COMPONENTS
Game Boy Player
Top
View
Front
View
Right
Side
View
Bottom
View
1
SYSTEM SETUP

INSTALLING THE GAME BOY PLAYER

IMPORTANT: Please review the separate Health and Safety
Precautions Booklet included with the Nintendo GameCube
and Game Discs before installing the Game Boy Player.
1. Remove any Game Discs from the Nintendo GameCube
and make sure the power is turned OFF.
2. Remove the High Speed
Port cover from the bottom
of the Nintendo GameCube
and put this in a safe place
for future use if the Game
Boy Player is removed.
3. Install the Game Boy
Player on the bottom of the
Nintendo GameCube,
inserting the High Speed
Port Connector into the
High Speed Port.
4. Tighten the attachment
screws clockwise using a
flat-bladed screwdriver or
coin. Do not over tighten.
3

Game Boy Player Start-up Disc

IMPORTANT: Please review the Game Disc
High Speed Port
Precautions/Maintenance sections of the separate Health
Connector
and Safety Precautions Booklet included with the
Connects to High
Nintendo GameCube and games before using this
Speed Port on the Start-up Disc.
bottom of the
Nintendo GameCube
This Start-up Disc must be loaded into the Nintendo
GameCube for the Game Boy Player to work properly.
When not using this disc, be sure to keep it safely stored
and protected from loss or damage.
Accessory Slots
For attachment of
Game Boy
Accessories
Game Pak Slot
For loading a
Game Pak
External Extension
Connector
For connection of
Game Boy
Accessories
Game Pak Ejector
For ejecting a Game
Pak from the Game
Boy Player.
Attachment Screws
To attach the Game
Boy Player to the
bottom of the
Nintendo GameCube
INSTALLING THE START-UP DISC AND GAME
BOY GAME PAKS
1. Make sure the power is OFF on the Nintendo GameCube.
2. Open the Disc Cover on
the Nintendo GameCube
and insert the Start-up
Disc. Close the Disc
Cover.
3. With the label facing down, insert a Game Boy Game Pak
into the Game Pak Slot in the front of the Game Boy Player.
NOTE: Make sure
the Game Pak
label is facing
down.
4. Turn ON the power of the Nintendo GameCube. The TV
screen will first display the Game Boy Logo and then the
title screen for the game you are playing.
COMPONENTS
2
SYSTEM OPERATION
4
