- Page 1 Short Range Basketball GAME ASSEMBLY INSTRUCTIONS Bob’s Space Racers, Inc. 427 15 Street Daytona Beach, Fl 32117 Tel: (386) 677-0761 Fax: (386) 677-0794...
- Page 2 Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions Model View (4 Player Unit Shown Here) ©2012 Bob’s Space Racers, Inc.
-
Page 3: Tools Needed
Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions TOOLS NEEDED: Ratchet and 7/16 Socket 7/16 Open end wrench Box cutter (for opening packaging) ASSEMBLY: Start by taking the parts off the pallet and group them together by type (example: side rails, basket ball nets, etc). ... - Page 4 Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions Now find the top left and top right side supports and fasten them to the back panel using the 3/8”x3” Hex bolts and nuts. Only secure the top rails on both sides Notice the rail has indentation to identify which rails go where.
- Page 5 Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions Now stand the back board up. ◦ Locate the front counter support rail and attach the backboard to the counter support rail. ◦ Attach remaining side rails. Now install the feet ◦...
- Page 6 Locate the rear canvas rail and the backboard stabilizing support rail and attach to the backboard assembly using the 1/4”x3 1/2” hex bolts and nuts. Now, attach the “Hot Shot” Marquee display ◦ Use the 1/4”x4” for the top ◦...
- Page 7 Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions After the marquee is attached, using the 3/8”x3” bolts, secure the basket ball backboard and net assemblies You can use any of the holes to set the basket as high/low as you want ...
- Page 8 Now locate the front counter and remove it from the pallet. You will see some Anchor bolts holding the counter down to the pallet. Now slide the counter up against the canvas rail. Your HOT SHOT™ game is now installed and ready for use! ©2012 Bob’s Space Racers, Inc.
- Page 9 Bob’s Space Racers, Inc.® Short Range Basketball Assembly Instructions CALLING FOR SERVICE 1. When calling for service, please check the service manual first. Many times the answer to your problem has been addressed in this documentation. 2. Please make sure you have the serial number of the game ready when you call. 3.
