Be sure to read this Operation Manual before using your machine to ensure safe operation.
© 2011 Bob's Space Racers® Incorporated
Table of Contents
MODEL VIEW ............................ 2
SPECIFICATIONS ..................... 3
Rated power supply: .................... 3
Power consumption: .................... 3
Dimensions: ................................ 3
Weight: ........................................ 3
INTRODUCTION ....................... 4
Overview: .................................... 4
To Maintain Safety: ..................... 4
WARNING: (or) CAUTION: ......... 4
NOTE (or) NOTICE: .................... 4
INFORMATION: ........................ 5
SET UP: ..................................... 5
PACKAGE CONTENTS ............ 6
ARCADE OPERATION MANUAL
th
427 15
Street, Daytona Beach, Florida 32117
Tel: (386) 677-0761 Fax: (386) 677-0794
INSTALLATION ........................ 7
Play zone (Operation Zone): ....... 7
Locations to avoid: ...................... 7
GAME LEVELING: .................... 8
CORD ........................................ 9
INSTRUCTION FOR PLAY ..... 10
OPTION SETTINGS ................ 10
Value, Hit Bonus Points .............10
Ticket, Demo / Music .................11
Bonus Increase, Difficulty ..........12
Point Group, Test ......................13
11-08-11
WARNING
INSPECTION ........................... 14
Maintenance: ............................ 14
Cleaning: ................................... 14
GAME LAYOUT ....................... 15
TROUBLESHOOTING ............. 16
General Troubleshooting: ......... 17
SHOOT ADJUSTMENT: .......... 18
PARTS LIST ............................ 18
WARRANTY ............................ 24
CALLING FOR SERVICE ........ 25
