Lifetime ADVENTURE CASTLE 91090 Assembly Instructions Manual

ADVENTURE CASTLE
PLAYSET
MODEL 91090
BEFORE ASSEMBLY:
• Prepare a level surface with the proper safety zone (see page 12).
• 3 adults recommended for setup.
• Inspect all parts and hardware. Ensure all are included
using the Parts Identifier in the middle of these instructions.
The Parts Identifier , in yellow, can be removed from the
instructions for quick reference.
TOOLS REQUIRED
(not included—unless otherwise indicated)
3/16 in/po
(≈5 mm)
(EEO x1, )
included
3/16 in/po
(≈5 mm)
(HFZ x1, )
included
(1)
(1)
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Dial 1-800-225-3865
7:00 am–5:00 pm (M–F) MST
and 9:00 am–1:00 pm (Sat) MST
(English, French, Spanish)
™
3/8 in/po
(≈10 mm)
(1)
1/4 in/po (≈7 mm)
7/16 in/po
(≈11 mm)
3/8 in/po (≈10 mm)
(1)
1/2 in/po
(≈13 mm)
(1)
7 mm
(1)
Live Chat: www.lifetime.com/customerservice
(click on "LIVE CHAT" tab)
For customer service in mainland Europe:
E-mail: cs@lifetimeproducts.eu
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
IMPORTANT, RETAIN FOR FUTURE
(1)
(1)
(1)
(1)
(1)
(1, )
included
(1)
WARNING: Only for domestic/
residential use.
REFERENCE: READ CAREFULLY
TABLE OF CONTENTS
Icon legend..........................................................4
Warnings & notices...............................................5
Safety information................................................6
Safe play area....................................................12
1 Tube slide assembly........................................14
2 Tower frame assembly.....................................36
3 Deck assembly................................................61
4 Handrail assembly...........................................67
Parts identifi er................................................i–viii
5 Staircase assembly.........................................77
6 Swing bar assembly........................................88
7 Roof assembly................................................98
8 Tower walls assembly...................................106
(1)
9 Swings and accessories...............................125
10 Anchor kit installation.................................128
Maintenance.................................................136
Registration......................................................139
(1)
Warning sticker.................................................140
Warranty.........................................................141
Model Number: 91090
Product ID:
