- Page 1 ™ BSR V3.0 WARNING Be sure to read this Operation Manual before using your machine to ensure safe operation. SEPTEMBER 2010...
- Page 2 BONGO BEAT ™ v3.0 ARCADE...
-
Page 3: Table Of Contents
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 TABLE OF CONTENTS 1. SPECIFICATIONS 2. INTRODUCTION 2-1 Overview 2-2 Important Safety Information 2-3 Set Up 3. PACKAGE CONTENTS 4. INSTALLATION 4-1 Installation 4-2 Play zone (Operation Zone) 4-3 Locations to avoid... -
Page 4: Specifications
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 1. SPECIFICATIONS (1) Rated power supply: 110VAC ±5%, 60 Hz. (Note: As for the actual voltage, please refer to the label on the game). (2) Power consumption: Minimum 125W (1.14 Amps) (3) Dimensions: 56.44”... -
Page 5: Introduction
BONGO BEAT retains all of the great game play you have come to expect of a game from BSR, and is specifically designed for today's Arcade environment. The new game uses technology specifically developed for this application. -
Page 6: Important Safety Information
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 2-2. Important Safety Information: IMPORTANT SAFETY INFORMATION WARNING: Unplug the game from the AC wall receptacle when servicing this product. Failure to do so could result in serious injury to yourself or others. -
Page 7: Package Contents
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 3. PACKAGE CONTENTS Be sure to check that you have received all packages indicated below. (1) Game Unit (2) Accessories NAME SPECIFICATION ILLUSTRATION NOTE Wrapped up 10A/250V, 10 feet Power cord... -
Page 8: Installation
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 4. INSTALLATION ATTENTION ●For indoor use only! 4-1. Installation Check the parts list before installation. Verify that all parts that have been received and are in good condition. 4-2. Play zone (Operation Zone): This machine requires space for playing the game and for the maintenance as shown below. -
Page 9: Locations To Avoid
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 4-3. Locations to avoid: WARNING The machine is designed for indoor use only. Never install this machine outdoors or in any of the following: ● Locations exposed to direct sunlight ●... -
Page 10: Palm Leaf Assembly
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 4-5. Palm Leaf Assembly: Disconnect game power before proceeding 1) Remove 4 Screws from back cover of Palm 2) Pull cover up so you can access the wires for the Arch. - Page 11 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 5) Route wire plug from beacon through center hole of Palm Leaf Assembly and mount beacon 6) Install green beacon cover. Make sure position using three wood screws that are provided.
-
Page 12: Connecting The Power Cord
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 5. CONNECTING THE POWER CORD 1. Insert the socket end of power cord into the power input of the game. 2. Insert the power cord plug into a service outlet. -
Page 13: Instruction For Play
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 6. INSTRUCTION FOR PLAY 1. Insert coin(s), the game starts. 1. The object of the game is to be the first toy to reach the top of the tree. When the game play starts, the bongo drums will light up. - Page 14 BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 P6 – Toy Run Time : This function allows the user to game the distance that the Monkey will travel. The settings are 0 – 24 with the default being set to 4. For Progressive Speed, it was found that a setting of 6 was best suited as it decreases the space that is travelled by the monkey from the default setting.
-
Page 15: Setting Options
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 7-1. Setting Options: Program Button Select Button Step Button PANEL PROGRAMMING ASSY The programming options are readable only by the game operator for the purpose of customizing the game to suit their location. -
Page 16: Maintenance And Inspection
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 8. MAINTENANCE AND INSPECTION 8-1. Maintenance: Due to the design of the machine, very little periodic maintenance is required. Start the game and verify the correct operation before putting the game into everyday operations. -
Page 17: Test Mode
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 8-3 Test Mode: Running Test Mode: Turn on the game power, wait 1 second then press all 3 buttons at the same time on the Panel Programming Assembly. Each unit will cycle through a test mode at 30 second intervals. The Bongo’s will light up, the monkey will go to the top of the tree and the Beacons will light up. -
Page 18: Troubleshooting
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 9. TROUBLESHOOTING WARNING For your safety, and to reduce risk of damage to your game read the Important Safety Information in Chapter 2-2 before attempting any troubleshooting procedure. TROUBLESHOOTING PHILOSOPHY When troubleshooting any product, certain general guidelines should be followed. - Page 19 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 Symptom Possible Problem Solution POWER POWER Sound Problems Low Volume Check Volume Control and adjust as necessary Faulty speaker harnessing Check connections and/or repair harnessing -No sound -Low Sound Faulty speaker...
-
Page 20: Parts List
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 10. PARTS LIST MECHANICAL PARTS CX700737 FRONT HEADDRESS NEON GRN CX700738 REAR HEADDRESS NEON GRN E0030635 GREEN DOME CX700756 ARCH GUIDE CX700780 TOY SHIELD PLEXIGLASS M0008152 TOY PLUSH M0004498 PAD FOR DRUM... -
Page 21: Part Identification
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 10-1 Part Identification: Main Board PN: ARWB2001 Board Station Drive I/O PN: E0007276 Board Motor DC Drive PN: E0007277 PANEL PROGRAMMING ASSY PN: WX800015 Board 2 Digit Display PN: E0007275... - Page 22 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 WX000055 Support Shield Alum E0013947-GRN Switch Push Button M0007497 Spring M0007800 Button Shell M0007900 Button Foam Top M0007902 Sits Button Foam Stop here...
- Page 23 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 Front Headdress Neon Green Replacement PN: CX700737 Beacon Bulb (Decal Sold Separately PN: E0029107 PN: A0007421) Rear Headdress Neon Green Dome Green PN: E0030635 PN: CX700738 (Decal Sold Separately (Decal Sold Separately...
- Page 24 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 DECALS Part # A0007422 Part # A0007421 Part # A0007419 Part # A0007420 Part # A0007416 Part # A0007414 Part # A0007418 Part # A0007417 Part # A0007415 Part # AX000125...
-
Page 25: Warranty
® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 11. WARRANTY BOB’S SPACE RACERS INC. 90 DAY COIN-OPERATED GAME WARRANTY ® INCLUDED IN THIS WARANTY Bob’s Space Racers , Inc. warrants to the original purchaser only that the equipment that is the subject of this sale conforms to its specifications, and is free from defects under normal service for a 90 day period from the original date of deliver. - Page 26 ® BOB’S SPACE RACERS BONGO BEAT ARCADE MANUAL BSR V3.0 427 15 Street Daytona Beach, FL 32117 Telephone number: 386/677-0761 FAX: 386/677-0794 WHEN CALLING FOR SERVICE 1. When calling for service, please check the service manual first. Many times the answer to your problem has been addressed in this documentation.
