9 Energy saving and optimum operation CAUTION NEVER expose little children, plants or animals directly to the airflow. NOTICE Do NOT place objects that should NOT get wet below the unit. Condensation on the unit or refrigerant pipes, or drain blockage may cause dripping. Possible consequence: Objects under the unit can get dirty or damaged.
Page 33 Maintenance and service 10 Maintenance and service 10.1 Precautions for maintenance and service CAUTION "4 User safety instructions" [ 20] to acknowledge all related safety instructions. NOTICE Maintenance MUST be done by an authorised installer or service agent. We recommend performing maintenance at least once a year. However, applicable legislation might require shorter maintenance intervals.
Page 34 Maintenance and service 10.2 Cleaning the air filter and air outlet CAUTION Turn off the unit before cleaning the air filter and air outlet. NOTICE ▪ Do NOT use gasoline, benzene, thinner polishing powder or liquid insecticide. Possible consequence: Discoloration and deformation. ▪...
Page 35 Maintenance and service 3 Clean the air filter. Use a vacuum cleaner or wash with water. If the air filter is very dirty, use a soft brush and neutral detergent. 4 Dry the air filter in the shadow. 5 Re-attach the air filter. Partially re-insert the first part of the air filter, align the middle part of the air filter with first part and push the 2 clips in place to lock the filter parts together.
Page 36 Maintenance and service ▪ Clean the air filter and the casing of the indoor unit (see "10.2 Cleaning the air filter and air outlet" [ 34]). Make sure to install cleaned air filters back in the same position. ▪ Turn on the power at least 6 hours before operating the system in order to ensure smoother operation.
Page 37 Troubleshooting 11 Troubleshooting If one of the following malfunctions occurs, take the measures shown below and contact your dealer. WARNING Stop operation and shut OFF the power if anything unusual occurs (burning smells etc.). Leaving the unit running under such circumstances may cause breakage, electrical shock or fire.
Page 38 Troubleshooting Malfunction Measure The system operates but ▪ Check if air inlet or outlet of outdoor or indoor cooling or heating is unit is not blocked by obstacles. Remove any insufficient. obstacles and make sure the air can flow freely. ▪...
Page 39 Troubleshooting ▪ The system does not start immediately after the power supply is turned on. Wait one minute until the micro computer is prepared for operation. 11.1.2 Symptom: White mist comes out of a unit (Indoor unit) ▪ When humidity is high during cooling operation. If the interior of an indoor unit is extremely contaminated, the temperature distribution inside a room becomes uneven.
Page 40 Relocation 12 Relocation Contact your dealer to remove and reinstall the entire unit. Moving units requires technical expertise. FDA200+250AXVEB Installer and user reference guide Split system air conditioners 4P580572-1B – 2024.07...
Page 41 Disposal 13 Disposal NOTICE Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FDA200+250AXVEB Installer and user reference guide Split system air conditioners...
Page 42 For the installer FDA200+250AXVEB Installer and user reference guide Split system air conditioners 4P580572-1B – 2024.07...
Page 43 About the box 14 About the box Keep the following in mind: ▪ At delivery, the unit MUST be checked for damage and completeness. Any damage or missing parts MUST be reported immediately to the claims agent of the carrier. ▪...
Page 44 About the box 14.1.2 To remove the accessories from the indoor unit 1 Remove the accessories from the side of the unit. Air outlet flange is placed under the indoor unit. 1× 1× 8× 49× 2× 1× 1× 2× 1× a Installation and operation manual b General safety precautions c Washers for hanger bracket...
Page 45 About the units and options 15 About the units and options In this chapter 15.1 Identification................................... 15.1.1 Identification label: Indoor unit ..........................15.2 About the indoor unit................................15.3 System layout..................................15.4 Combining units and options ..............................15.4.1 Possible options for the indoor unit ........................15.1 Identification NOTICE When installing or servicing several units at the same time, make sure NOT to switch...
Page 46 About the units and options a Indoor unit b Outdoor unit c User interface d Suction air e Discharge air f Refrigerant piping + interconnection cable g Drain pipe h Earth wiring 15.4 Combining units and options INFORMATION Certain options may NOT be available in your country. 15.4.1 Possible options for the indoor unit Make sure you have the following mandatory options: ▪...
Page 47 Unit installation 16 Unit installation In this chapter 16.1 Preparing the installation site ..............................16.1.1 Installation site requirements of the indoor unit....................16.2 Mounting the indoor unit............................... 16.2.1 Guidelines when installing the indoor unit......................16.2.2 Guidelines when installing the ducting ......................... 16.2.3 Guidelines when installing the drain piping ......................
Page 48 Unit installation NOTICE The equipment described in this manual may cause electronic noise generated from radio-frequency energy. The equipment complies to specifications that are designed to provide reasonable protection against such interference. However, there is no guarantee that interference will NOT occur in a particular installation. It is therefore recommended to install the equipment and electric wires in such a way that they keep a proper distance from stereo equipment, personal computers, etc.
Page 49 Unit installation Service space and ceiling opening size Make sure ceiling opening is big enough to ensure a sufficient clearance for maintenance and service. Top view: a 1100 b ≥1143 (mm) a Ceiling opening b Service space c Inspection hatch (600×600 mm) INFORMATION Some options may require additional service space.
Page 50 Unit installation e 1028 a Nut (field supply) b Washer (accessories) c Hanger bracket d Double nut (field supply) e Suspension bolt pitch ▪ Install the unit temporarily. 1 Attach the hanger bracket to the suspension bolt. 2 Fix it securely. ▪...
Page 51 Unit installation CAUTION ▪ Make sure the installation of the duct does NOT exceed the setting range of the external static pressure for the unit. Refer to the technical datasheet of your model for the setting range. ▪ Make sure to install the canvas duct so vibrations are NOT transmitted to the duct or ceiling.
Page 52 Unit installation d Insulation (field supply) e Canvas duct (field supply) f Aluminium tape (field supply) ▪ Filter. Be sure to attach an air filter inside the air passage on the air inlet side. Use an air filter with dust collecting efficiency ≥50% (gravimetric method). The included filter is not used when the intake duct is attached.
Page 53 Unit installation b Refrigerant pipes Drain piping connection 1 Pull out the drain plug. 2 Install the adapter for the drain hose (field supply). 3 Push the drain hose as far as possible over the adapter for the drain hose. 4 Tighten the metal clamp until the screw head is less than 4 mm from the metal clamp part.
Page 54 Piping installation 17 Piping installation In this chapter 17.1 Preparing refrigerant piping ..............................17.1.1 Refrigerant piping requirements ........................... 17.1.2 Refrigerant piping insulation ..........................17.2 Connecting the refrigerant piping............................17.2.1 About connecting the refrigerant piping....................... 17.2.2 Precautions when connecting the refrigerant piping ................... 17.2.3 Guidelines when connecting the liquid piping ......................
Page 55 Piping installation Depending on the applicable legislation and the maximum working pressure of the unit (see "PS High" on the unit name plate), larger piping thickness might be required. 17.1.2 Refrigerant piping insulation ▪ Use polyethylene foam as insulation material: with a heat transfer rate between 0.041 and 0.052 ...
Page 56 Piping installation 17.2.2 Precautions when connecting the refrigerant piping INFORMATION Also read the precautions and requirements in the following chapters: ▪ "2 General safety precautions" [ 7] ▪ "17.1 Preparing refrigerant piping" [ 54] DANGER: RISK OF BURNING/SCALDING NOTICE ▪ Do NOT use mineral oil on flared part. ▪...
Page 57 Piping installation NOTICE Do NOT open the refrigerant stop valve before checking the refrigerant piping. When you need to charge additional refrigerant it is recommended to open the refrigerant stop valve after charging. 17.2.3 Guidelines when connecting the liquid piping INFORMATION To connect the liquid piping use flare connection.
Page 58 Piping installation a Cut exactly at right angles. b Remove burrs. 3 Remove the flare nut from the stop valve and put the flare nut on the pipe. 4 Flare the pipe. Set exactly at the position as shown in the following figure. Flare tool for R410A or Conventional flare tool R32 (clutch type)
Page 59 Piping installation c Taping d Manual valve e Pressure-reducing valve f Nitrogen ▪ Do NOT use anti-oxidants when brazing pipe joints. Residue can clog pipes and break equipment. ▪ Do NOT use flux when brazing copper-to-copper refrigerant piping. Use phosphor copper brazing filler alloy (BCuP-2: JIS Z 3264/, BCu 93P-710/795: ISO3677), which does not require flux.
Page 60 Piping installation A Liquid piping B Gas piping a Insulation material (field supply) b Cable tie (field supply) c Attached piping (accessory) d Hexagon head bolt and spring washer (accessory) e Refrigerant pipe connection (attached to the unit) f Unit NOTICE Make sure to insulate all refrigerant piping.
Page 61 Electrical installation 18 Electrical installation In this chapter 18.1 About connecting the electrical wiring ..........................18.1.1 Precautions when connecting the electrical wiring ....................18.1.2 Guidelines when connecting the electrical wiring ....................18.1.3 Specifications of standard wiring components ..................... 18.2 To connect the electrical wiring to the indoor unit ....................... 18.1 About connecting the electrical wiring Typical workflow Connecting the electrical wiring typically consists of the following stages:...
Page 62 Electrical installation WARNING ▪ If the power supply has a missing or wrong N-phase, equipment might break down. ▪ Establish proper earthing. Do NOT earth the unit to a utility pipe, surge absorber, or telephone earth. Incomplete earthing may cause electrical shocks. ▪...
Page 63 Electrical installation Use the following methods for installing wires: Wire type Installation method Single-core wire AA´ A´ Stranded conductor wire twisted to "solid-like" connection a Curled wire (single-core or twisted stranded conductor wire) b Screw c Flat washer Stranded conductor wire with round crimp-style terminal a Terminal...
Page 64 Electrical installation Power supply Phase FDA200: 4 A FDA250: 4.3 A MCA=Minimum circuit ampacity. Stated values are maximum values (see electrical data of indoor unit for exact values). Components Power supply cable MUST comply with national wiring regulation. 3-core cable Wire size based on the current, but not less than 1.5 mm Interconnection cable Only use harmonised wire providing double...
Page 65 Electrical installation 3 Interconnection cable (indoor↔outdoor): Route the cable through the opening for the cable. Connect it to the terminal block (make sure the numbers 1~3 match with the numbers on the outdoor unit), and connect the earth wiring. 4 Power supply cable: Route the cable through the opening and connect the cable to the terminal block (L, N, earth).
Page 66 Electrical installation 7 Reattach the service cover. Complete system wiring example For the wiring of outdoor units, refer to the installation manual attached to the outdoor units. Pair type: 1 remote controller controls 1 indoor unit (standard) 1 2 3 1 2 3 a Power supply b Main switch...
Page 67 Electrical installation 1 2 3 1 2 3 a Power supply b Main switch c Residual current device d User interface e Separate power supply INFORMATION In case of group control, it is not necessary to assign a group address to the indoor unit.
Page 68 19 Commissioning NOTICE General commissioning checklist. Next to the commissioning instructions in this chapter, a general commissioning checklist is also available on the Daikin Business Portal (authentication required). The general commissioning checklist is complementary to the instructions in this chapter and can be used as a guideline and reporting template during commissioning and hand-over to the user.
Page 69 Commissioning 19.3 Checklist before commissioning 1 After the installation of the unit, check the items listed below. 2 Close the unit. 3 Power up the unit. You have read the complete installation and operation instructions described in the installer and user reference guide. The indoor unit is properly mounted.
Page 70 Configuration 20 Configuration 20.1 Field setting Make the following field settings so that they correspond with the actual installation setup and with the needs of the user: ▪ External static pressure setting using: Airflow automatic adjustment setting User interface ▪ Time to clean air filter Setting: External static pressure INFORMATION...
Page 71 Configuration 5 After airflow automatic adjustment is finished (air conditioning unit will stop) check if the value number “—“ is set to 02. If there is no change, perform the setting again. Setting content: Then — Airflow adjustment is OFF 11(21) Completion of automatic airflow adjustment Start of automatic airflow adjustment...
Page 72 Configuration If you want an interval of… Then — (air contamination) ±2500 h (light) 10 (20) ±1250 h (heavy) Notification ON Notification OFF ▪ 2 user interfaces: When using 2 user interfaces, one must be set to "MAIN" and the other to "SUB". Field settings are defined as follows: •...
Page 73 Hand-over to the user 21 Hand-over to the user Once the test run is finished and the unit operates properly, make sure the following is clear for the user: ▪ Make sure that the user has the printed documentation and ask him/her to keep it for future reference.
Page 74 Troubleshooting 22 Troubleshooting 22.1 Solving problems based on error codes If the unit runs into a problem, the user interface displays an error code. It is important to understand the problem and to take measures before resetting an error code. This should be done by a licensed installer or by your local dealer. This chapter gives you an overview of most possible error codes and their descriptions as they appear on the user interface.
Page 75 Disposal 23 Disposal NOTICE Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FDA200+250AXVEB Installer and user reference guide Split system air conditioners...
Page 76 A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of the latest technical data is available on the Daikin Business Portal (authentication required). 24.1 Wiring diagram 24.1.1 Unified wiring diagram legend For applied parts and numbering, refer to the wiring diagram on the unit.
Page 77 Technical data Symbol Meaning AC*, CN*, E*, HA*, HE*, HL*, HN*, HR*, Connection, connector MR*_A, MR*_B, S*, U, V, W, X*A, K*R_*, NE D*, V*D Diode Diode bridge DIP switch Heater FU*, F*U, (for characteristics, refer to Fuse PCB inside your unit) Connector (frame ground) Harness H*P, LED*, V*L...
Page 78 Technical data Symbol Meaning Thermo switch Residual current device Resistor Thermistor Receiver Limit switch Float switch S*NG Refrigerant leak detector S*NPH Pressure sensor (high) S*NPL Pressure sensor (low) S*PH, HPS* Pressure switch (high) S*PL Pressure switch (low) Thermostat S*RH Humidity sensor S*W, SW* Operation switch SA*, F1S...
Page 79 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
Page 80 4P580572-1B 2024.07...
