- Page 1 SPINNING ® Commercial Bike Assembly Guide and Owner’s Manual PRO Power NXT Power Chrono www.spinning.com...
-
Page 2: Table Of Contents
CONTENTS Getting Started Guide Page 3 Program Safety Page 5 Assembly Guide Page 6 Bike Maintenance Page 12 Warranty Page 15 Trademark Usage Page 21... -
Page 3: Getting Started Guide
Together with the Spinning® program, Spinning® provides an unparalleled experience for studios and gyms worldwide. Before you start, you can learn more about Safety, Maintenance, Spinning® Accessories, Training, and the Spinning® Community by visiting us at www.spinning.com. - Page 4 Foot Position Note If your foot comes loose when riding, firmly press down Place the balls of your feet securely on the center of the pedals. on the resistance knob to stop and secure your foot. Foot Strap Resistance Control and Stop Function Adjust the toe straps to hold your foot firmly on the pedal, Turn the resistance knob 5 to change the pedaling resistance.
-
Page 5: Program Safety
• Keep children and pets away from the bike whenever it is in use. • Stay hydrated. Drink plenty of water throughout your ride. • During warm-up and cool-down, pedal with a light amount of resistance at all times, The Spinning ®... -
Page 6: Assembly Guide
SPINNING® ASSEMBLY GUIDE Fore/aft handlebar knob Handlebar Resistance assembly Seat assembly knob Handlebar post Seat Handlebar slider knob adjustment Seat post pop-pin Seat adjustment Pedal pop-pin Crank arm Flywheel Rear stabilizer Front Adjustment feet stabilizer... - Page 7 3. Install and tighten the set screw in the rear of the post. 4. Pull the pop-pin out. 5. Insert head post into frame. 6. Tighten pop-pin (clockwise). all models clockwise to tighten www.spinning.com...
- Page 8 TILT THE BIKE FORWARD To avoid damage, ensure that the bike is on carpet, cardboard or other soft surface. 2. With 2 people, pivot the bike forward and gently rest it in a vertical position on the handlebars. One person should always hold the bike steady when in this position.
- Page 9 4. Install endcap using three 3mm screws. INSTALL THE SEAT SLIDER ASSEMBLY Pull the pop-pin back. 2. Insert the seatpost assembly into glide. 3. Secure the seatpost by releasing the pop-pin into an adjustment hole and turning the pop-pin (clockwise). www.spinning.com...
- Page 10 TILT THE BIKE REARWARD To avoid damage, ensure that the bike is on carpet, cardboard or other soft surface. 2. With 2 people, pivot the bike rearward and gently rest it in a vertical position on the seatpost. One person should always hold the bike steady when in this position.
- Page 11 Download the SPINPower Crank Connect app available free for Apple and Android devices and follow the on-screen instructions to calibrate your crank. You can also rename your crank, check for firmware updates and check the battery life, all from your mobile device. See the Studio SPINPower Crank supplement for more info. www.spinning.com...
-
Page 12: Bike Maintenance
Always purchase replacement parts and hardware from Spinning®. If you use parts not approved by Spinning®, you could void the Spinning® Limited Warranty. Use of parts not approved by Spinning® may cause injury and potential damage to your equipment. -
Page 13: Warranty
Inspect and tighten resistance knob assembly. o Level feet. • Clean and seal the bike frame. Sweat can corrode the bike frame. Spinning® recommends that you seal the bike frame at least once a month with equipment polish. To seal the bike frame: Wipe the bike frame using a clean lint-free cloth dampened with 30 parts water to 1 part non-abrasive detergent. - Page 14 (Friction-Resistant Bikes) Replace the Brake Pad Your bike comes with a spare brake pad. To order more pads, contact Spinning® Customer Support. To replace the brake pad: Remove tension from the brake pad by turning the resistance knob counterclockwise (–) until completely loose.
- Page 15 To claim under this warranty, the buyer must notify MDA or your authorized Spinning® Distributor within 30 days after the date of discovery of any nonconformity and make the affected product available for inspection by MDA or its service representative.
- Page 16 Spinner® Bike Line of products as set forth in a signed Product Quote that has been accepted by Spinning®, then such limited extended warranty (i) shall only apply to Mechanical and Electrical parts and Product Labor, if applicable, (ii)
- Page 17 This warranty is valid only in accordance with the conditions set forth below: 1. The warranty applies to the Spinning® product only if: a. it has been serviced by a Spinning® Authorized Service Provider and/or Spinning® Certified facility staff. Outside of North America, such product must be serviced by Spinning®...
- Page 18 Spinner® Bike Line Limited Warranty Except in Canada, Spinning® does not pay labor outside the United States. Equipment limited warranty is void when equipment is installed in a country other than where sold. Moving parts bolted to the structural frame are not included in the “Structural Frame”...
- Page 19 Exclusive Remedies. For any product described above that fails to conform to its warranty, Spinning® will provide, at its sole discretion, one of the following: (1) repair; (2) replacement; or (3) refund of the purchase price. Spinning® Limited Warranty service may be obtained by contacting the authorized Spinning® office or Distributor from whom you purchased the item.
- Page 20 EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES. EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES. SPINNING® AND/OR ITS SUPPLIERS SHALL HAVE NO OBLIGATION OR LIABILITY, WHETHER ARISING IN CONTRACT (INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE, OR IMPUTED NEGLIGENCE AND STRICT LIABILITY), OR OTHERWISE, FOR DAMAGE TO THE EQUIPMENT,...
-
Page 21: Trademark Usage
SPINNING TRADEMARK USAGE ® The Spin®, Spinner®, Spinning®, Spin Fitness®, Spin Pilates®, Spin Yoga®, SPINPower® and the Spinning logo ® trademarks are important business assets to Mad Dogg Athletics, Inc. and should be treated with care and respect. We rely on our trademarks to identify our products, services, activities and programs to distinguish them from those of our competitors. - Page 22 Badge COLORS FONTS To maintain a strong identity for the Spinning® program, it is neces- ›› For body text, the font family Proxima Nova should always be sary to employ a consistent color palette. Use these primary and used. As a general guideline, body text should be Proxima Nova secondary colors in all materials.
- Page 23 SPINNING® NOTES Complete this portion and keep for your records. Purchased from: _________________________________________ Example: Distributor or store name. Phone number: _________________________________________ Example: Distributor or store telephone number Product/model: _________________________________________ Example: Spinner Chrono®. Serial number: _________________________________________ The serial number is found on the box or bike frame.
- Page 24 Fax: 1.310.823.7408 info@spinning.com www.spinning.com SPINNING.COM ©2023 Mad Dogg Athletics, Inc. All rights reserved. Spin®, Spinner®, Spinning®, Spin Fitness®, Spin Yoga® ® SPINPower® and the Spinning logo ® are registered trademarks that are owned by Mad Dogg Athletics, Inc. Designed and engineered in Venice, California.
