ANCHOR KIT
MODEL 90641
BEFORE ASSEMBLY:
• Before you start, make sure the playset is in the desired
location over ground that is soft enough to drive the
anchors in by hammer.
• 2+ adults recommended for setup.
• Have the playset instructions handy. Once the anchors
are installed, use a loose-fi ll material to cover the play
area of the playset (see page 12 of the Playset Assembly
Instructions).
TOOLS REQUIRED
1/2" (≈13 mm)
(x1)
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Call: 1-800-225-3865
7:00 am–5:00 pm (Monday–Friday) MST
and 9:00 am–1:00 pm Saturday MST
(English, French, Spanish)
7 mm
3/16" (≈5 mm)
(x1)
(x1)
Live Chat: www.lifetime.com/customerservice
(click on "LIVE CHAT" tab)
For customer service in mainland Europe:
E-mail: cs@lifetimeproducts.eu
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
(x1)
Model Number: 90641
Product ID:
